Parts for Ge PK7500SF2SS: Upper Door Parts

Replacement badge designed to restore the appliance's exterior appearance and factory look. This decorative emblem replaces a faded, scratched, or missing badge so the control panel or door presents a clean, branded finish. What it does:

• Replaces a worn, cracked, faded, or missing badge to restore original appearance
• Sits on the appliance front where the original emblem was located for accurate visual match
• Helps maintain a factory-fresh look after cosmetic damage or panel repair
• Sold as the individual decorative emblem; intended as a direct-fit cosmetic replacement

• Clean and fully dry the mounting area before installing to ensure proper adhesion and fit
• Align carefully with the original location; press firmly and evenly to secure the badge

This inner refrigerator door panel replaces a damaged or worn door liner to restore a clean interior surface and proper bin mounting. Fits select GE refrigerators and helps maintain organized storage and proper door function. What it does:

• Replaces a cracked, warped, or stained inner door panel to restore interior appearance
• Provides mounting surface for door bins, shelves, and hardware
• Helps ensure a proper seal and consistent cooling by restoring the door's structural fit
• Reduces rattles or movement from a loose or broken liner

• Intended for experienced DIYers; follow manufacturer instructions
• Power down the refrigerator and remove food from the door before beginning
• Use appropriate hand tools; avoid overtightening fasteners which can crack the liner
• Inspect door bins and fasteners during reassembly; replace any damaged clips or screws as needed

A replacement liner support that secures the refrigerator cabinet liner and keeps interior trim and panels aligned for a proper seal and appearance. Restores stability to cracked or broken support points. What it does:

• Holds the cabinet liner and interior trim in position to prevent gaps and movement
• Helps maintain door seal alignment by keeping liner edges stable
• Reduces rattling or shifting caused by a damaged support
• Commonly replaced when liner pieces are cracked, broken, or loose

• One liner support

• Disconnect power to the appliance before beginning any repair
• Remove food, shelves, and trim pieces as needed to access the damaged support
• This part typically secures with clips or fasteners; inspect existing hardware and replace if necessary

The Oven Door Gasket is an OEM replacement part for GE electric ranges. As the seal that lines the edges of the oven door, the gasket plays a crucial role in insulating the oven cavity from heat loss.

Causes of a bad gasket can include dry-rot, warping, or compression from repeated door closing over time. Exposure to cleaning chemicals or high-heat cooking accelerates degradation.

Symptoms of a bad oven door gasket include:

• Inefficient or uneven baking/cooking results
• Increased energy costs due to heat escaping
• A loud squeaking or squealing sound when opening/closing the door
• Visible cracks, splits, or fraying along the gasket edges

 This OEM GE part is also compatible with Hotpoint, RCA, and select Kenmore electric ranges.

The Door Handle and End Cap Assembly is an OEM part for GE ranges and wall ovens. It serves as the central component used for accessing the oven cavity and grill cavity. This assembly consists of the handle pulled to open and close the oven door along with end caps protecting the hinges and lock mechanism.

Symptoms of a bad door handle and end cap assembly include:

• Loose or wobbly door handle that is difficult to grip
• Misalignment of the door that prevents proper closing or sealing
• End caps that are cracked, broken, or missing exposing internal parts
• Destabilization of the entire door that puts undue stress on the hinges
• Causes of failure can be regular wear and tear over years of usage as well as stresses from repeated opening/closing of a heavy range door.

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This outer oven door glass with trim restores the exterior glass panel that protects the oven cavity and improves the door's appearance. It replaces cracked, scratched, or missing outer glass to help contain heat and restore a finished look. What it does:

• Replaces the exterior glass panel that covers the oven door and trim assembly
• Helps contain heat and provides the smooth, finished outer surface of the door
• Addresses visible damage such as cracks, chips, scratches, or warped trim
• Restores proper sealing surface and appearance after impact or wear

• Disconnect power (or unplug) and allow the oven to fully cool before starting work
• Handle glass carefully and wear cut-resistant gloves and eye protection
• Typical installation requires removing the door and separating door layers; follow OEM instructions or service manual

This handle support mount kit secures and reinforces an appliance door handle so it stays aligned and stable during normal use. It replaces worn or broken handle supports to restore proper handle fit and function. What it does:

• Provides the mounting point and hardware to secure a door or panel handle
• Stops handle wobble, looseness, or sag caused by worn supports or damaged mounts
• Restores correct handle alignment for safe, reliable operation
• Works as the replacement support when the original mounting has cracked or failed

• Disconnect power (or unplug) and remove any panels before starting
• Use basic hand tools (screwdriver/socket) and avoid over-tightening fasteners to prevent damage
• Handle replacement may require holding the handle in position while securing the support

This glass panel forms the viewing window in your oven door. Replace a cracked or cloudy pane to restore safe visibility and help maintain proper heat retention—without replacing the entire door assembly.

• Forms the clear viewing window in the oven door
• Helps retain heat and maintain consistent cooking temperatures
• Allows you to monitor food without opening the door
• Replace if the pane is cracked, shattered, chipped, or permanently stained/cloudy

• Disconnect power and let the oven cool completely
• Remove the door and place it face-down on a padded surface for access
• Wear cut-resistant gloves and eye protection; handle glass carefully to avoid injury
• Track screw locations, note pane order/orientation in multi-glass doors, and tighten fasteners evenly without overtightening

ST10-16 X 7/16"

Black. 8-18 AB HXW 3/8

Includes 12 washers.

This handle support mount kit secures and reinforces an appliance door handle so it stays aligned and stable during normal use. It replaces worn or broken handle supports to restore proper handle fit and function. What it does:

• Provides the mounting point and hardware to secure a door or panel handle
• Stops handle wobble, looseness, or sag caused by worn supports or damaged mounts
• Restores correct handle alignment for safe, reliable operation
• Works as the replacement support when the original mounting has cracked or failed

• Disconnect power (or unplug) and remove any panels before starting
• Use basic hand tools (screwdriver/socket) and avoid over-tightening fasteners to prevent damage
• Handle replacement may require holding the handle in position while securing the support

This hex-head machine screw has a 10-32 thread and measures 1-3/4 inches long. Use it to replace a missing, stripped, or rusted fastener and restore a secure fit where this exact size is specified.

• Secures brackets, panels, and internal components requiring a 10-32 x 1-3/4 in hex-head screw
• Restores proper alignment and mounting integrity
• Replaces damaged, corroded, or lost hardware
• Can help resolve symptoms like loose/rattling parts or shifting components

• Disconnect power (and shut off gas, if applicable) before servicing; allow appliance to cool
• Remove the old screw, align parts, and start the new screw by hand to avoid cross-threading
• Tighten snugly but do not overtighten
• Reuse any original washers or spacers if present

This 10-32 machine screw secures brackets, panels, and other hardware in cooking appliances. Replacing a missing or stripped screw restores a snug, rattle-free fit and keeps components aligned and safely fastened. What it does:

• Fastens panels, brackets, and components using a 10-32 machine thread
• Replaces hardware that is missing, rusted, or stripped
• Helps address loose or rattling parts and minor panel misalignment
• Maintains secure mounting after service or part replacement

• One 10-32 machine screw

• Disconnect power; for gas appliances, also shut off gas before service
• Support the panel or bracket while removing/installing hardware
• Start threads by hand to avoid cross-threading; do not overtighten
• Replace them one at a time to keep alignment
