Parts for Frigidaire GCWD2767ADD: Upper Oven Parts

This rack assembly replaces a damaged or worn dishwasher rack to securely hold dishes during wash cycles and restore proper loading and drainage. Designed to match the original equipment fit and function. What it does:

• Provides a complete dish-holding framework so plates, bowls and glasses sit securely during cycles
• Replaces bent, rusted or collapsed rack wires that can scrape dishes or block spray arms
• Restores proper rack movement and alignment so drawers and rollers operate smoothly
• Helps prevent items from shifting and reduces the risk of chips and breaks during washing

• Remove dishes and disconnect power to the appliance before starting work
• Remove the old rack by sliding out the rail assembly or detaching fasteners per your model's service instructions
• Inspect rollers, rails and mounting clips; replace damaged hardware as needed for proper operation

This flexible door seal replaces a worn or damaged refrigerator door gasket to help restore a tight door closure and reduce air leaks. It fits into the door channel to help maintain proper cooling and reduce frost buildup. What it does

• Creates a compressible barrier between the door and cabinet to keep cold air in and warm air out
• Helps stop common symptoms like visible gaps at the door edge, excess frost/ice buildup in the compartment, and unstable interior temperatures
• Reduces strain on the compressor caused by air leaks and helps maintain consistent cooling
• Restores the appliance's intended seal when the original gasket is torn, stretched, or hardened

• One door seal

• Disconnect power to the appliance before starting and work on a cool, empty compartment
• Remove the old gasket fully and clean the channel or flange to ensure the new seal seats properly
• Press the new gasket evenly into the door channel; some models require gradual warming or light trimming for a perfect fit

This replacement switch restores reliable control of a selected function by opening or closing an electrical circuit inside your appliance. When the original switch wears out, buttons may stop responding or features may not activate consistently.

• Opens/closes an electrical circuit when the button/actuator is engaged
• Routes power or sends a signal to the control or component
• Common symptoms: no response when pressed, intermittent operation, or function won't start
• May show signs of heat damage, loose terminals, or inconsistent "click" feel

• Disconnect power at the breaker before servicing
• Photograph or label wire positions to ensure correct transfer to the new switch
• Move wires one at a time; fully seat connectors on the correct terminals
• Reassemble, restore power, and test the function activated by the switch

This lamp assembly replaces a damaged or nonworking interior refrigerator light to restore safe, reliable illumination. It includes the housing and lamp so you can see contents clearly and check temperatures at-a-glance. What it does

• Provides interior lighting so food and controls are visible when the door is opened
• Replaces cracked or yellowed lens/housing that scatters light or exposes wiring
• Restores a light that stays off due to a broken assembly
• Helps prevent food spoilage by making it easier to find items and verify temperatures

• One lamp assembly (housing with lamp)

• Disconnect power or unplug the appliance before beginning work
• Use basic hand tools; handle glass or lens pieces carefully to avoid breakage
• Check the door switch and wiring harness

This small replacement spacer positions and secures appliance components to maintain correct alignment and fit. Installing the spacer restores proper panel spacing and reduces vibration where a worn or missing spacer causes looseness or rubbing. What it does:

• Maintains the correct gap between panels, trim, or assemblies to ensure parts fit flush
• Keeps components aligned to prevent rubbing, binding, or uneven wear
• Helps reduce vibration and rattling caused by a missing or damaged spacer
• Preserves original part spacing for reliable operation of the surrounding components

• Disconnect power to the appliance before any service to avoid shock or injury
• Remove any trim or fasteners that block access; keep track of screws and small parts
• Match the new spacer's orientation to the original; do not force parts into place

The Temperature Sensor is an OEM part for Frigidaire ranges. It monitors and reports the temperature inside the oven cavity to ensure foods are cooked at the correct temperature. The sensor communicates temperature readings to the control board to regulate burner and heating element.

Causes of a bad temperature sensor can include faulty electronic elements, damage from oven spills or moisture intrusion, or sensors wearing out over extended use. At room temperature (70°F) the sensor should read around 1100 ohms. If your reading is 10% outside of that, the probe would need to be replaced.

Symptoms of a bad range temperature sensor include:

• Inaccurate or fluctuating oven temperatures
• Inconsistent or uneven cooking results
• Food burning on one side of the oven or under/overcooking
• The oven heating element running continuously without cycling

This OEM Frigidaire part can also be used on Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, and Sears/Kenmore.

The Oven Meat Probe is an OEM replacement part for Frigidaire ovens and ranges. It is used to accurately monitor the internal temperature of meat and other food items as they cook inside the oven.

