Parts for Kitchenaid KRFF507HPS02: Refrigerator Door Parts

This service door provides a replacement access panel that restores safe, convenient access to internal components for service and maintenance. It helps technicians reach controls and wiring without removing major panels. What it does:

• Replaces a cracked, broken, or missing access panel that prevents safe access to internal parts
• Restores a secure cover for control or service openings to help keep wiring and components protected
• Allows technicians to reach controls, connectors, and components for diagnostics and repairs
• Helps stop drafts or debris from entering through service openings

• Always disconnect power (unplug or shut off breaker) before starting work
• Basic hand tools are typically required; follow the correct procedure
• Handle edges carefully to avoid cuts; wear gloves if needed

This factory screw fastens appliance components securely. Replacing a missing, stripped, or rusty screw helps stop rattles, keep panels and brackets aligned, and restore a solid, as-designed fit.

• Secures panels, brackets, and trim to the appliance cabinet or frame
• Helps maintain alignment and reduce vibration or rattling noises
• Replaces damaged, corroded, or missing hardware
• Can resolve loose or shifting components

• Disconnect power and shut off gas/water to the appliance before service.
• Use the correct driver; start threads by hand to avoid cross-threading and do not overtighten.
• Install in the original location and match the OEM fastener type specified in your model's parts diagram.

Left Hand Closer

Right Hand Closer

This is the refrigerator door mullion, also called the flipper rail. It creates the vertical center seal between the fresh food doors, helping reduce air leaks and condensation so the doors close smoothly and temperatures stay consistent. What it does:

• Swings with the left door to cover the gap between the French doors and seal against the opposing gasket
• Helps minimize warm air infiltration, condensation, and frost at the center post
• Restores proper door closure when the original rail is cracked, bent, or has a failed hinge/spring
• Common symptoms: loose or dangling center rail, doors popping back open, moisture/sweating at the center, visible cracks or broken tabs

• One door mullion (flipper rail) assembly

• Unplug the refrigerator before servicing; turn off water supply if lines run through the door
• Work with the doors supported to avoid misalignment or damage
• Transfer and align the rail on the upper and lower pivots, then secure with existing fasteners
• After installation, the rail flips freely and the doors seal and latch properly

This door bumper cushions and stabilizes the appliance door to reduce noise and wear from slamming. It helps the door close smoothly and maintain proper alignment for reliable operation. What it does:

• Absorbs impact to prevent metal-on-metal contact and reduce slamming noise
• Helps the door sit evenly to improve latch engagement and sealing
• Reduces vibration and rattling during operation
• Simple replacement that restores proper door feel and alignment

• Disconnect power to the appliance before starting any repair
• Access the bumper by opening the door; some models may require removing the door or inner panel
• Press or snap the bumper into the locating hole or slot until secure; replace any retaining clips if present

This door bumper cushions the door against the frame to prevent metal-to-metal contact. Replacing a worn or missing bumper restores smooth, quieter closing and helps protect surfaces from chips, scuffs, and vibration.

• Absorbs impact where the door meets the cabinet/frame
• Reduces slamming noise and vibration during closing
• Helps protect paint, glass, and trim from wear
• Typical symptoms: missing/cracked bumper, loud clunk when closing, marks on frame, rattling

• Disconnect power and, if applicable, shut off gas/water; allow hot surfaces to cool
• Open the door to access the bumper location
• Remove the worn bumper and clean the contact area for proper seating
• Install the new bumper fully seated and aligned; test door operation

This replacement screw fastens appliance panels and components securely. Replace a missing, stripped, or corroded original to restore a tight fit and help prevent rattling, vibration, and gradual loosening of assemblies.

• Secures panels, brackets, and internal assemblies to the frame
• Replaces damaged or missing hardware to maintain proper fit
• Helps reduce vibration, noise, and movement caused by loose parts
• Supports correct alignment at the original mounting points

• Disconnect power and shut off water or gas before service.
• Match the original screw's location and length; replace one at a time if needed.
• Use the correct driver/bit and avoid overtightening to prevent stripping plastic or metal.
• Reuse any washers or clips only if in good condition.

The Door Shelf Bin is an OEM part for Whirlpool refrigerators. It is a removable shelf that stores various items inside the refrigerator door.

