Parts for Kitchenaid KRFF507HPS02: Shelf Parts

This front pan is the front half of the outer tub assembly in a washing machine. It forms the watertight front section of the tub that houses and supports the spin basket and seals against the rear tub half.

• Forms the front portion of the outer tub to contain wash water
• Provides mounting and sealing surface for the door boot/bellow
• Supports the spin basket shaft and helps maintain proper alignment
• Wear or damage may cause leaks, rubbing noises, or vibration

• Disconnect power and water before service; use protective gloves
• Removal generally requires taking off the top, front panel, and door boot
• Transfer any seals, clamps, screws, and hardware from the original part
• Inspect and replace the tub gasket/door bellow if worn or damaged

The Shelf-Glas is an OEM part for Whirlpool refrigerators. This glass refrigerator shelf provides storage space within the refrigerator compartment. The shelf is responsible for providing an even, sturdy surface to neatly organize and display items inside the fridge. Its transparent glass construction allows for easy visibility of contents stored on the shelf.

Over time, glass shelves can develop cracks or chips, especially if heavier items are dropped onto the shelf. The glass may also dull or become stained through regular cleaning.

Symptoms of a damaged shelf include:

• Cracks or chips in the glass that could cause cut risks
• Dull, stained, or grimy glass that is difficult to properly clean
• Sagging or uneven shelf surfaces
• Broken shelf clips or mounting hardware

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

This refrigerator crisper pan replaces a damaged or missing produce drawer. It restores smooth sliding access and dedicated storage for fruits and vegetables, keeping spills contained and fresh items organized in the fresh-food compartment.

• Provides a dedicated bin for fruits and vegetables
• Helps contain drips and debris to protect shelves and liners
• Slides on existing rails for easy access to contents
• Common symptoms: cracked or broken bin, warped drawer, broken front lip/tab, won't slide or stay on track, or missing drawer

• Disconnect power and clear the crisper area before handling parts
• Remove the old drawer; clean and inspect the tracks/rails
• Transfer any reusable trim or inserts from the old drawer if applicable
• Align the new pan with the tracks and slide it fully into place

This glass shelf replaces a damaged or missing refrigerator shelf to restore usable storage space and an even load surface. It provides a flat, easy-to-clean surface for food storage and organization. What it does:

• Replaces a broken, cracked or missing refrigerator shelf so you can safely store items.
• Provides a stable, level surface for food containers, deli items and produce.
• Helps maintain organized shelving and prevents items from shifting or tipping.
• Easy-to-clean glass surface resists stains and odors compared with porous shelving.

• Remove all items from the refrigerator compartment and support adjacent shelves before removing the old shelf.
• Slide the shelf out carefully to avoid chipping; lift straight up when reinstalling to seat into shelf supports.
• Handle the glass with care and wear cut-resistant gloves if broken glass is present.
• No electrical disconnection is typically required, but follow your appliance owner's manual for any model-specific instructions.

The Front Panel is an OEM part for Whirlpool refrigerators. This part is the drawer front with the integrated handle.

Causes of a bad drawer front panel include damage from overloading or forcefully slamming drawers. General wear over many cycles of use can also weaken plastic and cause breaks or cracks.

Symptoms of a failing drawer front panel include:

• Handles detaching from panel placement
• Scratches, scuffs or gouges in the surface
• Difficulty sliding drawers open fully
• Improper track engagement or alignment issues

This genuine OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Storage Drawer is an OEM replacement part for Whirlpool refrigerators. It provides customizable organization for items like snack foods, beverages, and condiments inside the refrigerator cabinet. The drawer measures approximately 27"x 20"x 6".

Causes of a bad storage drawer can include broken mounting slides, making it difficult to open or close securely. Overpacking may also cause cracks in the plastic construction over time.