Causes of a bad oven meat probe include damage to the temperature sensor or wiring over time from repeated high heat exposure during cooking. The wiring can fatigue and become brittle or the connector can corrode from steam and debris inside the hot oven area.

Symptoms of a bad oven meat probe include:

• Temperature readings that do not correspond to the food's actual doneness
• Inaccurate or inconsistent readings on the controller display
• The controller does not recognize that the probe is connected
• Physically damaged probe components like a cracked sensor tip

This Frigidaire OEM replacement part is also compatible with Electrolux, Gibson, Kelvinator, and some Kenmore ranges.

This receptacle is the appliance's power terminal housing that secures the incoming wiring and provides a safe connection point for the power harness. It helps restore reliable electrical connection and prevents loose or damaged terminals. What it does:

• Holds and protects the power terminal connections for the appliance
• Provides the mounting point for the incoming power harness/plug
• Helps eliminate intermittent power or arcing caused by a cracked or melted housing
• Restores safe, stable electrical contacts when the original receptacle is damaged

• Disconnect power at the breaker or unplug the appliance before starting
• Remove access panel(s) to reach the existing terminal housing; keep fasteners for reassembly
• Transfer wires exactly as found; note or photograph wire positions before removal
• If terminals or wiring are damaged, replace or repair those components per local electrical codes

This evaporator fan motor circulates cold air inside the refrigerator compartment to maintain even cooling and proper airflow. Replaces a failed or noisy fan motor to restore consistent temperature distribution. What it does:

• Spins the evaporator fan blade to move air across the evaporator coils and throughout the fresh-food compartment
• Helps prevent uneven cooling, warm spots, and excessive frost buildup when operating correctly
• Reduces or eliminates grinding, rattling, or humming caused by a worn or failing motor
• Works as part of the refrigerator's airflow system to support normal compressor and defrost operation

• One evaporator fan motor (single unit as shown)

• Disconnect power before servicing to avoid shock or injury
• Access typically requires removing interior panels; handle evaporator fins and wiring with care
• Verify fan blade clearance and secure electrical connectors before restoring power

This motor assembly is the factory-style replacement motor used to restore proper operation and movement in compatible Frigidaire appliances. It replaces a worn or failed motor to help your appliance run smoothly. What it does:

• Drives the appliance component it mounts to, restoring normal mechanical movement
• Stops symptoms like a non-spinning drum, no airflow, or loss of expected mechanical operation
• Helps eliminate intermittent starting, humming, or overheating related to failed motors
• Matches OEM fit and function when the motor assembly is the correct part for your model

• For experienced DIYers only; disconnect power before starting any repair
• Inspect mounting hardware, wiring harness, and connectors for damage and replace if needed
• Follow factory service manual steps for alignment, torque, and routing to avoid interference

This replacement evaporator fan blade helps circulate cold air inside the freezer or refrigerator compartment to maintain even temperatures and proper cooling performance. A direct-fit replacement when the existing blade is cracked, warped, or missing. What it does:

• Moves air across the evaporator to promote even cooling and frost prevention
• Restores proper airflow when a damaged blade causes noise or reduced cooling
• Helps reduce hot or warm spots inside the compartment
• Quiet, balanced operation when installed correctly

• One replacement evaporator fan blade

• Disconnect power to the appliance before starting any repair
• Typically accessed by removing interior panels in the freezer/refrigerator compartment
• Inspect the fan motor shaft and mounting for damage before installing the new blade

This is a nut that is used in many microwave ovens. It is typically used to hold interior fan in place. A nut is a fastener that is used to hold two items together or keep one component secure against a surface. Use and time can cause the nut to become stripped, damaged, or broken. If the nut is broken, it will no longer hold the fan in the right location. The nut will need to be replaced.Before replacing this part, the microwave should be unplugged. Open the refrigerator door and remove the cover that goes over the fan. The nut can then be removed using a nut driver. Replace the other parts before using the appliance.This nut is used in microwave ovens manufactured by Crosley, Electrolux, Frigidaire, and Kenmore. It is sold as a single part. This is an authentic OEM replacement part is sourced directly from the manufacturer.