Symptoms of a bad Door Shelf Bin include:

• Cracks or weaknesses in the plastic that can lead to breakage
• Difficulty removing or replacing the shelf securely in the door frame
• Items falling through or off of a shelf with sagging or missing supports

Causes of a bad Door Shelf Bin can be normal wear and tear over time from frequent use, excessive weight loads, or damages incurred from improper cleaning chemicals or methods.

This OEM replacement part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore refrigerators.

A small replacement pin that secures the flipper emitter assembly, restoring correct movement and alignment so the flipper can engage and operate reliably. Ideal when the original pin is bent, worn, or missing. What it does:

• Holds the flipper emitter or lever in place so the mechanism can pivot correctly
• Restores proper movement when a loose or broken pin causes misalignment
• Helps stop clicking, scraping, or intermittent operation related to a damaged fastener
• Serves as a direct-fit replacement designed for the OEM emitter/lever assembly

• One replacement pin as shown

• Disconnect power to the appliance before beginning any repair
• Handle small parts carefully; keep screws and pins organized during disassembly
• Use basic hand tools; no special tools or adhesives are typically required

6 - 19 x .250

This gasket seals the ice compartment door to help maintain proper cold temperatures and reduce frost or moisture buildup inside the ice storage area. A worn seal can let warm air in and harm ice quality. What it does:

• Seals the ice compartment door to help keep ice cold and dry
• Helps reduce frost buildup and excess condensation inside the compartment
• Can improve cooling consistency and reduce strain on the refrigerator
• Common symptom fix: visible gaps, torn or compressed seal, frost or melting in the ice area

• One ice compartment door gasket

• Clean the door surface and channel before installing to ensure a proper seal
• Press the gasket into the door channel evenly, working around the perimeter for a uniform fit
• If needed, loosen or remove the door per the manufacturer's instructions for easier access
• Avoid sharp tools that could damage the gasket; check the seal after installation and allow time for it to fully seat

This drain tube clip secures the washer's drain hose or tube to the cabinet or pump assembly to help keep the hose positioned and reduce the chance of leaks or kinks. It's a simple replacement for a broken or missing retainer. What it does

• Holds the drain tube or hose firmly in place to prevent it from slipping free
• Helps maintain proper tube routing to reduce kinks that can restrict drainage
• Reduces water dripping or pooling caused by a loose or detached tube
• Useful when a damaged or brittle clip no longer secures the drain line

• Always unplug the appliance and turn off water supply before starting repairs
• Locate the damaged or missing clip on the drain tube near the cabinet or pump and remove any obstructing panels as needed
• Snap the new clip onto the tube and into the mounting slot until it seats securely; use a small screwdriver if required for removal only
• Check for proper hose routing and test a short cycle to verify no leaks

This flipper spring returns the refrigerator's ice dispenser door (chute flapper) to the closed position after dispensing. It helps keep warm air and moisture out to minimize frost at the chute and reduce ice clumping in the bin.

• Provides the closing tension for the ice chute door/flapper
• Helps maintain a proper seal at the dispenser opening
• If worn or broken, you may notice the flapper not closing fully
• Frost/condensation around the chute or ice clumping in the bucket may occur

• Disconnect power to the refrigerator before servicing
• Remove dispenser trim/control to access the ice chute door assembly; note spring orientation and anchor points
• Install the new spring in the same orientation; the flapper moves freely and closes under spring tension
• Wear gloves and use caution—metal edges in the dispenser area can be sharp

This replacement cover is a molded housing piece that protects internal components and restores the appliance's exterior appearance. It keeps wiring and controls shielded while helping reduce noise and debris entry. What it does:

• Protects internal components and wiring from physical damage and contamination
• Helps reduce vibration noise and rattling by covering exposed parts
• Restores a finished appearance to the appliance cabinet or control area
• Can prevent loose parts from shifting during operation

• Disconnect power (unplug appliance or switch off breaker) before beginning service
• Use basic hand tools; support the appliance panel while removing fasteners
• Handle with care to avoid scratching painted surfaces or breaking tabs

This slide is the replacement rack glide that helps a rack roll smoothly in and out of the appliance, restoring proper rack movement and preventing scraping or sticking during use. Fits where the factory rack glide has worn or broken. What it does

• Provides a smooth track for a rack to slide in and out without binding
• Replaces cracked, worn or missing glide that causes rubbing or uneven movement
• Helps keep the rack properly aligned during loading and unloading
• Reduces noise and drag from a damaged or missing glide

• One replacement slide/rack glide

• Remove power supply or disconnect appliance before starting any repair
• Access the glide by sliding the rack out and removing any retainer clips or screws as required
• Snap or screw the replacement slide into place and verify smooth rack movement before restoring power
• If other rack parts are damaged, replace them to ensure proper function

The Ice Level Control Board is an OEM part for Whirlpool refrigerators. This board manages the ice maker’s production by monitoring the ice level in the ice bin, ensuring that ice is made when needed and halting production when the bin is full.

