Parts for Ge JK3500DF2BB: Upper Door Parts

This inner refrigerator door panel replaces a damaged or worn door liner to restore a clean interior surface and proper bin mounting. Fits select GE refrigerators and helps maintain organized storage and proper door function. What it does:

• Replaces a cracked, warped, or stained inner door panel to restore interior appearance
• Provides mounting surface for door bins, shelves, and hardware
• Helps ensure a proper seal and consistent cooling by restoring the door's structural fit
• Reduces rattles or movement from a loose or broken liner

• Intended for experienced DIYers; follow manufacturer instructions
• Power down the refrigerator and remove food from the door before beginning
• Use appropriate hand tools; avoid overtightening fasteners which can crack the liner
• Inspect door bins and fasteners during reassembly; replace any damaged clips or screws as needed

A replacement liner support that secures the refrigerator cabinet liner and keeps interior trim and panels aligned for a proper seal and appearance. Restores stability to cracked or broken support points. What it does:

• Holds the cabinet liner and interior trim in position to prevent gaps and movement
• Helps maintain door seal alignment by keeping liner edges stable
• Reduces rattling or shifting caused by a damaged support
• Commonly replaced when liner pieces are cracked, broken, or loose

• One liner support

• Disconnect power to the appliance before beginning any repair
• Remove food, shelves, and trim pieces as needed to access the damaged support
• This part typically secures with clips or fasteners; inspect existing hardware and replace if necessary

The Oven Door Gasket is an OEM replacement part for GE electric ranges. As the seal that lines the edges of the oven door, the gasket plays a crucial role in insulating the oven cavity from heat loss.

Causes of a bad gasket can include dry-rot, warping, or compression from repeated door closing over time. Exposure to cleaning chemicals or high-heat cooking accelerates degradation.

Symptoms of a bad oven door gasket include:

• Inefficient or uneven baking/cooking results
• Increased energy costs due to heat escaping
• A loud squeaking or squealing sound when opening/closing the door
• Visible cracks, splits, or fraying along the gasket edges

 This OEM GE part is also compatible with Hotpoint, RCA, and select Kenmore electric ranges.

This outer door glass and trim assembly replaces the front glass panel on compatible ovens and restores the door's appearance and protective surface. It provides a finished exterior and helps maintain proper insulation and safety. What it does

• Replaces cracked, chipped or shattered outer door glass that affects appearance and safety
• Helps keep heat inside the oven by restoring the door's exterior barrier
• Eliminates rattling or loose trim caused by damaged glass or clips
• Restores a smooth, clean outer surface for easier cleaning and use

• Disconnect power to the appliance before starting any repair and allow the oven to cool completely.
• Handle glass carefully and wear cut-resistant gloves and eye protection.
• Door disassembly is typically required; use proper tools and keep track of fasteners.
• Secure all clips/fasteners before returning the appliance to service.

This handle support mount kit secures and reinforces an appliance door handle so it stays aligned and stable during normal use. It replaces worn or broken handle supports to restore proper handle fit and function. What it does:

• Provides the mounting point and hardware to secure a door or panel handle
• Stops handle wobble, looseness, or sag caused by worn supports or damaged mounts
• Restores correct handle alignment for safe, reliable operation
• Works as the replacement support when the original mounting has cracked or failed

• Disconnect power (or unplug) and remove any panels before starting
• Use basic hand tools (screwdriver/socket) and avoid over-tightening fasteners to prevent damage
• Handle replacement may require holding the handle in position while securing the support

This glass panel forms the viewing window in your oven door. Replace a cracked or cloudy pane to restore safe visibility and help maintain proper heat retention—without replacing the entire door assembly.

• Forms the clear viewing window in the oven door
• Helps retain heat and maintain consistent cooking temperatures
• Allows you to monitor food without opening the door
• Replace if the pane is cracked, shattered, chipped, or permanently stained/cloudy

• Disconnect power and let the oven cool completely
• Remove the door and place it face-down on a padded surface for access
• Wear cut-resistant gloves and eye protection; handle glass carefully to avoid injury
• Track screw locations, note pane order/orientation in multi-glass doors, and tighten fasteners evenly without overtightening

ST10-16 X 7/16"

Black. 8-18 AB HXW 3/8

Includes 12 washers.

This handle support mount kit secures and reinforces an appliance door handle so it stays aligned and stable during normal use. It replaces worn or broken handle supports to restore proper handle fit and function. What it does:

• Provides the mounting point and hardware to secure a door or panel handle
• Stops handle wobble, looseness, or sag caused by worn supports or damaged mounts
• Restores correct handle alignment for safe, reliable operation
• Works as the replacement support when the original mounting has cracked or failed

• Disconnect power (or unplug) and remove any panels before starting
• Use basic hand tools (screwdriver/socket) and avoid over-tightening fasteners to prevent damage
• Handle replacement may require holding the handle in position while securing the support

This 10-32 machine screw secures brackets, panels, and other hardware in cooking appliances. Replacing a missing or stripped screw restores a snug, rattle-free fit and keeps components aligned and safely fastened. What it does:

• Fastens panels, brackets, and components using a 10-32 machine thread
• Replaces hardware that is missing, rusted, or stripped
• Helps address loose or rattling parts and minor panel misalignment
• Maintains secure mounting after service or part replacement

• One 10-32 machine screw

• Disconnect power; for gas appliances, also shut off gas before service
• Support the panel or bracket while removing/installing hardware
• Start threads by hand to avoid cross-threading; do not overtighten
• Replace them one at a time to keep alignment
