Parts for Electrolux CPEF3077QFB: 02 - Backguard Parts

This door hinge cover shields and protects the refrigerator hinge area from dirt and damage while giving the hinge a finished appearance. Replaces a worn, cracked, or missing cover to restore proper fit and appearance. What it does

• Covers and protects the door hinge assembly from debris and accidental contact
• Helps maintain a finished look by hiding hinge hardware and mounting fasteners
• Prevents sharp edges from being exposed, reducing snag and scratch risk
• Commonly replaced when cracked, broken, or missing after impact or wear

• One door hinge shield

• Remove power and open the door before servicing to prevent injury
• Typically installs with a few screws or clips—retain original fasteners unless replacement specified
• Handle part carefully to avoid scratching painted surfaces; align shield before tightening

A rotary potentiometer used to adjust temperature/speed settings on compatible appliances. Replaces a worn or noisy control to restore smooth, responsive adjustment and reliable user control. What it does:

• Varies electrical resistance to change a control signal for temperature, speed, or other adjustable functions
• Restores crisp, consistent knob response when original control is loose, intermittent, or damaged
• Helps resolve symptoms like inconsistent temperature, unresponsive adjustments, or erratic control behavior
• Serves as the user-adjustable component in selector or control assemblies

• One potentiometer

• Disconnect power to the appliance before starting any repair to avoid shock or injury
• Access may require removing control panel or trim; keep fasteners and components organized
• Handle the part carefully to avoid bending terminals; ensure correct wiring and secure connections

This potentiometer is the user control variable resistor that lets the appliance vary a setting (speed, temperature or timer) from the front control panel. Replacing a faulty potentiometer restores responsive, smooth control. What it does:

• Converts knob rotation into an adjustable electrical signal for the appliance control
• Restores consistent setting changes when knob rotation previously produced no response
• Eliminates erratic or jumpy adjustments caused by worn or dirty contacts
• Used wherever a variable user input is required (e.g., temperature, speed, or timer control)

• Disconnect power to the appliance before starting any repair to avoid shock
• Access usually requires removing the control panel or console; keep track of screws and fasteners
• Note and label any wiring connections before disconnecting for correct reassembly

The Indicator Light is an OEM part for Frigidaire ranges. This light is designed to signal when the range or oven is in operation, providing a visual cue for safety and usability. It typically illuminates when the burners or oven are on, ensuring users are aware of active heating elements.

Causes of a bad indicator light can include electrical malfunctions, wear and tear over time, or damage from power surges or excessive heat.

Symptoms of a bad indicator light include:

• Light not illuminating when the range or oven is in use
• Flickering or inconsistent illumination
• Light staying on constantly, even when the range or oven is off
• Visible damage or discoloration of the light

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

This small protective cap covers and protects exposed appliance hardware, keeping dirt and moisture out while preventing accidental contact. It's a simple replacement that restores a finished appearance and helps maintain part integrity. What it does:

• Covers and protects an exposed shaft, tab, or fastener from debris and wear
• Helps prevent accidental contact with sharp or moving parts
• Restores the finished look of the appliance where the original cap was lost or damaged
• Simple, passive part—no electrical or mechanical function to reconfigure

• One replacement protective cap

• Always unplug the appliance or disconnect power before servicing
• Remove the damaged cap by hand or with a gentle pry tool; press the replacement into place until fully seated
• Small part—keep away from children and pets; loss is common during disassembly

This snap-in plug seals a small cabinet or component opening to keep out moisture, debris and pests while preserving a finished appearance. It's a simple, low-cost replacement that restores proper sealing and fit. What it does

• Seals unused holes or access openings to prevent water, dust and pests from entering
• Restores a finished look where trim or panels have a missing cap
• Helps stop rattles from loose openings and reduces airflow where needed
• Works as a direct-fit replacement when the original plug is damaged or lost

• One snap-in plug

• Remove surrounding trim or panel per your model's service instructions to access the opening
• Press the plug into the hole until it snaps fully into place; no special tools normally required
• Always disconnect power to the appliance before doing any service that requires panel removal

The Indicator Light Lens is an OEM part for Frigidaire ranges. This component covers and protects the indicator light, which signals when a burner or the oven is on, providing a visual cue for users to ensure safe operation.

Over time, the indicator light lens can become damaged or discolored due to heat exposure, regular cleaning, or accidental impacts. Causes of a bad indicator light lens include cracking, warping, or clouding that obscures the light.

Symptoms of a bad indicator light lens include:

• The indicator light not being clearly visible
• Cracks or breaks in the lens
• Discoloration or cloudiness that diminishes the brightness of the light
• The lens becoming loose or falling off

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

The Surface Element Control Switch is an OEM part for Frigidaire electric ranges and cooktops. It is a critical component that controls the operation of the surface heating elements, allowing you to turn them on and off, and select the desired heat settings.

Symptoms of a faulty Surface Element Control Switch include:

• Inability to turn on or control the surface heating elements
• Inconsistent or erratic heat output from the elements
• Elements not cycling on and off properly or staying on continuously
• Heating elements not responding to temperature adjustments

Causes of a bad Surface Element Control Switch can include electrical faults, physical damage, or wear and tear over time due to frequent use and exposure to high temperatures.