Causes of a bad ice level control board can include electrical issues such as power surges, wear and tear over time, or damage from moisture or debris.

Symptoms of a bad ice level control board include:

• The ice maker not producing ice
• Continuous ice production even when the bin is full
• Error codes related to the ice maker
• Irregular or inconsistent ice production

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

This replacement retainer secures the ice chute door assembly inside the dispenser, helping maintain a proper seal and smooth ice dispensing. Use it to restore alignment and reduce frost or dripping at the dispenser opening.

• Secures the ice chute/flapper assembly within the dispenser housing
• Helps keep the chute sealed to minimize warm air entering the freezer
• Replace if the chute door is loose, misaligned, or won't stay closed
• Common symptoms include frost/ice buildup at the chute, ice not dispensing smoothly, or visible damage to the retainer

• Unplug the refrigerator and shut off the water supply before servicing
• Remove the dispenser front/escutcheon to access the chute; note part orientation
• Transfer any reusable hardware and seat the new retainer fully
• Restore power and test ice dispensing and chute door sealing

This ice dispenser chute gasket seals the opening at the freezer door's ice chute, helping block warm, humid air from entering. A proper seal reduces frost and moisture around the dispenser and helps keep ice from clumping near the chute.

• Seals the gap between the ice door/flapper and chute to limit air leaks
• Helps minimize frost, condensation, and ice buildup in the dispenser area
• Replaces a torn, flattened, or missing gasket that prevents a tight seal

• Disconnect power to the refrigerator before servicing
• Remove the dispenser front panel/escutcheon to access the ice door and chute area
• Remove the old gasket, clean the mating surfaces, and seat the new gasket evenly all around
• Ensure the ice door/flapper moves freely and seals uniformly before reassembly

This vent directs and protects an appliance's exhaust, helping airflow move from the appliance to the ductwork for safe, efficient venting. It replaces a worn or damaged exhaust outlet to restore proper ventilation. What it does:

• Provides the finished outlet for appliance exhaust, guiding airflow into the duct system
• Helps reduce backflow and air leakage when properly installed
• Prevents larger debris and physical damage at the exhaust opening
• Can correct symptoms like reduced venting efficiency, unusual airflow, or visible damage at the vent opening

• One vent outlet piece

• Disconnect power (and gas if applicable) before servicing the appliance
• Use basic hand tools; avoid over-tightening fasteners that could distort the part
• If ductwork shows heavy lint, corrosion, or damage, repair or replace ducting for best results

A replacement bin control lever for the refrigerator door shelf that restores secure bin engagement and smooth opening/closing. Fits into the door shelf mechanism to help keep bins locked in place during use. What it does:

• Replaces a worn or broken lever that secures the door shelf/bin to the door rail
• Helps stop bins from popping out or not latching properly when opening the door
• Restores normal bin release action and tactile engagement
• Commonly replaced when lever is cracked, loose, or missing

• One replacement bin control lever

• Basic snap-in or screw-in replacement; remove bin or inner door trim as needed for access
• Turn off power or keep door closed/stable per manufacturer safety guidance before servicing
• Use hand tools; avoid forcing plastic tabs to prevent breakage

Color: Black

Color: Grey

This is the replacement ice door that opens and closes inside the refrigerator dispenser to let ice through and help keep warm air out. Keeps the ice chute sealed when not dispensing to reduce frost and maintain cooling. What it does:

• Covers the ice chute and opens to allow ice to dispense.
• Helps prevent warm air and moisture from entering the freezer through the dispenser.
• Commonly used when the dispenser door is cracked, broken, or won't latch.
• Can resolve symptoms such as ice not dispensing smoothly, a stuck door, or visible damage to the dispenser opening.

• One replacement ice door

• Disconnect power to the refrigerator before beginning any repair.
• Remove dispenser bezel/inner door panel as needed to access and replace the ice door; follow your model's service instructions.
• Handle plastic parts carefully to avoid cracking; verify proper alignment so the door seals and operates freely.
