Parts for Kenmore 253.23114100 (25323114100, 253 23114100): System Parts

Includes service line.

This main wiring harness routes power and signal connections between the refrigerator control board and key components, restoring electrical continuity for proper appliance operation. What it does:

• Delivers power and control signals to components like compressors, fans, lights and ice systems
• Replaces damaged or frayed wiring that can cause intermittent operation or component failure
• Helps resolve symptoms such as loss of lights, fans not running, ice maker not cycling, or no cooling when due to wiring faults
• Preserves factory connector interfaces for a plug-and-play replacement when the harness is an exact match

• One main wiring harness as specified

• Disconnect power to the appliance before beginning any work
• Handle connectors by the housings; avoid pulling on wires to prevent damage
• Route and secure the harness following factory clips and channels; do not cut or splice unless explicitly instructed by a service manual

Replacement shelf support bracket for freezers. Secures and stabilizes freezer shelves. Replace if broken, cracked, or missing due to heavy loads or age.

The Support-Shelf is an OEM part for Frigidaire freezers, designed to provide sturdy and reliable support for the freezer shelves. This part ensures that the shelves remain level and secure under the weight of stored items.

Causes of a bad Support-Shelf can range from overloading shelves beyond their weight capacity, to normal wear and tear from years of use.

Symptoms of a bad Support-Shelf include:

• Shelves sagging or not sitting level, which can lead to inefficient storage and the risk of items falling.
• Cracks or breaks in the support, compromising the stability of the entire shelving system.
• Difficulty installing or removing shelves, indicating that the supports may be damaged or misshapen.

This OEM Frigidaire part is also compatible with Electrolux, Gibson, Kelvinator and some Kenmore models.

Replacement spacer for the front of the top grid in your freezer. Needed when original spacer is cracked, broken, or missing to properly support shelf.

Mounting screw that secures the top grid assembly inside your refrigerator. Replace if the original screw is stripped, missing, or damaged during maintenance.

Rubber mounting grommet that cushions and isolates the compressor from the chassis. Replace if cracked, worn, or missing to restore proper support.

Refrigerator not cooling or compressor won't start? This compressor kit with electrical components restores cooling. Requires HVAC certification.

This kit includes the start relay and overload protector that help the compressor motor start and run properly. The relay provides the initial electrical boost to get the compressor running, while the overload protector shuts it off if it draws too much current or overheats. Replace this kit if the refrigerator or freezer is not cooling, the compressor clicks on and off repeatedly, or you hear a buzzing sound coming from the back of the unit.

Secures interior trim and panels in your refrigerator. Replace when trim becomes loose or rattles. Verify fit with your model number before ordering.

Compressor vibrating or loose? This mounting screw secures the compressor in freezers and refrigerators. Simple fix, basic tools required.

Freezer won't start or compressor hums but doesn't run? A failed run capacitor is often the cause. DIY-friendly repair, typically done in under an hour.