Symptoms of a bad storage drawer include:

• Will not stay fully closed when loaded
• Mounting brackets crack or break off from vibration
• Contents spill out easily due to loose fit

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This tempered glass shelf replaces a cracked, broken or missing refrigerator shelf and restores a stable, easy-to-clean storage surface. It supports food and containers while keeping cold air circulation consistent. What it does:

• Provides a sturdy, flat surface for storing food, containers and deli items
• Replaces chipped, cracked or shattered glass that can cause leaks or instability
• Helps maintain even airflow and organization inside the refrigerator compartment
• Fits into existing shelf supports or rails to restore normal shelf function

• Remove all items from the shelf area before installation
• Wear cut-resistant gloves and handle glass carefully to avoid injury
• Slide into the existing shelf supports/rails; do not force or flex the glass
• If shelf supports are damaged or loose, replace or secure them before use

This tempered glass refrigerator shelf provides a sturdy, easy-to-clean storage surface that helps keep food organized and visible. It replaces a cracked, chipped, or missing shelf to restore safe, level storage space inside the fridge. What it does:

• Provides a flat, stable surface for storing food and containers
• Tempered glass resists everyday impacts and is simple to wipe clean
• Prevents items from falling through wire shelving and helps contain spills
• Restores proper shelf spacing and organization when a shelf is broken or missing

• One (1) tempered glass shelf

• Remove food and any loose shelving or supports before installing
• Handle glass with care and use two hands; wear gloves to protect against cuts
• Slide shelf into the existing shelf supports until it rests securely
• If supports or trim are damaged, replace those components before using the shelf

This rail is a replacement oven rack support that helps guide and stabilize the oven rack for smooth in-and-out movement and correct rack alignment during cooking. It restores proper support when the original rail is bent or worn. What it does:

• Guides the oven rack so cookware slides in and out smoothly
• Keeps the rack properly aligned to prevent tipping or uneven cooking
• Replaces damaged or bent rails that cause rack instability
• Helps maintain safe, predictable rack movement during use

• One rail

• Disconnect power to the appliance before beginning any repair
• Remove oven racks and follow the OEM instructions for rail removal and installation
• Use proper tools and avoid forcing parts; inspect mounting points for damage

This decorative trim piece replaces a damaged or worn exterior trim to restore the appliance's finished appearance and fit. It provides a clean edge and helps cover mounting gaps around the control area. What it does:

• Covers and protects the appliance edge where trim is installed, improving appearance
• Hides gaps between panels and the control area for a finished look
• Replaces cracked, chipped, bent, or missing trim that affects aesthetics
• Prevents sharp or exposed edges that can catch clothing or skin

• Disconnect power (unplug appliance or shut off breaker) before starting any repair
• Typical installation requires removing adjacent screws or clips; have a screwdriver set handy
• Handle edges carefully; trim and surrounding metal can be sharp

This is a replacement mounting plate that secures and supports internal components for proper alignment and stable operation. Restores structural support and helps maintain correct positioning of nearby parts. What it does:

• Provides a stable mounting surface for adjacent components to prevent movement or vibration
• Keeps parts aligned so mechanisms operate smoothly and reliably
• Replaces a damaged, bent, or corroded plate that can cause rattling or misalignment
• Helps maintain proper spacing to protect wiring and connectors from contact or wear

• Disconnect power before beginning any repair to avoid shock or injury
• Installation typically requires basic hand tools; handle edges carefully
• Inspect nearby fasteners, clips, and gaskets and replace if damaged

This is a replacement mounting plate that secures and supports components inside your appliance, restoring proper fit and alignment for safe, reliable operation. It helps maintain correct spacing and attachment where the original plate is worn or damaged. What it does:

• Provides structural support for attached components and panels
• Restores proper alignment to reduce vibration and rattling
• Replaces a cracked, bent, or corroded plate that no longer holds parts securely
• Helps prevent wear on fasteners and adjacent parts by keeping them correctly positioned

• One replacement mounting plate

• High-level replacement only; installation requires basic hand tools and removal of adjacent panels
• Follow manufacturer service instructions for disassembly and reassembly
• Disconnect power (and gas, if applicable) before servicing the appliance
• If fasteners or clips are missing or damaged, replace them with OEM-recommended hardware

The Drawer Slide Rail is an OEM part for Whirlpool refrigerators. It is designed to allow freezer or refrigerator drawers to glide smoothly in and out.

Causes of a bad refrigerator slide rail can be wear and tear over long-term use. Accidental damage from overloading a drawer or rough handling can also prematurely wear out slide rails.

