Parts for Jenn-Air CCG2423S: 02 - Top Assembly Parts

This small pan seal replaces a worn or damaged sump/pan gasket to help stop leaks and keep water inside the appliance's drain area. It restores a proper seal so the appliance can drain without pooling or seepage. What it does:

• Seals the small pan/sump area to prevent water from leaking onto the floor
• Helps maintain proper drainage and reduces pooling under the appliance
• Restores a tight gasket where cracks, compressions, or wear allow seepage
• Commonly used when you see water under the unit, drips after cycles, or visible gasket damage

• Disconnect power and water supply before servicing the appliance
• Remove access panels and clean the mating surfaces before installing the new seal
• Press the seal into place evenly; ensure it sits flush in the pan/sump channel
• Inspect surrounding parts for damage and replace any brittle or warped components

A flexible pan seal that helps keep the refrigerator's drain pan and base area sealed to reduce leaks and contain condensation. Replaces a worn or damaged gasket to help prevent water pooling and odors. What it does:

• Seals the drain/condensate pan to the cabinet base to limit water leaks and vapor escape
• Directs condensate toward the drain so water drains properly instead of pooling
• Helps reduce musty odors from standing water in the pan area
• Commonly replaced when you see water under the appliance, pooling inside the cabinet, or visible gasket damage

• Disconnect power to the appliance before beginning any repair
• Remove the appropriate access panels or kickplate to reach the pan area per your model's service instructions
• Clean the pan and mating surfaces thoroughly before installing the new seal for a proper fit
• Press the seal into place; do not force or use solvents/adhesives unless specified by the OEM

This grommet sits in the control panel opening around the valve/switch shaft on select ranges and cooktops. It helps seal out spills and stabilizes the control knob for a clean look and smooth operation.

• Seals the knob/shaft hole to help keep moisture, grease, and crumbs out of the control area
• Centers and supports the knob for a snug, stable feel
• Helps prevent rubbing and cosmetic wear around the panel opening
• Common signs: cracked or missing grommet, visible gap around knob, loose/wobbly knob, evidence of spills beneath the knob

• Disconnect power and, if applicable, shut off gas supply before servicing
• Pull the knob straight off the shaft and lift out the old grommet
• Clean the panel opening; press the new grommet fully into place, matching the original orientation
• Reinstall the knob and ensure smooth, unobstructed operation

Color: black. It measures about 2 inches in diameter.

This venturi mixing tube channels and meters incoming air to the gas burner assembly to support proper combustion. Replacing a worn or damaged venturi restores consistent air/gas mixing for safer, more reliable burner performance. What it does

• Directs and mixes incoming air with gas for stable burner combustion
• Restores proper burner operation when airflow is restricted or misdirected
• Can correct weak, uneven, or inconsistent burner flames linked to venturi damage
• Helps eliminate issues caused by cracked, clogged, or misshapen venturi passages

• Shut off electrical power and gas supply before beginning any service
• Inspect adjoining seals, gaskets, and mounting points; replace any damaged hardware
• After installation, check burner operation and test for gas leaks using a safe, approved method

This oven igniter is the glow-bar that lights the gas for the bake or broil burner. Replacing a weak or failed igniter restores dependable ignition and consistent oven heat, solving no-heat and long preheat complaints.

• Heats to ignite the gas burner in the oven cavity
• Draws the proper current to open the oven safety valve
• Common symptoms: oven won't heat, igniter glows but no flame, delayed or intermittent ignition, extended preheat times
• Restores reliable burner lighting for baking or broiling

• Disconnect power and shut off gas supply before servicing; allow the oven to cool
• Handle the igniter by the insulated base; avoid touching the fragile element
• Mount using the correct bracket and position the tip near the burner, as on the original
• Restore power and gas, then test for prompt, steady ignition

A replacement hex nut used to secure appliance components and fasten assemblies. This small but essential fastener restores proper clamping force and helps stop loose or rattling parts for safe, reliable operation. What it does

• Secures mating parts and threaded studs to hold assemblies in place
• Restores proper tension where a missing or stripped nut allows movement
• Helps eliminate rattling, vibration, or intermittent contact caused by loose hardware
• Works where a standard hex nut is specified by the manufacturer

• One hex nut

• Turn off and unplug the appliance before attempting any repair
• Use the correct socket or wrench to avoid rounding the nut; apply moderate torque
• Replace any damaged studs or washers and use thread locker only if specified by the manufacturer
