James M Camden , NC July 25, 2020 Appliance: KitchenAid Refrigerator, French Door, Bottom Mount KRFF507ESS01 The evaporator was freezing up. Checked the evaporator fan it wasn't working properly. Replaced the fan all is good Read More... 4 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 2+ hours Tools: Nut Drivers, Screwdrivers
Thomas N Hughesville , MD January 13, 2023 Appliance: Model KRFF707EBS001 Not going into defrost mode and icing up. I had to remove most of the shelves and drawers to get to the back panel to be able to replace the Fan Motor & Harness. Read More... 2 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Nut Drivers, Pliers
Vincent M Myrtle Beach , SC August 01, 2025 Appliance: KitchenAid Refrigerator, French Door, Bottom Mount KRFF507ESS01 Frozen evaporator coil and water under crisper draw I spoke to your tech assist group and watched a few utube videos. Read More... 1 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 2+ hours Tools: Adjustable Wrench, Screwdrivers, Socket Set
Bruce C Everett , WA March 30, 2024 Appliance: KitchenAid Refrigerator, French Door, W/Dispenser KRFF707ESS01 Refrigerator warm (50 degrees) freezer cold Replaced the evaporator fan assembly inside the refrigerator. The evaporator fan is located in the inside rear of the refrigerator behind the bottom drawers. You must remove the crisper drawers and bottom drawer center support to gain access to the rear evap plastic cover. The cover can be difficult to remove as it snaps onto upper vent assembly that houses the air duct and filter. Remove two 1/4 in. screws on the cover and gently pull towards you to un snap. Now you can access the evap fan assembly. The fan is mounted to the duct with a rubber mount. Pull the corners with a needle nose pliers to remove the fan asm. The fan assembly comes with the wire harness and thermistor and temp sensor. Install in reverse order. Read More... 1 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Nut Drivers, Pliers
