Parts for Kenmore 911.47744201 (91147744201, 911 47744201): Control Panel Parts

Fix F9 error codes and oven shutting off during baking. This control cooling fan motor keeps electronics cool and prevents overheating. 15-minute repair.

Oven won't unlock or shows lock error? This door lock position switch detects when the door is locked. Straightforward replacement restores lock function.

Protective cover that shields wiring at the top of your oven. Replace if cracked, broken, or missing to protect electrical connections and components.

Oven vent box assembly that routes hot air and steam from the cooking cavity. Replace if cracked, damaged, or missing to restore proper ventilation.

Duct vent inlet for wall ovens. Channels air from the oven cavity to the exhaust system. Replace if cracked, damaged, or broken to restore proper ventilation.

Vent tube for electric ranges and ovens. Connects oven cavity to exhaust system. Replace if cracked, broken, or missing to restore proper ventilation.

Conduit wire assembly for wall ovens. Routes electrical connections between components. Replace if wiring is damaged, frayed, or exposed.

8-32 thread screw fastens panels and components inside ranges, ovens, and cooktops. Replace stripped, missing, or damaged screws to secure covers properly.

Hex head mounting screw for ranges and ovens. Secures elements, panels, and internal components. Replace if stripped, missing, or damaged during repairs.

Replacement mounting screw for electric ranges, ovens, and wall ovens. Secures panels, brackets, and components. Replace if stripped, missing, or broken.

Replacement mounting screw secures panels, brackets, and controls on ranges and ovens. Needed when original screws are missing, stripped, or damaged.

Mounting screw for securing oven components and panels. Replace if stripped, corroded, or missing during appliance repair or maintenance work.

Mounting screw secures range components and panels. Replace if screw is stripped, missing, or damaged during appliance repair or maintenance work.

Black hex washer screw for securing range components like door trim, control panels, and internal brackets. Replace missing or stripped screws during repairs.

Range ground washer ensures proper electrical grounding. Prevents shock hazards and ensures safe operation. Quick 5-minute repair for most models.

This factory-style main lower wire harness connects the cabinet's lower electrical components so controls, motors and sensors receive power and signals. Replacing a damaged harness restores proper electrical routing and reliable operation. What it does:

• Routes power and signal connections between lower control components, switches and motors
• Restores electrical continuity when wires or connectors are damaged or corroded
• Helps stop intermittent power loss, unresponsive lower controls or component failures
• Keeps wiring organized and secured to prevent shorts or chafing

• Disconnect all power before starting work to avoid shock or damage
• Inspect connectors and routing; replace only if the harness and terminals match the original
• Handle terminals carefully and secure the harness to factory clips to prevent rubbing or strain
