Parts for Thermador PSC366ZS: 02 - 36`` Cooktop Rough-In Box Parts

This is a quality spark re-igniter module for stoves, ranges, and ovens. This part is located between the cooktop on the stove. This part creates a spark to ignite a low-pressure gas flow that goes to the flame pilot light. It will stay lit until the thermostatic control on the oven is turned to the off position.Sometimes, the spark re-igniter will become damaged or stop working, which can cause problems using the range. If there is a weak or nonexistent spark between the igniter pin and the edge of the gas burner, this is a sign the spark re-igniter needs to be replaced. The first thing to do is unplug the stove from the wall. Access the back of the stove and remove the large panel. Remove the original component and install the new one in its place.This is an authentic OEM replacement part that has been obtained directly from the manufacturer. The spark re-igniter module is sold as a single part. It is made to be compatible with Bosch and Thermador stoves and ranges.

The Simmer Control is an OEM component specifically designed for Bosch ranges. It regulates gas flow to provide the lowest possible flame setting needed for delicate cooking tasks. Precise control allows for uniform, attentive simmering.

Symptoms of a bad simmer control include inconsistent or unadjustable flame heights on low settings. Cracks, damage, or wear of internal mechanisms over time can also cause unstable flame control.

Causes of bad simmer control can be normal wear and tear issues like dirt buildup impeding mechanisms. Accidental impact or overheating leading to cracks are other causes for replacement.

Symptoms of a bad simmer control include:

• Flames that surge or fluctuate below the lowest settings
• Inability to adjust the flame down sufficiently low
• Burners that shut off or cause overflow flooding on low-heat

This OEM Bosch part is also compatible with Thermador and some Kenmore ranges. Replace for dependable, Fine-tuned low-heat performance.


This Tinnerman C nut is a spring-steel speed clip that secures sheet-metal panels and components using a mating screw. It provides a captive thread where a tapped hole or weld nut isn't practical, helping restore proper fit and stop rattles. What it does:

• Provides a captive, reusable threaded anchor for self-tapping or machine screws
• Secures trim, access panels and internal brackets to sheet-metal edges or panels
• Stops panel movement and vibration-related noise when the original clip is damaged or missing
• Works where a conventional nut or stud cannot be used due to limited access

• Disconnect power and unplug the appliance before accessing panels or fasteners
• Position the clip over the panel edge or hole, then press or slide until it snaps into place
• Align the mating screw and thread carefully to avoid cross-threading the clip
• Use hand tools or pliers for placement; do not over-torque the screw once installed

The Ignition Device is an OEM part for Bosch ranges and ovens. Located near each gas burner, the ignition device provides the critical spark needed to light the burners during startup.

Causes of a bad ignition device can include wear from prolonged use over many years. Mineral buildup or debris accumulation may also prevent the spark from jumping across.

Symptoms of a bad ignition device include:

• Burners failing to light or staying lit
• Repeated attempts needed to ignite the gas
• Inconsistent flame heights or burner performance
• Fault codes or error messages displayed

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

This side-trim gasket seals the edge of the appliance door/trim to help maintain a clean fit and reduce rattling or light air leakage. It restores the door edge seal for a neater appearance and improved closing performance. What it does:

• Seals the door side trim to help reduce noise and prevent light air or moisture intrusion
• Helps maintain proper alignment and fit of the door trim for smooth opening and closing
• Replaces worn, torn or compressed trim gasket that can cause rubbing or gaps
• Supports overall door aesthetics by restoring a continuous seal line

• One side-trim gasket

• Basic trim removal may be required
• Inspect mating surfaces and remove old adhesive or debris before installing the new gasket
• Use gentle pressure to seat the gasket; avoid stretching or over-tensioning
• Disconnect power to the appliance before doing any service that exposes electrical components

This Wire is an OEM part for Bosch ranges. As an essential component of the appliance's electrical system, this wire ensures secure connections between various electrical components within the range. Its durable construction and precise design contribute to reliable power distribution and safe operation.

A common issue with a faulty Wire involves wear and tear over time, leading to wire fraying, exposure, or damage. Exposure to heat or physical strain can also compromise its integrity, potentially causing electrical malfunctions within the range.

Symptoms of a malfunctioning Wire may include:

• Inconsistent power supply to the range
• Non-functional heating elements or components
• Visible damage, such as fraying or exposed wires

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

This pressure regulator controls and stabilizes incoming water pressure to the appliance, helping maintain consistent operation and protect internal valves and seals. Fits systems that use a 3/4 inch inlet regulator. What it does:

• Reduces high incoming water pressure to a safe, steady level for the appliance
• Prevents pressure-related leaks, valve chatter, and premature wear on seals
• Helps maintain consistent water flow for reliable cycles and operation
• Commonly replaced when irregular pressure, humming valves, or water leaks occur

• One pressure regulator (3/4 in.)

• Turn off water supply and power to the appliance before starting; relieve system pressure first
• Inspect connection fittings and seals; use appropriate thread sealant if required by the OEM
• Tighten to manufacturer torque recommendations and check for leaks after restoring water

Solenoid valve controls the appliance's water inlet using an electrically actuated plunger to open and close flow. Replacing a failing valve helps restore proper filling and can stop leaks, overfilling, or no-fill conditions. What it does

• Electrically opens and closes the inlet to allow water into the appliance during fill cycles.
• Shuts off water flow when the valve is de-energized to prevent overfilling.
• Common symptom fixes: no water fill, continuous filling, visible leaks at the inlet, or related fill/flood error codes.
• Interfaces with the appliance inlet hose and the electrical connector for timed/controlled fill cycles.

• One solenoid valve.

• Disconnect power and shut off the water supply before starting any repair.
• Handle electrical connectors carefully; ensure correct orientation and a secure connection.
• Inspect and replace any worn seals, gaskets, or hoses to prevent leaks after installation.