Symptoms of a bad slide rail include:

• A drawer that is stiff, sticks, or binds during operation
• Visible damage or bent parts along the slide rail
• A drawer that no longer fully extends from the refrigerator

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This slide is the replacement drawer rail that supports and guides a range/oven storage drawer for smooth opening and closing. Restores proper alignment so the drawer rides evenly and stays securely in place. What it does:

• Provides a guided track for the appliance's storage/drawer assembly to slide in and out
• Replaces worn, bent, or broken rails that cause sticking, grinding, or misaligned drawers
• Helps prevent the drawer from slipping off its track or falling when opened
• Restores stable, consistent drawer movement and proper closure

• One replacement slide

• Disconnect power to the appliance before beginning any repair to avoid shock or injury
• Remove the drawer and any obstructions; install the slide in the same orientation as the original
• Basic hand tools are typically required; keep fasteners and mounting positions consistent

This is the right-side crisper plate — the shelf panel that supports the crisper drawer and its contents, helping keep produce organized and stable inside the refrigerator. What it does:

• Provides a stable shelf surface for the right crisper/drawer area
• Supports the crisper drawer and helps keep items from falling into lower cavities
• Replaces cracked, chipped, warped or missing right crisper shelf panels
• Restores proper seating and alignment for the crisper drawer on the right side

• Handle carefully during install to avoid chipping or cracking; use gloves if needed
• Slide the crisper drawer out and set aside before positioning the replacement plate

The DRAWER GLIDE is an OEM component specifically designed for bottom-mount Whirlpool refrigerators. It facilitates smooth extension and retraction of refrigerator shelves and drawers.

These heavy-duty glides are engineered to silently and reliably operate over extended use. Proper functionality of the glides is necessary for accessible storage of items placed on shelves and in drawers.

Causes of bad drawer glides can include worn roller bearings, broken plastic clips or guides, or accumulated debris that causes resistance.

Symptoms of a bad Drawer Glide include:

• "Sticking" or binding when pulling shelves out
• Noisy or grinding sounds emanating from glide areas
• Difficulty fully extending shelves or drawers

This part is also compatible with refrigerators from Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, and some Kenmore models.

This is a replacement plate that covers and protects internal components on select Whirlpool appliances, helping keep parts secure and preventing debris from entering service areas. It restores proper fit and appearance to the area it covers. What it does:

• Covers and shields internal components from dust, food debris and moisture
• Helps hold adjacent parts in place for correct appliance operation
• Reduces rattling or vibration caused by loose or missing metal trim
• Restores finished appearance to the appliance where the original plate was damaged or missing

• One replacement plate as shown

• Disconnect power (unplug or shut off circuit breaker) before starting any repair
• Verify plate orientation and fastener locations before fastening; use existing screws if still serviceable
• Wear gloves to protect hands from sharp metal edges during installation

This trim piece restores the finished appearance of your appliance where trim has become cracked, chipped, or missing. It provides a clean, factory look while protecting the exposed edge or opening. What it does:

• Covers and protects an exposed edge or seam for a finished appearance
• Replaces cracked, warped, or otherwise damaged trim that affects looks
• Helps maintain the appliance's original styling and visual fit
• Simple, non-electrical part — no wiring or moving components

• Remove power to the appliance and follow the manufacturer's service instructions before starting.
• Installation typically requires basic hand tools and careful removal of old trim to avoid damaging surrounding surfaces.
• Keep mounting screws or clips from the original trim if re-using; replace only with manufacturer-specified fasteners.

This slide is a direct-fit replacement guide that restores smooth, stable movement for a refrigerator drawer or shelf. It helps the drawer track correctly and prevents binding or uneven operation. What it does:

• Guides and supports a refrigerator drawer or shelf for smooth, controlled opening and closing
• Replaces worn, damaged or missing slide hardware that causes sticking or uneven movement
• Helps maintain correct alignment so the drawer loads and unloads without jamming
• Commonly used when a drawer drops, tilts, or does not track properly

• One replacement slide

• High-level installation: remove the drawer or shelf, unfasten the old slide, and install the new slide using existing mounting holes and hardware
• Inspect mating tracks and mounting points for damage; clean debris before installing
• Use proper tools and avoid overtightening fasteners to prevent cracking the slide or mounting bosses
• Disconnect power only if required by your appliance model; follow all manufacturer safety instructions

