Richard M Coppell , TX October 06, 2018 Appliance: KitchenAid Refrigerator KSRS25FTSS01 Not delivering ice down the chute, auger not working but it makes ice New auger motor, shaft, and washer fixed it for about $120 , repair people quoted $500 Read More... 4 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Nut Drivers, Screwdrivers
Kerry R San Antonio , TX May 28, 2019 Appliance: Whirlpool Refrigerator GS6NBEXRL02 While trying to replace the ice dispenser motor, I could not remove the shaft, it was rusted into the motor We put quite a bit of rust busting oil on the shaft and motor. It took three days, and finally the shaft came out. Read More... Do-It-Yourself Rating: Repair Time Estimate: 2+ hours Tools: Adjustable Wrench, Pliers, Screwdrivers, Socket Set, Wrench Set
David P Chattanooga , TN October 07, 2024 Appliance: KitchenAid Refrigerator KSCS25FVMS03 Ice dispenser not dispensing ice driveshaft not spinning but motor starting The existing motor would come on when you pushed the door paddle for ice, but ice would not dispense. Determined there was an issue in the drivetrain. Had to replace the motor and gearbox assembly for the ice dispenser driveshaft. Also found a cracked driveshaft seal where the shaft enters the freezer compartment. Replacement parts fit perfect and now dispensing ice! Read More... Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Nut Drivers, Screwdrivers
Kent A Webb City , MO September 29, 2015 In door ice dispenser stopped working Replaced auger motor, washer and coupler seal. The video on your site was helpful, but I had to go to YouTube to find my model. Replacing motor was easy. Hardest part was getting washer on auger shaft. Had to line it up in the blind. Overall, not bad. Glad I did it. Read More... Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Nut Drivers, Screwdrivers
Robert N Atlanta , GA June 01, 2014 Appliance: KitchenAid Refrigerator KSCS25FTMS00 The icemaker wouldn't dispense ice I called customer service and asked if it was more likely to be the motor or the control board. The CS person wouldn't diagnose, but she was willing to say that they sell many more motors than controller boards, so I ordered the motor. Then, right after I clicked purchase, I remembered I meant to buy a washer, so I quickly called CS. This time the CS person said she couldn't modify an existing order, but she was willing to ship out a washer without additional shipping charges. The motor an washer arrived sooner than expected, and my ice dispenser is working again. Read More... Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Nut Drivers, Pliers, Screwdrivers
