Parts for Thermador SGN36GS: 02 - Knobs & Burners Parts

Color: Black.

The Burner Cap Assembly is an OEM part for Bosch ranges and cooktops. It refers to the rounded caps placed over each burner to contain and direct flames safely.

Causes of a bad burner cap assembly can include warping, cracks or punctures from consistent high heat that allow flames to escape improperly. Surface scratches likewise compromise insulation and durability over time.

Symptoms of damaged or faulty caps are:

• Excessive flames licking up beyond cap borders
• Scratches or cracks visible on hot surfaces
• Difficulty adjusting flame height precisely
• Burners do not heat evenly or shut off completely

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

The Gas Burner Seal is an OEM part for Bosch cooktops and ranges. This component sits between the burner and the cooktop surface, providing a seal that prevents gas leaks and ensures efficient burner operation. The seal helps maintain proper gas flow and supports the stability of the burner during cooking.

You should replace the gas burner seal if it becomes damaged or deteriorates. Over time, exposure to high temperatures, food spills, and regular cleaning can cause the seal to wear out or crack, leading to potential gas leaks and reduced burner efficiency.

Symptoms of a bad gas burner seal include:

• Visible cracks or damage to the seal
• Gas smell near the burner area
• Inefficient or uneven burner flames

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

Color: White. Right front. Gas.

Color: Black.

This burner cap assembly covers and protects the gas burner head and helps shape the flame for even cooking. It replaces a damaged or missing cap to restore proper burner appearance and flame pattern on compatible cooktops. What it does:

• Centers and shields the burner head to promote an even flame distribution during use
• Replaces cracked, warped, or missing caps that can cause uneven heating or unstable flames
• Helps maintain correct burner alignment for reliable ignition
• Restores finished appearance around the burner for safe, proper operation

• One black burner cap assembly

• Turn off gas supply and power to the appliance before servicing
• Allow the cooktop to cool fully; handle with care to avoid scratching or chipping
• Seat the cap squarely on the burner head—no tools typically required

The Venturi Gas Tube is an OEM replacement part for Bosch gas cooktop ranges. Its primary function is to ensure an optimal gas/air mixture for consistent and efficient burner combustion, thereby enhancing the overall performance of the cooktop.

Causes involve normal wear of internal components from continuous heating and cooling cycles. Corrosion damage may also disrupt the venturi tube over time.

Symptoms of a faulty venturi gas tube include:

• Unstable or hard-to-control flame levels
• Potential issues shifting burner flames out of their intended position
• Safety risks including carbon monoxide from improper fuel/air balance

This OEM Bosch part is also compatible with Thermador, Gaggenau and some Kenmore models.

The Burner Gasket is an OEM part for Bosch cooktops and ranges. It provides a seal between the burner and the cooktop surface, preventing gas leaks and ensuring efficient operation.

Causes of a bad burner gasket can include wear and tear from frequent use, exposure to high temperatures, or damage from cleaning activities. Over time, the gasket may become brittle or develop cracks, compromising its sealing ability.

Symptoms of a bad burner gasket include:

• Gas odors near the cooktop
• The burner not igniting properly
• Visible cracks or deterioration in the gasket
• The burner not sitting securely in place

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

Used to hold down the jet holder assembly.

The Tape, Foam is an OEM part for Bosch cooktops. This foam tape creates a tight seal between the cooktop surface and surrounding countertop. It helps contain spills and keeps external surfaces heat-isolated.

Causes of bad foam tape can include wear and breakdown of the adhesive over repeated exposure to cooking heat and cleaning chemicals.

Symptoms of a bad foam tape include:

• Fluids leaking down around the edges of the cooktop
• Hot surfaces outside the cooktop area that can cause burns
• Reduced heat containment impacting cooking efficiency

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

The Igniter Mounting Clip is an OEM part for Bosch ranges. It secures the igniter to the range top, ensuring it is properly aligned and stable for optimal ignition performance. The surface igniter is crucial for the ignition of gas burners, facilitating an immediate and safe flame to cook with.

Over time, the Igniter Mounting Clip can succumb to various forms of wear and tear, including corrosion from exposure to moisture, degradation from frequent heating cycles, or physical damage during cleaning or maintenance activities.

Symptoms of a compromised Igniter Mounting Clip include:

• The surface igniter becoming loose or dislodged
• Difficulty in igniting the burner or uneven flames
• Noisy or irregular ignition sounds
• Visible signs of damage or corrosion on the clip

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

This is a cooktop burner igniter OEM replacement part for Bosch cooktops and ranges and is sold as an individual part. This part creates a spark that ignites the burner within your cooktop or stovetop and is made of a combination of metal and ceramic.

Causes of a bad ignition plug can include issues with the electronic module, worn electrodes that no longer spark reliably, or damaged wiring.

Symptoms of a bad ignition plug include:

• Gas burners that will not light or remain lit
• Delayed ignition of one or more burners
• Intermittent or no sparking from the ignition plug

This OEM Bosch part is also compatible with Thermador, Gaggenau and some Kenmore models.

This is a standard left-side control knob for appliance surface/console controls that restores proper grip and pointer alignment for temperature or power selection. Durable plastic construction matches original fit and feel. What it does:

• Replaces a cracked, loose or missing left-side control knob so you can adjust power/temperature precisely
• Fits standard splined control stems for easy push-on installation
• Restores the pointer/indicator so settings are visible and accurate
• Helps prevent accidental setting changes caused by a worn or slippery knob

• One left-side standard black control knob

• Pull the old knob straight off the control shaft; push the replacement fully onto the stem until it seats
• Align the knob pointer with the control indicator before use
• Disconnect power at the breaker or unplug the appliance before servicing for added safety
• Do not force the knob onto a damaged or mismatched shaft

Color: White. Right rear. Gas.

Color: Black. Right rear. Gas.

Used to hold down the jet holder assembly.

The Venturi Gas Tube is an OEM replacement part for Bosch gas cooktop ranges. Its primary function is to ensure an optimal gas/air mixture for consistent and efficient burner combustion, thereby enhancing the overall performance of the cooktop.

Causes involve normal wear of internal components from continuous heating and cooling cycles. Corrosion damage may also disrupt the venturi tube over time.

Symptoms of a faulty venturi gas tube include:

• Unstable or hard-to-control flame levels
• Potential issues shifting burner flames out of their intended position
• Safety risks including carbon monoxide from improper fuel/air balance

This OEM Bosch part is also compatible with Thermador, Gaggenau and some Kenmore models.