This temperature control thermostat regulates refrigerator temperature by cycling the compressor and evaporator fan to keep food cold. It replaces a failed control to restore consistent cooling. What it does:

• Senses internal cabinet temperature via a capillary bulb and rod, opening/closing the electrical circuit to the compressor
• Stops excessive compressor run time when the set temperature is reached
• Helps correct symptoms such as inconsistent temperatures, unit running continuously, or failure to cool
• Works as the user-adjustable control when the front dial or lever is turned

• One thermostat assembly with capillary tube and mounting bracket

• Disconnect power before replacing; follow all safety precautions
• Handle the capillary tube and bulb gently—do not kink, stretch, or crimp the sensor
• Verify proper routing and secure mounting to ensure accurate temperature sensing

This motor is the replacement drive motor used to power the appliance's mechanical operation, restoring movement and normal function when the original motor fails. It provides direct, reliable replacement performance for compatible units. What it does:

• Spins the drive mechanism so the appliance can run cycles normally.
• Replaces a failed or noisy motor to reduce humming, stalling, or lack-of-motion symptoms.
• Restores proper mechanical operation when the appliance won't start or stops mid-cycle.
• Helps eliminate intermittent operation caused by worn or damaged motor components.

• One motor assembly

• Disconnect power before starting any repair to avoid shock or injury.
• Remove access panels and disconnect wiring harness; note wire locations or take a photo for reassembly.
• Replace motor mounting hardware and ensure proper alignment before reconnecting power.

This Tube Assembly routes water inside the refrigerator to the dispenser and ice-maker, restoring proper water flow and preventing leaks when the original line is damaged. Reliable replacement for delivery and fill connections. What it does:

• Transports water from the inlet to the ice maker/dispenser assembly
• Replaces cracked, kinked, or leaking tubing that causes puddles or low water flow
• Helps restore normal ice production and dispenser operation when the tube is the fault
• Matches OEM routing and connector types for correct fit and seal

• One tube assembly as shown

• Disconnect power and shut off the water supply before starting
• Remove ice maker or access panel as needed to reach routing; follow OEM service instructions
• Inspect fittings and replace any damaged clamps or seals; avoid kinking the new tube
• After installation, turn on water, check for leaks, and run dispenser/ice cycles to confirm proper flow

This spacer positions and supports components to maintain proper alignment and clearance in the appliance. It prevents rubbing and ensures panels or parts sit correctly for reliable operation. What it does:

• Keeps panels, brackets or assemblies spaced correctly to prevent contact and wear
• Restores proper alignment to reduce vibration, noise or rubbing symptoms
• Maintains clearance for airflow or moving parts where specified
• Provides a stable mounting point for adjacent components

• One spacer

• Install in the location shown in the service diagram and secure with the original fasteners
• Disconnect power to the appliance before beginning service to avoid shock or injury
• If the original spacer shows damage or distortion, replace it to restore correct fit

Replacement water-line tube that routes water inside the refrigerator to the ice maker or dispenser, helping restore proper water flow and reduce leaks. Designed to match factory routing so the line fits and seals correctly at the connections. What it does:

• Carries water from the cabinet valve to the ice maker or dispenser.
• Restores normal dispenser flow and ice production when the tube is cracked, pinched, or clogged.
• Helps stop visible leaks or pooling caused by damaged or misrouted tubing.
• Matches factory bends for correct routing and clearance behind panels.

• Disconnect power and shut off the water supply before starting any work.
• Remove shelves or panels as needed for access; watch for sharp edges.
• Check and replace any worn clamps or fittings; tighten connections and test for leaks with water on before reassembling.

Replacement screw that secures panels, trim and internal components in compatible appliances. Restores proper fit and helps reduce rattling or loose parts when the original fastener is missing, worn, or damaged. What it does:

• Fastens panels, brackets, trim pieces and small component assemblies to the appliance frame
• Helps eliminate noise and vibration caused by loose or missing fasteners
• Replaces stripped, corroded or missing screws to restore secure mounting
• Matches OEM fit when the identical screw is required for proper alignment

• Disconnect power to the appliance before starting any repair
• Use the correct driver size to avoid cam-out or damage to the screw head
• Do not overtighten; overtightening can strip threads or crack plastic parts

The Screw is an OEM part for Frigidaire ranges and ovens. This part is designed to securely fasten various parts of the appliance, ensuring stability and durability.

Over time, screws can become loose due to the expansion and contraction of materials with temperature changes. Regular use and the occasional necessary removal for repairs or cleaning can also wear down the threads, making them less effective.

Symptoms of a bad Screw (Chrome) include:

• Loose or wobbly components that should be securely fastened.
• Difficulty in securing parts due to stripped or damaged screw threads.
• Visible corrosion or deterioration of the screw.

This OEM Frigidaire part can also be used on Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, and Sears/Kenmore.

Size: 8-18 x 0.5 inch. Color: Chrome.
