Parts for Kitchenaid KRFF302EBS02: Shelf Parts

This replacement oven door handle restores a secure grip for opening and closing the oven door. It replaces a damaged, loose, or missing handle to make door use safer and more convenient. What it does:

• Provides a sturdy grip for opening and closing the oven door
• Replaces handles that are cracked, bent, loose, or missing
• Helps prevent slippage and improves user control when handling hot appliances
• Matches the original mounting style for a straightforward replacement

• Use basic hand tools; support the door while removing and installing the handle to avoid injury or damage
• Disconnect power to the appliance or ensure it is cool before attempting replacement
• Tighten mounting fasteners securely but do not overtighten to avoid stripping

The Pantry Drawer Rail is an OEM part for Whirlpool refrigerators. This part allows it to slide in and out smoothly for easy access to stored food items.

Causes of a bad pantry drawer rail can include repeated heavy loads, general wear and tear, or accidental damage.

Symptoms of a bad pantry drawer rail include:

• Difficulty sliding the pantry drawer in and out
• Pantry drawer not staying in place
• Uneven or wobbly drawer movement
• Visible damage or bending of the rail

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

Note: Right Hand Encap

The Pantry Endcap is an OEM part for Whirlpool refrigerators. As an important structural component, the pantry endcap provides structural integrity to the pantry bin as well as protection for the outer wall. It is specifically designed to fit seamlessly within the pantry to improve organization and optimize storage space.

Causes of a bad pantry endcap are typically wear and tear over time from repeated impacts, especially along the edges.

Symptoms of a damaged pantry endcap include:

• Visible dents, cracks or holes in the material
• Difficulty fully closing or sealing the pantry bin
• Reduced insulation value leading to warmer temperatures inside
• Inability to attach or mount accessories in the pantry area

This genuine OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Endcap, Pantry (lh) is an OEM part for Whirlpool refrigerators. It serves as the cover that encloses the left end of the refrigerator pantry drawer. The end cap is designed to match the style and finish of the surrounding refrigerator panels, providing a seamless appearance.

Causes of a bad endcap can include cracks or breaks from impact or handling, faulty clips or screws that no longer securely attach it to the drawer side, or general wear and tear over long-term use.

Symptoms of a bad Endcap include:

• Gaps between the endcap and drawer side where air or moisture can enter
• Loose or detached endcap that no longer properly encloses the pantry area
• Noticeable cosmetic damage or imperfections

This OEM replacement is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Shelf Frame is an OEM part for Whirlpool refrigerators. It supports the refrigerator shelves, providing a sturdy and stable base for food storage. This frame ensures that the glass or wire shelves remain securely in place and can handle the weight of stored items. The frame measures about 28 by 15.5 inches.

Causes of a bad shelf frame can include heavy loading, physical impacts, or material fatigue over time.

Symptoms of a bad Shelf Frame include:

• Shelves not sitting level or securely
• Cracks or breaks in the frame
• Difficulty installing or removing shelves
• Items falling or tipping over due to instability

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Drawer Glide Gear is an OEM part for Whirlpool refrigerators. This part ensures the smooth operation of refrigerator drawers, allowing them to slide in and out with ease. This gear mechanism is vital for the user-friendly access to stored food items, contributing to the efficient organization and optimization of space within the refrigerator.

Causes for replacement include physical damage such as cracks or breakage, wear that impedes smooth operation, or a malfunction that prevents drawers from opening or closing properly.

Symptoms of a bad Drawer Glide Gear include:

• Difficulty in sliding the refrigerator drawers
• Uneven movement or jamming of the drawer
• Noise when opening or closing the drawer

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

This spur gear is part of the appliance's drive assembly, transferring motor power to mating components. Replacing a worn or stripped gear restores smooth, consistent motion and helps eliminate grinding, slipping, or no-drive issues. What it does

• Transfers rotational power within the drive mechanism
• Maintains proper engagement with mating gear(s) for smooth operation
• Common failure symptoms: grinding/clicking noises, slipping or stalled movement, irregular motion
• Visual clues: rounded, chipped, or missing teeth

• One spur gear

• Disconnect power; turn off water supply before service
• Access the drive assembly and note gear orientation and any shims/washers during disassembly
• Inspect mating gears, bushings, and bearings; replace any worn components to prevent rapid re-failure
• Apply manufacturer-specified grease if required and tighten fasteners per service information

This 33-inch shaft-rack replaces the rack support shaft that the dishwasher rack slides on, restoring smooth in-and-out movement and correct rack alignment for easier loading and unloading. What it does:

• Acts as the axle for a dishwasher rack, supporting and guiding rack travel along the tub.
• Restores smooth sliding if the original shaft is bent, worn, or broken.
• Helps eliminate rack misalignment, rubbing, or sticking during use.
• Matches OEM fit and mounting points when used with the correct part number.

• Disconnect power and water to the appliance before beginning any repair.
• Remove the affected rack to access the shaft; keep track of end caps or retaining clips.
• Slide out the old shaft and install the replacement, ensuring clips/end caps are properly secured.

Left side mount

Right side mount

The Center Crisper Rail is an OEM part for Whirlpool refrigerators. It serves as a support for the crisper drawer, helping to guide and stabilize the drawer as it slides in and out.

Symptoms of a bad Center Crisper Rail include:

• Difficulty in sliding the crisper drawer in or out.
• The drawer sagging or not aligning properly when closed.
• Unusual noises or resistance when moving the drawer.

Causes of a bad center crisper rail can include physical damage from overloading the drawer, wear and tear from regular use, or breakage due to brittle plastic and aging components.

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This crisper drawer front replaces the broken face of your refrigerator's produce bin. It restores a secure front wall and easy handhold so the drawer slides smoothly, stays aligned, and keeps items contained. What it does:

• Attaches to the crisper bin to form the front wall and grab point
• Helps the drawer open/close smoothly and remain seated in its tracks
• Replaces a cracked, missing, or warped front that leads to sticking, misalignment, or spills
• Direct replacement for the original front used with this drawer style

• 1 crisper drawer front (pan front)

• Unplug the refrigerator and remove the crisper bin
• Release the old front by disengaging locking tabs or removing screws, as applicable
• Align the new front with the bin and snap/secure it fully; transfer any labels/trim if present
• Reinstall the drawer on the rails and verify smooth travel

This trim piece replaces a worn or damaged decorative trim to restore the appliance's finished appearance and cover edge gaps. It provides a clean, factory-style look so doors and panels sit flush and look complete. What it does:

• Covers and finishes an exposed edge or seam for a neater appearance
• Restores a factory look after panel or door service
• Helps prevent small items from catching on an unfinished edge
• Useful when the original trim is cracked, dented, or missing

• One trim piece

• Designed to snap or fasten into place; verify orientation before seating
• Turn off and unplug the appliance before removing panels or trim to avoid injury
• Retain all mounting hardware; replace hardware only if specified
