Parts for Kitchenaid KMHC319EBS0: 05 - Air Flow Parts

This lamp cover is the replacement lens that protects and diffuses your oven's interior light, restoring even illumination while keeping the bulb shielded from heat and food residue. It helps maintain safe, usable oven lighting. What it does:

• Protects the oven light bulb from splashes, crumbs and direct contact.
• Diffuses the bulb for more even interior illumination.
• Replaces a cracked, cloudy, melted or missing lens that can cause dim or exposed lighting.
• Fits over the lamp housing to restore the oven's normal light appearance and function.

• Disconnect power to the appliance before starting and allow the oven to cool completely.
• Handle the cover carefully—wear gloves to protect from sharp edges or broken glass.
• Remove any retaining screws or clips, swap the old cover for the new one, then secure the retainer.
• After installation, restore power and replace the bulb if issues persist.

This oven temperature sensor senses cooking cavity heat and sends accurate temperature readings to the range control so your oven can reach and maintain set cooking temperatures. Replaces a failed or intermittent sensor for consistent performance. What it does:

• Detects oven cavity temperature and relays readings to the controller
• Helps the oven maintain set temperatures for proper cooking and baking
• Common fix when oven won't heat correctly or displays inaccurate temps

• One oven temperature sensor (W10557536)

• Disconnect power to the appliance before servicing to avoid shock
• Handle the sensor and connector carefully; avoid bending or crimping the probe
• Verify connector type and routing match your model before final assembly

The 40W Light Bulb is an OEM replacement part for Whirlpool microwave ovens. It is a standard-size bulb designed to provide illumination inside the microwave cavity, allowing you to easily view and monitor the cooking or reheating process.

Symptoms of a faulty microwave light bulb include:

• Dimming or flickering light during operation
• Complete bulb failure or no illumination within the cavity
• Discoloration or physical damage to the bulb itself

Causes of a bad microwave light bulb can include normal wear and tear over time, electrical surges or voltage fluctuations, or physical impact or vibration during use.

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore microwave oven models.

The Motor-Fan is an OEM part for Whirlpool ranges. This motor works with the lower convection fan to circulate heat underneath and throughout the oven cavity during the baking and broiling functions.

Causes of a bad motor can include normal wear over several years of continuous usage. Issues may also stem from dust or grease buildup inhibiting free fan rotation.

Symptoms of a bad motor-fan include:

• The lower convection fan not spinning or circulating air
• Improper or uneven cooking temperatures inside the oven
• Slower cook times compared to when new
• Possible smoke or burning of foods from poor air flow

This essential Whirlpool replacement is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore oven models.

This Charcoal Filter is an OEM replacement part for Whirlpool microwaves. The charcoal filter is responsible for improving the air quality in the kitchen by removing impurities and odors from the air. It is used to remove smoke, grease, and cooking odors as it is drawn up through the vent fan. By trapping these particles, the filter helps maintain cleaner air in the kitchen and prevents odors from recirculating and affecting the taste and smell of your food.

Causes of a bad Charcoal Filter include saturation from absorbing smoke and odors over time, accumulation of grease and particles that clog the filter, leading to decreased effectiveness, and physical damage that compromises its ability to filter air properly.

Symptoms of a bad Charcoal Filter include:

• Persistent odors in the kitchen after cooking.
• Smoke not being effectively vented out during microwave use.
• Reduced airflow from the microwave's venting system.

Replacing the charcoal filter at regular intervals or when these symptoms are noticed ensures that your microwave continues to operate efficiently and keeps your kitchen air clean. This OEM Whirlpool part can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

Description- Color: metallic. Measures about 5 inches wide by 5 inches deep.

The Fixed thermostat is an OEM component specifically designed for Whirlpool microwaves. This part plays an important role in regulating the internal cavity temperature during the cooking cycle.

Symptoms of a bad Thermost-Fix include:

• Food not heating evenly or completely
• Portions of food becoming overcooked while others remain cold
• Inconsistent or improper cooking at set power levels

Causes of a bad Thermost-Fix can include failure or damage of internal thermostatic components or sensors, electrical issues preventing proper communication, or obstructions interfering with temperature monitoring.

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This Light Housing secures and protects the interior lamp assembly, helping keep the compartment safely illuminated. Replace a cracked or heat-damaged housing to restore a stable bulb fit and consistent lighting performance. What it does:

• Provides a stable mount for the interior light bulb/socket
• Shields nearby wiring and components around the lamp area
• Helps position the light for proper illumination inside the compartment
• Common signs of wear: cracked or melted housing, loose bulb fit, lens/cover won't stay attached, intermittent lighting from a poor physical connection

• 1 light housing

• Disconnect power to the appliance before servicing
• Remove the lens/cover and bulb, then unfasten the damaged housing
• Transfer the existing socket, wiring, and any hardware from the old housing as needed
• Reinstall the housing, replace bulb/cover, restore power, and test the light

This air duct routes dryer exhaust air between the drum housing and the external vent to help proper airflow and safe venting. Replaces a damaged, cracked, or disconnected duct to restore consistent drying performance. What it does:

• Channels heated air from the dryer to the external venting system
• Helps maintain proper airflow to avoid long dry times and possible overheating
• Prevents lint buildup in inaccessible gaps when intact and sealed
• Reduces rattling or vibration caused by a loose or broken duct section

• Disconnect power (and gas, if applicable) before starting any repairs
• Remove the dryer rear panel or front assembly as required to access the duct
• Inspect mounting tabs and seals; replace or reseal to prevent air leaks
• Test dryer operation and check for proper venting and airflow after installation

This replaceable refrigerator water filter cartridge helps restore clear, better-tasting drinking water and ice by capturing sediment and common impurities. Designed for a quick swap to keep your fridge dispensing clean water. What it does:

• Filters sediment and particulate to reduce cloudiness in water and ice
• Helps improve taste and odor commonly associated with older filters
• Restores normal water flow and delivery when a clogged filter causes slow dispensing
• Supports routine maintenance to help prevent scale and buildup in the dispenser system

• Shut off the refrigerator water supply before removal to limit spills
• Follow the refrigerator manufacturer's removal/installation motion (push, pull, twist, or bayonet style)
• Flush several full glasses of water after installation to clear air and initial carbon fines
• Check for leaks at the filter and housing after restoring the water supply; discard the old filter per local regulations

This microwave magnetron is the high-voltage tube that generates the microwave energy to heat food. When it fails, the oven may run but not heat or heat very slowly. Replacing it restores normal cooking performance. What it does:

• Produces the microwave energy that heats food in the oven cavity
• A failed unit can cause the microwave to run but not heat
• Can create an unusual loud humming or buzzing during operation

• Includes 1 magnetron

• Unplug the microwave and discharge the high-voltage capacitor before servicing
• Handle by the mounting surfaces; avoid touching or damaging the antenna and ceramic insulators
• Reconnect high-voltage leads exactly as routed and reassemble cooling airflow parts; test with a cup of water to confirm heat
