Parts for Jenn-Air JGRP748HM01: Burner Box, Griddle, And Grill Parts

This speaker module provides audible tones and chimes used by the appliance to signal cycle progress and user alerts. It restores clear sound feedback so you can hear cycle completion, alerts, and error tones. What it does:

• Produces the appliance's audible chimes, beeps, and alert tones
• Signals cycle completion and user prompts with clear sound
• Helps indicate error codes and status changes through audible alerts
• Interfaces with the main control to provide user feedback

• Disconnect power to the appliance before servicing to avoid electrical shock
• Handle the module and wiring harness carefully; avoid static discharge and bent pins
• Reconnect the wiring harness fully and secure the module in its mounting location
• Test the appliance after installation to ensure audible tones function correctly

This heater deflector directs heated air inside the dryer and protects nearby components from excessive heat, helping maintain proper airflow and reduce wear on internal parts. What it does:

• Shields the dryer cabinet and nearby components from direct heater/element heat
• Helps channel heated air for more even drying performance
• Can prevent heat-related damage that leads to component failure
• Common symptoms: burning or metallic smell, uneven drying, or visible heat damage near the heater area

• Disconnect power (and gas, if applicable) before beginning any repair
• Accessing this part usually requires removing the dryer cabinet or rear panel; follow your model's service instructions
• Handle carefully to avoid bending the deflector; install with original fasteners and correct orientation
• If you see damaged insulation or other heat-damaged parts, inspect and replace those items as needed

The Whirlpool screw is an OEM replacement part responsible for securing various components or parts on different types of Whirlpool appliances. The screw is designed to provide a secure and reliable fastening connection, ensuring that different parts of the appliance stay in place. It is commonly used in different locations within the appliance, such as the cabinet, panels, or other structural elements.

This part fixes the following symptoms:

• Loose or wobbly components within the appliance
• Panels or parts that are not securely attached
• Rattling or unusual noises due to loose parts
• Damaged or missing screw

The Whirlpool screw can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

The Range Screw is an OEM part for Whirlpool ranges. It is a small but essential component used to secure various parts and panels of the range. It is designed to fit securely into pre-drilled holes, holding components tightly in place.

There are a few factors that can lead to a bad Range Screw. Over time, screws may become loose or stripped due to frequent use or inadequate tightening. Accidental cross-threading or overtightening can also damage the screw or the surrounding components.

Symptoms of a bad screw may include loose or wobbly parts, rattling noises during operation, or difficulty in keeping components securely attached. This OEM Whirlpool part can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

The Drip Tray is an OEM component designed specifically for Whirlpool ranges. Located underneath the range's bottom heating elements, the tray collects moisture, melted cheese, or other baked-on messes during cooking. Its indented surface area and angled drainage grooves route debris toward an easily removed drip cup.

Causes of a bad drip tray can include scorched grease that accumulation makes thorough cleaning difficult or impact dents that cause leakage.

Symptoms of a bad drip tray include:

• Excessive residue buildup outside the designated drainage path
• Stains or water marks appearing on surrounding cabinetry
• Drip cup overflowing due to impaired drainage route
• Difficulty removing tray for cleaning of hardened messes

This OEM Whirlpool part is compatible with KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore wall oven and range models.

This yellow wire electrode connects the broil ignitor to the oven's ignition system so the broil burner can spark and light reliably. Replaces a damaged or brittle ignitor lead to restore consistent broil operation. What it does:

• Transfers ignition spark/current from the control to the broil ignitor so the broil burner can light
• Commonly used when broil fails to ignite, sparks are intermittent, or wire insulation is cracked or burned
• Serves as the low-voltage lead between the oven control/igniter and the broil element/ignitor assembly

• One yellow wire electrode (single lead) as pictured

• Disconnect power (and gas supply where applicable) before inspecting or replacing any ignition components
• Handle the electrode tip and connector carefully to avoid damage to the ceramic/insulator
• Route and secure the wire away from hot surfaces and moving parts; replace any damaged clips or insulation

Screws for range anti tip bracket: WP3801F656-51. Includes 2 screws.
