Joe S Virginia Beach , VA January 15, 2018 Appliance: KitchenAid Refrigerator KFIS25XVMS10 Trying to dispense water. Makes muffled banging noise with no water flowing. Replaced the Water tank/head assembly. The problem is not the water tank or the plastic tubing being clogged. It's the valve that the filter screws into, and specifically it's the two little white prongs that protrude slightly out of the water valve. They are pushed in when the filter or temporary plug are screwed in. Mine were wore down so the filter wouldn't make good contact but the plug did. Before I replaced the part, I screwed in the temporary blue plug (in place of the water filter) and the water flowed fine. However you can't just replace the water valve you have to replace the entire water tank/head assembly. It took me about an 75 minutes or so including removing the contents and right side shelves and the bottom shelve unit with sliding drawers. The part fits perfectly. Getting the old one out is a bit tricky. I'll try to go through the steps: 1. Turn off the water and unplug the power cord to the fridge. Disconnect the water line from the wall to the fridge. Have a short 2" tall pan underneath the joint and lay down some towels too. There won't be too much water leaking at this point. 2. Remove the filter cover, then the vertical panels inside the fridge. Inserting a screw driver will bend the prongs. Do this slowly so you don't crack the panels or the prongs. 3. Remove the valve head assembly and pull out the short gray tube from the other valve. ONCE YOU DO THIS ALL THE WATER WILL THEN FLOW...have someone behind the fridge to catch the water!!! 4. Then slowly start pulling out all of the tubing...the 1" diameter tubing the snakes back and forth is a little hard to get out but not impossible. 5. Pull out the whole part which will be exactly like the one your be installing. I took pictures before I pulled the old part out (once the panels were off) so I knew how to install the new one. That helped me.. 6. Remove the LOWER back cover so it's easier to grab the end of the new part when you "fish" is through. Another person once again I helpful at this point. 7. Then it's just a matter of reconnecting everything in reverse! HOPE THIS HELPS! :) Read More... Do-It-Yourself Rating: Repair Time Estimate: 1-2 hours Tools: Adjustable Wrench, Screwdrivers, Wrench Set
Pablo C Apex , NC November 23, 2015 Appliance: Model MAYTAG MFI2569VEM4 Water dispenser made a lot of noise Water dispenser came down to a trickle and made a lot of noise, I changed the filter but it didnt help and thus the water tank/head assembly needed to be replaced. Replacing the water Tank/head assembly was an easy task, the hardest part is removing the covers and taking care of not breaking the insulation of the water inlet hose. For the not-so-experts like me it is also good to rememebr to have a bucket to collect all the water that comes out after the connection to the solenoid valves is removed. At the end the wife is happy... and that's all that matters Read More... 52 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Screwdrivers, Wrench Set
Philip S Chesapeake , VA July 27, 2014 Appliance: Maytag Refrigerator MFI2568AEW12 Slow flow & noise when dispensing water (maytag model #mfi2568aew) Replaced the water filter, but that didn't work. From researching online thought it might be the water filter head. The part ordered includes the water filter head as well as the water reservoir. Part received with no instructions. Had to remove all refrigerator internal shelves to get to panel at back of refrigerator. Removed water filter cover, and two panels at back of interior of refrigerator. Also had to unfasten water supply behind refrigerator. Once all this was done, was able to remove the old water filter head and reservoir. Also had to disconnect one hose from the water filter head to a valve that I was not replacing. Connected new part using reverse procedure. This has completely corrected the issue of low water flow from the water dispenser. Read More... 41 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Adjustable Wrench, Pliers
John D Rockwall , TX September 07, 2014 Appliance: Maytag Refrigerator MFI2568AES12 Water flow was normal at first then after a couple of seconds would be reduced to a trickle This problem only occurred after installing a new filter, it worked fine with the old filter. Read similar stories on line, checked that the solenoid valves were getting power and decided it was the filter head. Filter head and tank all come together. Replacement took about 1 hour. Remove the shelves on the right, pop off the covers on the back with a screw driver in the latch slots. Disconnect water line to valves, disconnect supply line in back. Tank, line and head are easily removed. I was worried that snaking the supply line back into the rear would be an issue but Maytag did a good job of providing a nice channel for this to be pushed through. Read More... 27 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Adjustable Wrench, Nut Drivers, Screwdrivers
Michael H Virginia Beach , VA April 20, 2015 Appliance: Model MAYTAG FRENCH DOOR, FREEZER ON BOTTOM No water at door or ice maker It hade a blockage in the water tank head assembly, I ordered both , the water head assembly and the daul water valve . Was going to return water valve but could not figure ot how to get it off without damaging the plastic seats so I replaced both. It was no problem to do and took me all of about 45 minutes, and that included emptying the fridge. This site is a big help, you can ask questions and I shoped around for the parts and they had the best price, but the best thing more than price is they will let you return any part so for me that is good. Thanks Appliance Parts Pros I have many rentals and I will not go anywhere else Read More... 21 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Adjustable Wrench, Nut Drivers, Pliers, Screwdrivers