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

The Small Surface Element Switch is an OEM replacement part for Frigidaire electric ranges. It serves as the control knob and circuitry to safely power one of the smaller cooking elements.

Symptoms of a bad surface element switch include:

• Inability to ignite or regulate heating for its assigned zone
• Switch knob that feels loose, won't click smoothly, or won't stay set
• Intermittent or unreliable power to the smaller element coils
• Tripped circuit breakers upon use that don't reset

Causes relate to thousands of rotations wearing micro-switches and wiring terminals within the control assembly. Regular cleaning around knobs can prevent accelerated deterioration from baked-on debris conducting excess heat.

This genuine OEM replacement part is compatible with other brands including Electrolux and Kenmore as well.

The Large Surface Element Switch is an OEM replacement part for Frigidaire ranges and cooktops. It is a component that controls the power and temperature settings for one of the larger surface heating elements on the appliance.

Symptoms of a faulty Large Surface Element Switch include:

• Difficulty in adjusting or maintaining consistent heat settings
• The surface element not heating up or cycling on and off unexpectedly
• Flickering or erratic behavior of the surface element
• Burning smell or visible signs of overheating

Causes of a bad large surface element switch can include normal wear and tear, exposure to excessive heat or moisture, or electrical malfunctions.

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore range and cooktop models.

This truss-head machine screw secures a switch to its mounting bracket or panel. Replacing a worn or missing screw restores a solid, aligned switch fit for reliable operation.

• Fastens the switch body to a bracket or chassis panel
• Helps keep the switch aligned for consistent actuation
• Replaces stripped, corroded, or missing mounting hardware
• Common symptoms: loose or wobbly switch, misalignment, rattling or vibration around the switch area

• Disconnect power to the appliance before servicing
• Start threads by hand to avoid cross-threading; tighten snugly without overtightening
• Verify thread size and length match the original hardware
• If multiple screws secure the switch, replace them in a consistent pattern to maintain alignment

The control assembly is the appliance's electronic brain. It interprets user inputs and manages cycle timing and functions, helping restore reliable control when the original board becomes unresponsive, erratic, or displays error codes.

• Interprets keypad/knob inputs and sends commands to relays, motors, valves, heaters, and indicators
• Governs timing, temperature, and operating sequences for the selected cycle or mode
• Interfaces with the display/indicator lights for status and error reporting
• Common failure symptoms include unresponsive controls, blank or erratic indicators, won't start, stuck cycles, or recurring error codes

• Disconnect power at the breaker or unplug the appliance before servicing; verify power is off
• Use ESD precautions; handle the board by the edges and avoid flexing or touching components
• Access typically requires removing a console/front or rear panel; photograph wiring and move connectors one at a time to matching positions
• After reassembly, restore power and run a test/diagnostic cycle to proper operation

This is a replacement mounting screw used to secure the dual safety valve assembly on compatible gas ranges and ovens. It restores proper fastening so the valve stays firmly in place during operation. What it does

• Secures the safety/dual gas valve to the appliance chassis or manifold
• Prevents valve movement that can interfere with burner operation or alignment
• Commonly replaced when original screw is missing, stripped, or damaged
• Matches OEM thread size and length for correct fit and retention

• One (1) screw, size 10-16 x 0.486

• Disconnect power and shut off gas supply before starting work; follow all safety procedures
• Thread carefully to avoid cross-threading; do not overtighten — snug to OEM torque specification
• Inspect surrounding mounting holes and hardware; replace any stripped or damaged parts for a secure fit

Size: 6-20 x 0.312 inch.

The Screw is an OEM part for Frigidaire ranges and ovens. This part is designed to securely fasten various parts of the appliance, ensuring stability and durability.

Over time, screws can become loose due to the expansion and contraction of materials with temperature changes. Regular use and the occasional necessary removal for repairs or cleaning can also wear down the threads, making them less effective.

Symptoms of a bad Screw (Chrome) include:

• Loose or wobbly components that should be securely fastened.
• Difficulty in securing parts due to stripped or damaged screw threads.
• Visible corrosion or deterioration of the screw.

This OEM Frigidaire part can also be used on Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, and Sears/Kenmore.

Size: 8-18 x 0.5 inch. Color: Chrome.

The Screw is an OEM part for Frigidaire ranges and ovens. This part is designed to securely fasten various parts of the appliance, ensuring stability and durability.

Over time, screws can become loose due to the expansion and contraction of materials with temperature changes. Regular use and the occasional necessary removal for repairs or cleaning can also wear down the threads, making them less effective.

Symptoms of a bad Screw (Chrome) include:

• Loose or wobbly components that should be securely fastened.
• Difficulty in securing parts due to stripped or damaged screw threads.
• Visible corrosion or deterioration of the screw.

This OEM Frigidaire part can also be used on Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, and Sears/Kenmore.

Size: 8-18 x 0.5 inch. Color: Chrome.
