Parts for Thermador PSC366ZS: 22 - Grill Assembly Parts

Electrode that produces the ignition spark for gas ovens and ranges, restoring reliable burner lighting. Replace a damaged or worn electrode to stop repeated clicking, weak sparks, or burners that fail to light. What it does:

• Delivers the spark at the burner to ignite gas during startup.
• Common symptom fix: oven/range burners that won't light or that click continuously without producing a flame.
• Use when the electrode is cracked, corroded, or the ceramic insulator is damaged.
• Works as part of the appliance's ignition system alongside the spark module/igniter wiring.

• Turn off power and gas supply before beginning any service.
• Avoid touching or chipping the ceramic insulator; handle the tip carefully.
• Reconnect wiring exactly as removed and secure the electrode in the original orientation.

This deflector redirects dishwasher spray to the rack and helps prevent the spray arm from hitting dishes. Replace a cracked or broken deflector to restore proper water coverage and reduce spraying issues. What it does:

• Directs wash water from the spray arm for better coverage of dishes
• Keeps the spray arm clear of obstructions so it can rotate freely
• Helps prevent water from spraying into areas it shouldn't
• Common symptom: visible damage, cracked or missing deflector causing poor cleaning or spray-arm interference

• Disconnect power and water supply before servicing
• Remove the lower rack to access the spray arm and deflector
• This deflector typically snaps or screws into place; use hand tools as needed
• Inspect spray arm and mounting area for debris or damage during replacement

This surface burner head replaces a worn or damaged gas cooktop burner to restore reliable ignition and more even heat across cookware. Ideal when a burner is cracked, warped, or producing inconsistent flames during cooking. What it does:

• Directs gas flow to create a stable flame for cooking
• Helps restore even heat distribution for consistent cooking results
• Addresses symptoms such as weak or inconsistent flames, burner that won't light, or visible damage to the burner surface
• Works with the existing cooktop ignition and burner cap to resume normal operation

• Turn off gas supply and electrical power to the appliance before starting; allow all parts to cool completely
• Remove grates and burner caps, lift out the old burner, and seat the replacement so ignition ports align properly
• Avoid scratching porcelain/enamel surfaces; use gentle hand tools and follow manufacturer torque recommendations for screws

This deflector directs dishwasher spray water for proper coverage and helps protect nearby components from direct spray. It replaces broken or warped deflectors to restore intended water flow and cleaning performance. What it does

• Guides spray water toward dishes and spray arms to maintain even coverage
• Prevents direct spray from hitting sensitive components or seals
• Helps reduce spotting and uneven cleaning caused by misdirected water
• Fits where the original deflector is mounted; replaces cracked, broken, or deformed pieces

• Turn off power and water supply to the appliance before starting any repair
• Remove the lower rack or other obstructions for clear access to the mounting area
• Inspect mounting tabs and surrounding components; replace any damaged clips or fasteners

This grill grate provides a stable, even cooking surface for compatible Bosch grills, restoring proper support and heat contact for pans and food. It replaces worn, bent, or missing grates to improve cooking consistency. What it does:

• Serves as the primary cooking surface, supporting cookware and food above the burner or heat source.
• Restores proper clearance and airflow for even heating when original grate is warped or damaged.
• Keeps food elevated and stable to prevent tipping or contact with burners.
• Foot provides extra stability and corrects alignment within the grill frame.

• One grill grate with attached foot

• Ensure the appliance is completely cool and gas/electric supply is turned off before handling.
• Typically installs as a drop-in replacement; align grate and foot with existing supports and seating points.
• Inspect surrounding seals and supports; replace any damaged mounting hardware for secure fit.
• Clean with non-abrasive cleaners; avoid harsh scrubbing that could remove coatings or finish.

This is a compression nut for 5/16-inch tubing. It secures the tubing to a compatible compression fitting to create and maintain a tight, reliable connection.

• Clamps 5/16-inch tubing onto a matching compression fitting when tightened
• Helps restore a secure seal at a leaking or loose compression joint
• Useful when threads are stripped, the original nut is cracked, or the connection won't hold tension
• Common signs include drips at the fitting, inability to tighten, or visible thread damage

• Shut off the supply and allow the system to depressurize before service
• Use appropriately sized wrenches; avoid overtightening to prevent damage
• Inspect the ferrule/olive and tubing end; replace if worn or distorted
• After installation, restore supply and check for leaks at the connection

This compression sleeve forms the sealing ring for a 5/16-inch tubing compression joint, restoring a watertight connection when used with a matching compression nut and fitting. Ideal for stopping leaks and restoring reliable water lines. What it does:

• Creates the compression seal on 5/16" tubing when installed with a compatible compression nut and fitting.
• Stops leaks or drips at compression-style water connections.
• Used on appliance water lines (ice makers, water inlets) and other 5/16" tubing joints.
• Replaces worn or damaged sleeves that fail to hold a tight seal.

• Shut off the water supply and relieve pressure before working on water lines.
• Inspect and cut tubing squarely; slide the sleeve onto the tube before threading the compression nut and fitting.
• Tighten the compression nut per the fitting manufacturer's instructions and check the joint for leaks.
• Replace the sleeve if damaged or deformed.
