Bryan S Athens , AL November 17, 2014 Jenn air oven digital keypad not working the clock worked/and timer button worked/stove top worked but oven would not work due to the rest of the keypad buttons not working This is an oven with keypad directly above oven door. And needed to replace the keypad and housing. Pretty easy fix. first turn oven off at breaker and unplug unit. Second pull off top burner knobs and remove 2 screws that are hidden behind each knob. 4th remove housing screws (1 screw on each side of housing and 4 screws on bottom of housing). 5th pull out housing and disconnect all wire connectors from mother board. They are labeled and color coded). There are also 4 small red lights.These connectors slide off from side and pull lights out. 6th install new housing/keypad in reverse order.take care with ribbon cable and make sure it snaps in.7th plug black in and turn breaker on. Finished. The part was at my door step next business day w regular shipping. Read More... 6 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers
Mark W Charlotte , NC March 28, 2015 Appliance: Maytag Slide-In Electric Range JES8850BAS20 There were two problems: 1 the 4 or 5 of the soft touch buttons on the control panel had quit working 2 the burner switch on the far left had starting making a clicking noise in the off position Once the oven was powered off and pulled out from the counter top about 6-8 inches, the 6 screws were removed from the control panel (4 underneath and 1 on each side). The control panel was gently pulled forward. I took several pictures of the multiple wire harness connections and then determined the best way to disconnect them. After all wiring was disconnected, the new switch was mounted in place. Next, the 3 other old switches were transferred to the new control panel. Then all of the red light tabs and the right sided burner flip switch were removed and installed on the new control panel. These parts were very delicate so great care was taken not to damage them during the de-installation from the old control panel. Last, the old circuit board was removed and re-installed in the new control panel and all wiring harnesses were connected. The 6 screws were then installed in the new control panel and power was turned back on to confirm that all functions were now in working order poor to sliding the stove back into place on the countertop. Read More... 3 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Nut Drivers, Screwdrivers
Erik T Saint Joseph , MO January 17, 2015 Oven portion of the appliance would not turn on I called the tech support of this site to troubleshoot the issue. They were very friendly and had the part needed right away. I turned out to be a bad touch pad. Once the part arrived it took 20-30 mins to replace thanks to the directions on the website. Thanks to the help and parts we are back in action. Thank you! Read More... 1 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers
Raymond H Sterling Heights , MI September 27, 2019 Appliance: Maytag Slide-In Electric Range JES8850BAS20 Left side of key pad did not work Jenn Air range I replaced the control panel as recommended by Appliance Parts Pros Read More... Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Nut Drivers
