Parts for Thermador PRSE366: Weldment Parts

This is a 48" shelf with louvers designed to replace a damaged or missing shelf and restore usable storage space. It provides stable support and proper airflow where louvers are required. What it does:

• Replaces a broken, cracked or warped shelf to restore usable storage area
• Louvers allow airflow and drainage where specified by the original design
• Supports refrigerated items and helps keep contents organized
• Prevents items from falling through compared with open-frame shelving

• Inspect mounting points and clips for damage before installing the new shelf
• Lift into place and engage any front/rear supports or clips; secure per the original hardware
• Use caution handling edges to avoid cuts; wear gloves if needed
• Disconnect power only if accessing internal components near electrical parts; shelf replacement typically does not require wiring changes

This is a 48" shelf with louvers designed to replace a damaged or missing shelf and restore usable storage space. It provides stable support and proper airflow where louvers are required. What it does:

• Replaces a broken, cracked or warped shelf to restore usable storage area
• Louvers allow airflow and drainage where specified by the original design
• Supports refrigerated items and helps keep contents organized
• Prevents items from falling through compared with open-frame shelving

• Inspect mounting points and clips for damage before installing the new shelf
• Lift into place and engage any front/rear supports or clips; secure per the original hardware
• Use caution handling edges to avoid cuts; wear gloves if needed
• Disconnect power only if accessing internal components near electrical parts; shelf replacement typically does not require wiring changes

Insulation lowback cover for 30-inch electric ranges. Shields internal components from heat. Replace if cracked, warped, or missing for proper insulation.

This Tinnerman C nut is a spring-steel speed clip that secures sheet-metal panels and components using a mating screw. It provides a captive thread where a tapped hole or weld nut isn't practical, helping restore proper fit and stop rattles. What it does:

• Provides a captive, reusable threaded anchor for self-tapping or machine screws
• Secures trim, access panels and internal brackets to sheet-metal edges or panels
• Stops panel movement and vibration-related noise when the original clip is damaged or missing
• Works where a conventional nut or stud cannot be used due to limited access

• Disconnect power and unplug the appliance before accessing panels or fasteners
• Position the clip over the panel edge or hole, then press or slide until it snaps into place
• Align the mating screw and thread carefully to avoid cross-threading the clip
• Use hand tools or pliers for placement; do not over-torque the screw once installed

This part has been discontinued by the manufacturer and is no longer available.

This is a #10 x 1/2 inch pan-head Phillips sheet-metal screw used to fasten appliance panels and internal components. It replaces missing or worn screws to restore proper fit and reduce rattles or loose parts. What it does:

• Secures trim, access panels, brackets and other sheet-metal parts
• Keeps components aligned and prevents vibration-related noise
• Restores proper fastening when original screws are stripped, lost or corroded
• Works where a #10 x 1/2" pan-head Phillips sheet-metal screw is specified

• One #10 x 1/2" pan-head Phillips sheet-metal screw

• Disconnect power and water before servicing the appliance
• Use the correctly sized Phillips screwdriver to avoid stripping the head
• Start threads straight and tighten until snug—do not overtighten to avoid stripping or deforming sheet metal
• Keep small parts away from children and pets

Secures the glass cooktop to the range frame. Replace if clip is cracked, broken, or missing to properly hold the cooktop surface in place during use.

This is a 1/4-20 hex keps nut — a hex nut with an attached captive washer that helps secure panels, brackets, and fasteners. It provides a simple, vibration-resistant fastening solution for appliance assemblies. What it does

• Fastens components to machine frames, panels, and brackets using a 1/4-20 bolt or stud.
• Captive washer helps resist loosening from vibration and movement.
• Commonly used where a compact, pre-assembled nut-and-washer is needed for reliable retention.
• Replace when threads are stripped, washer is damaged, or parts wobble or rattle.

• One hex keps nut (1/4-20).

• Disconnect power and follow appliance safety procedures before working on hardware.
• Use the correct 1/4" socket or wrench to install; hold the mating bolt head as needed to tighten.
• Tighten securely but avoid over-tightening to prevent thread damage or distortion.
• Replace with the same nut type and size to maintain fit and vibration resistance.

90-degree elbow orifice holder for gas ranges and cooktops. Replace this gas line connector if cracked, broken, or causing improper gas flow alignment.

Foam adhesive tape seals gaps between range panels to reduce vibration and eliminate rattling. Replace when worn or loose. Verify fit with your model number.

Mounting screw for securing range components and panels. Replace worn, stripped, or missing screws during repairs or maintenance to ensure proper assembly.

Griddle cleaning kit for cooktop and range griddle surfaces. Removes rust, debris, and buildup from neglected or heavily used griddles. Restores appearance.

Package of 60 pyramid shaped briquettes
