Parts for Lg LRBC20512WW: Water / Ice Maker Parts

This replacement screw secures specified panels or components inside your appliance. Refreshing worn or missing hardware helps restore a tight fit, reduce rattling, and keep assemblies properly aligned for reliable performance.

• Provides secure fastening for brackets, panels, or internal assemblies
• Replaces stripped, rusted, or lost hardware
• Helps reduce vibration and rattling noises
• Symptoms include loose panels, shifting components, or a screw that won't tighten

• Disconnect power and allow any hot surfaces to cool before servicing
• Wear cut-resistant gloves and eye protection
• Match length and thread to the original; replace like-for-like
• Start threads by hand to avoid cross-threading; do not overtighten

The Clip is an OEM part for LG refrigerators. This clip secures the water tube in place, preventing it from moving or becoming disconnected. It plays a crucial role in maintaining the proper flow of water to the ice maker and water dispenser.

Causes of a bad water tube clip can include physical damage, wear and tear from regular use, or brittleness due to temperature fluctuations. If the clip fails, it can result in leaks or disconnections, disrupting the water supply.

Symptoms of a bad water tube clip include:

• Water leaks inside or outside the refrigerator
• The water tube becoming loose or disconnected
• Reduced or no water flow to the ice maker or water dispenser

This OEM LG part is also compatible with Sears/Kenmore refrigerators.

The Icemaker Assembly is an OEM part for LG refrigerators. It is responsible for producing and storing ice within the freezer compartment.

You should replace the icemaker assembly if it becomes faulty. Causes of a bad icemaker assembly can include wear and tear from regular use, mineral buildup from hard water, or failures in the mechanical or electronic components. These issues can lead to inconsistent ice production or complete failure to produce ice.

Symptoms of a bad icemaker assembly include:

• The icemaker not producing ice
• Leaking water around the icemaker
• Ice cubes that are misshapen or smaller than usual
• Unusual noises coming from the icemaker

This OEM LG part is also compatible with Sears/Kenmore.

The Water Supply Tube (1/4" O.D.) is an OEM part for LG refrigerators. It transports water from the household water line to the refrigerator’s water dispenser and ice maker, ensuring a steady and reliable supply of water for these functions.

Causes of a bad water supply tube can include wear and tear over time, kinks or bends restricting water flow, or leaks due to cracks or punctures.

Symptoms of a bad Water Supply Tube include:

• Leaks or water pooling behind or under the refrigerator
• Reduced or no water flow to the dispenser or ice maker
• Visible cracks or kinks in the tube
• Ice maker not producing ice or dispensing water intermittently

This OEM LG part is also compatible with some Kenmore models.

This injection tube directs water to the refrigerator ice maker so the mold fills correctly and produces ice. It replaces a cracked or blocked tube to restore reliable water flow to the ice-making assembly. What it does:

• Channels water from the valve to the ice maker fill cup for proper ice production
• Helps prevent leaks caused by cracked or brittle tubing
• Commonly replaced when the ice maker won't fill, fills slowly, or leaks near the ice mold
• Works with the ice maker fill system; not a water valve or pump

• Disconnect power and shut off the water supply before starting work
• Inspect adjoining fittings and seals; replace worn grommets or clips as needed
• Handle carefully to avoid kinks or damage to the tube during installation

This replacement water inlet valve controls the flow of water to the refrigerator's dispenser and ice maker, restoring reliable water delivery and ice production. Designed to match OEM fit and function. What it does:

• Opens and closes to route water to the dispenser and ice maker when commanded
• Helps stop water flow when the dispenser is inactive to prevent leaks
• Commonly replaces failed valves that cause no water, weak dispensing, or continuous running
• Works as a direct-fit valve for compatible LG refrigerator units

• Disconnect power and shut off the water supply before starting work
• Handle connectors and tubing carefully; confirm tight, leak-free connections when reassembling
• Inspect and replace damaged inlet tubing or fittings as needed to prevent leaks

The Water Nozzle is an OEM replacement part for LG refrigerators. It is a component within the refrigerator's ice maker and water dispenser system. The water nozzle controls the flow of water into the ice making mold or water dispenser functions.

Symptoms of a bad water nozzle include:

• Slow filling or inability to fill the ice-making mold
• Inconsistent or weak water dispensing from the refrigerator's door
• Leaks or water drips around the ice maker or water dispenser area

Causes of a faulty water nozzle can be mineral deposits accumulating over time, wear and tear from heavy use, or damage due to impact or freezes.

This part is also compatible with many Kenmore side-by-side refrigerator models.

This mechanical mounting band secures a bracket assembly inside the appliance to keep components aligned and reduce vibration. It restores proper bracket positioning so moving parts run quietly and reliably. What it does:

• Holds a bracket or component assembly in place to maintain proper alignment
• Dampens movement and reduces vibration-related noise or rattling
• Prevents excess wear by keeping parts from shifting during operation
• Helps maintain correct clearances to avoid interference or rubbing

• Disconnect power before inspecting or replacing internal parts
• Remove only the fasteners necessary to access the bracket; keep track of hardware
• Secure all fasteners to the manufacturer's torque or snug specification
• Replace the band if bent, cracked, or missing to restore proper fit and function

The Water Inlet Valve is an OEM part for LG refrigerators. It regulates the flow of water to the ice maker and water dispenser, ensuring they receive the correct amount of water needed for ice production and dispensing. This valve is critical for maintaining the efficiency and functionality of your refrigerator’s water systems.

Causes of a bad water inlet valve can include mineral buildup from hard water, electrical malfunctions, or general wear and tear over time. A faulty valve can disrupt water flow, leading to issues with both the ice maker and water dispenser.

Symptoms of a bad water inlet valve include:

• No water dispensing
•  No ice production
• Slow or irregular water flow
• Water leaks around the valve area

This OEM LG part is also compatible with Sears/Kenmore models.