This replacement support is a mounting bracket that helps secure and stabilize a major appliance assembly, restoring proper alignment and reducing vibration or movement. It fits into the OEM assembly to keep panels and components supported. What it does

• Holds and supports a panel or internal component to prevent sagging and misalignment
• Reduces rattling, vibration and contact-related noises caused by loose supports
• Restores proper alignment so doors, panels or assemblies sit and operate correctly
• Helps maintain safe, stable operation by keeping parts secured in their intended position

• Disconnect power and water (if applicable) before starting any repair
• Use basic hand tools; follow the OEM diagram for correct orientation and fastener locations
• Inspect adjoining parts (fasteners, clips, mounting points) and replace any that are worn

A small mounting screw used to secure appliance panels and components. This genuine replacement restores proper fit and reduces vibration or loose parts when a missing or stripped fastener causes fit issues. What it does:

• Secures panels, trim, or internal components to the appliance frame
• Helps stop rattling or movement caused by a missing or loose screw
• Restores correct alignment where a fastener is lost or damaged
• Works as a direct-fit replacement when the original screw is worn or stripped

• The screw shown/listed

• Disconnect power (and gas if applicable) before any repair
• Use the matching screwdriver or driver bit to avoid stripping the head
• Thread carefully and avoid overtightening to prevent damage
• Keep small parts away from children and store removed hardware for reference

This genuine replacement glass shelf restores stable storage and organization inside the refrigerator. It provides a flat, easy-to-clean surface for holding food containers and keeps items from shifting. What it does:

• Replaces a cracked, chipped, or missing refrigerator shelf so you can safely store items again
• Provides a sturdy, flat surface for plates, containers and small appliances
• Helps contain minor spills for easier cleanup
• Restores proper spacing and organization inside shelving compartments

• Remove food and carefully lift out broken shelf; wear cut-resistant gloves if glass is damaged
• Align shelf with existing support rails or brackets and set into place gently
• Do not force or flex the glass; ensure it is fully seated on the supports before loading
• Clean with mild soap and avoid abrasive cleaners to preserve finish

This pantry top cover is the molded interior trim piece that fits above the refrigerator pantry/produce area, restoring a finished look and protecting the pantry opening from wear and debris. It replaces cracked, warped or missing covers. What it does:

• Covers the top of the pantry/produce opening to keep the interior tidy and prevent items from catching on exposed edges
• Restores proper interior trim and appearance after damage or loss
• Helps maintain proper airflow pattern in the pantry area by replacing a missing or damaged cover
• Common symptom: cover is cracked, broken, loose or missing, leaving the pantry edge exposed

• High-level snap-in or screw-in installation; verify fasteners before reassembly
• Remove food and close the door while working; handle gently to avoid scratching the finish
• Unplug or disconnect power to the appliance only if required by your model before accessing internal components

This housing is a factory-style replacement cabinet bulkhead that supports internal components and helps seal the appliance cabinet for reliable operation. It restores proper alignment and reduces airflow leaks and vibration. What it does

• Provides a secure mounting surface for internal components and assemblies
• Helps seal and channel airflow to maintain performance
• Reduces vibration and rattling caused by warped or damaged cabinet areas
• Can stop air or water leaks that originate at the cabinet opening

• One replacement housing as shown

• Disconnect power (and water, if applicable) before starting service
• Handle carefully — edges may be sharp and mounting tabs can be brittle on older units
• Typical installation requires basic hand tools; retain original fasteners when possible
• Verify alignment of attached components and seals during reassembly

This replacement door shelf bin mounts on the refrigerator door to hold condiments, bottles, and small items. Replacing a cracked or missing bin restores secure door storage and helps keep contents organized and easy to reach.

• Provides a stable storage shelf on the fresh-food door
• Replaces bins with cracks, broken tabs, or that won't stay attached
• Helps prevent tipping or spills when opening/closing the door
• Restores original door storage capacity and organization

• Compare to your original to confirm the correct door position
• Engage lower hooks in the door liner slots, then rotate up until top tabs snap in
• Ensure the bin is fully seated before loading; avoid overloading with heavy items
• Transfer any removable dividers or mats from the old bin if your model uses them
