Parts for Thermador PSC366ZS: 28 - Standard Burner Parts

This replacement jet holder fits the 15,000 burner on gas cooktops and ranges. It supports the orifice and channels gas to the burner head, helping restore a stable flame and consistent heat when the original holder is damaged or corroded.

• Positions and secures the orifice for the 15,000 burner
• Routes gas from the valve/manifold to the burner head
• Helps maintain proper flame shape and output
• Replace if cracked, warped, or corroded; symptoms can include weak or uneven flame, yellowing, or difficulty lighting at that burner

• Shut off gas supply and disconnect power before servicing
• Remove grates, burner caps, and heads; raise or remove the cooktop surface to access the holder
• This holder is specific to the 15,000 burner position; transfer the orifice and any seals as required
• After reassembly, check all gas connections for leaks with a soap-and-water solution and verify burner operation

Used to hold down the jet holder assembly.

This compression sleeve forms the sealing ring for a 5/16-inch tubing compression joint, restoring a watertight connection when used with a matching compression nut and fitting. Ideal for stopping leaks and restoring reliable water lines. What it does:

• Creates the compression seal on 5/16" tubing when installed with a compatible compression nut and fitting.
• Stops leaks or drips at compression-style water connections.
• Used on appliance water lines (ice makers, water inlets) and other 5/16" tubing joints.
• Replaces worn or damaged sleeves that fail to hold a tight seal.

• Shut off the water supply and relieve pressure before working on water lines.
• Inspect and cut tubing squarely; slide the sleeve onto the tube before threading the compression nut and fitting.
• Tighten the compression nut per the fitting manufacturer's instructions and check the joint for leaks.
• Replace the sleeve if damaged or deformed.

This is a compression nut for 5/16-inch tubing. It secures the tubing to a compatible compression fitting to create and maintain a tight, reliable connection.

• Clamps 5/16-inch tubing onto a matching compression fitting when tightened
• Helps restore a secure seal at a leaking or loose compression joint
• Useful when threads are stripped, the original nut is cracked, or the connection won't hold tension
• Common signs include drips at the fitting, inability to tighten, or visible thread damage

• Shut off the supply and allow the system to depressurize before service
• Use appropriately sized wrenches; avoid overtightening to prevent damage
• Inspect the ferrule/olive and tubing end; replace if worn or distorted
• After installation, restore supply and check for leaks at the connection

This replacement tube restores proper routing for liquids or airflow in compatible appliances, helping maintain normal operation and prevent leaks or flow issues. It's a direct-fit part when your appliance requires the OEM tube. What it does:

• Replaces a worn, cracked, or damaged routing tube to stop leaks and restore proper flow
• Guides water, drain, or air where the original tubing was installed to maintain system function
• Helps prevent intermittent failures caused by pinched, split, or brittle tubing
• Matches OEM fit and routing to keep adjacent components aligned

• One replacement tube

• Verify the part number and orientation against the appliance diagram before installing
• Turn off power and water supply to the appliance before starting work
• Use appropriate tools and retainers; avoid kinking or over-bending the tube during installation

This replacement tray restores the original fit and support in your appliance. It provides a stable surface for items and replaces a damaged or missing tray to keep things organized and functioning as intended.

• Provides a secure surface to hold items where the original tray sits
• Restores proper fit so items don't tip, slide, or fall
• Direct replacement for a cracked, warped, or missing tray
• Helps ensure the section operates as designed once the tray is seated correctly

• Disconnect power if accessing internal areas or moving the appliance
• Remove the old tray and clean the supports/rails before installing
• Align with existing guides or tabs and press/slide into place until fully seated
• Verify a level, secure fit before loading items back onto the tray

This is a cooktop burner igniter OEM replacement part for Bosch cooktops and ranges and is sold as an individual part. This part creates a spark that ignites the burner within your cooktop or stovetop and is made of a combination of metal and ceramic.

Causes of a bad ignition plug can include issues with the electronic module, worn electrodes that no longer spark reliably, or damaged wiring.

Symptoms of a bad ignition plug include:

• Gas burners that will not light or remain lit
• Delayed ignition of one or more burners
• Intermittent or no sparking from the ignition plug

This OEM Bosch part is also compatible with Thermador, Gaggenau and some Kenmore models.

The Venturi Gas Tube is an OEM replacement part for Bosch gas cooktop ranges. Its primary function is to ensure an optimal gas/air mixture for consistent and efficient burner combustion, thereby enhancing the overall performance of the cooktop.

Causes involve normal wear of internal components from continuous heating and cooling cycles. Corrosion damage may also disrupt the venturi tube over time.

Symptoms of a faulty venturi gas tube include:

• Unstable or hard-to-control flame levels
• Potential issues shifting burner flames out of their intended position
• Safety risks including carbon monoxide from improper fuel/air balance

This OEM Bosch part is also compatible with Thermador, Gaggenau and some Kenmore models.

This panel insert is the replacement control-panel trim that restores a clean, finished look and protects the console area from scratches and wear. It fits into the console to cover and support the control surface. What it does:

• Replaces cracked, scratched, or cosmetically damaged control-panel trim
• Protects underlying buttons and electronics from everyday wear and spills
• Restores a uniform appearance to the appliance front for a like-new finish
• Helps ensure control buttons and labels sit correctly in the console area

• Disconnect power to the appliance before starting any repair
• Access may require removal of the console or outer door; follow the OEM service manual
• Handle the insert carefully to avoid scratches; align tabs/clips before applying pressure

This panel insert replaces a damaged or missing control-panel trim piece to restore the front appearance and support proper button alignment and sealing. It fits into the appliance's control area for a clean, finished look. What it does:

• Replaces cracked, faded, or otherwise damaged control-panel insert pieces
• Restores cosmetic finish and proper fit for control buttons and overlays
• Helps maintain a sealed control area against moisture and debris
• Prevents loose or misaligned panel edges that can interfere with operation

• Disconnect power to the appliance before starting any repair
• Handle edges carefully to avoid scratching or cutting; wear gloves if needed
• May require removal of the outer door or control bezel—use proper tools and follow the service manual
