Parts for Thermador RDFS30: 06 - Non-Sequence Manifold Assy Parts

Burner won't spark or ignite? This spark switch signals the ignition module to light gas burners. Common DIY repair with basic tools, 15-30 minutes.

Replace your range's tubing assembly if the original is cracked, damaged, or leaking. This part connects internal components for proper operation.

This tubing assembly routes water inside the refrigerator to the dispenser/ice system, restoring a sealed water path and reliable flow. Use it to replace cracked, kinked, or leaking tubing for better water delivery. What it does:

• Carries water from the inlet to the dispenser/ice components to enable ice and water dispensing
• Stops leaks and seepage caused by cracked or damaged tubing
• Restores proper water routing when bends or kinks restrict flow

• Tubing assembly

• Turn off the refrigerator and shut off the water supply before starting work
• Drain any remaining water from lines and have a towel/container ready for spills
• Inspect connections and use new fittings or seals if the old ones are damaged

Jet holder assembly secures the orifice that meters gas flow to your cooktop burner. Replace if cracked, stripped threads, or missing nut components.

Jet holder assembly routes gas through the orifice to the burner. Replace if cracked, corroded, or stripped threads prevent secure installation.

Saddle clamp secures gas lines and wiring on cooktops and ranges. Replace if cracked, loose, or missing to prevent rattling and ensure safe operation.

Used to hold down the jet holder assembly.
