Parts for Hot Point HTWP1400F2WW: Controls & Backsplash Parts

This left end cap is a molded replacement trim piece that restores the finished edge and appearance of the appliance door. It replaces a cracked, broken or missing cap to keep the door trim secure and looking original. What it does:

• Covers and protects the left edge of the door trim or hinge/handle end for a finished appearance
• Hides mounting hardware and helps keep the trim aligned
• Prevents sharp edges or exposed holes that can catch on clothing
• Common symptom: visible crack, broken corner, loose or missing end cap causing an unfinished look

• Install with basic hand tools; verify orientation for the left side before fastening
• Handle parts carefully to avoid scratching the finish during installation
• Disconnect power only if needed to access components near wiring — otherwise follow normal appliance safety practices
• If mounting hardware is missing or damaged, replace only with manufacturer-recommended fasteners

The Compression Ring is an OEM part for GE washing machines. This ring is essential for securing the tub within the washing machine, ensuring it remains in place during the wash and spin cycles. It helps maintain the stability and proper function of the washing machine.

You should replace the compression ring if it becomes worn, cracked, or damaged. Causes of a bad compression ring can include frequent use, high-stress loads during wash cycles, or physical damage, which can lead to instability and poor washing performance.

Symptoms of a bad compression ring include:

• Excessive shaking or movement of the washing machine during cycles
• Unusual noises during operation
• The washing machine tub appearing misaligned or loose
• Ineffective washing due to instability

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This dial assembly is the labeled control ring used on a washer's control panel. It restores clear cycle selection and secure indexing when the original dial becomes cracked, stripped, or unreadable.

• Provides the printed cycle/setting indicators and aligns with the knob for accurate selection
• Replaces a damaged or missing dial that wobbles, slips, or no longer shows settings
• Helps ensure your chosen cycle is indicated correctly on the panel
• Typical symptoms include a loose dial face, misaligned pointer, or difficulty selecting a cycle

• Disconnect power to the washer before servicing
• Pull the control knob straight off; remove any retaining clip if present
• Release the old dial's locking tabs and lift it away from the panel
• Align the new dial and press to lock in place; reinstall knob (and clip, if used)

This control knob assembly is the user interface for the timer/cycle selector on your washer. Replacing a cracked or stripped knob restores a secure grip and positive engagement so you can confidently choose wash cycles and settings. What it does:

• Attaches to the timer/cycle selector shaft to let you turn and set cycles
• Transfers rotation to the control without slipping when intact
• Helps maintain proper pointer alignment for accurate setting selection
• Common symptoms: knob cracked, loose, spins freely, falls off, or can't select/start cycles

• Includes: 1 control knob assembly

• Disconnect power before servicing
• Pull the old knob straight off the shaft; do not pry against the console
• Align the flat(s)/D-shape on the shaft with the knob insert and press until fully seated
• If your model uses a retaining clip, ensure it's properly positioned in the knob before installation

The Timer Knob Clip is an OEM part for GE washing machines. It secures the timer knob to the timer shaft, allowing users to set and adjust the washing cycle duration accurately.

You should replace the timer knob clip if it becomes worn out, broken, or lost. Common causes of a bad timer knob clip include regular use leading to wear and tear, physical damage from excessive force, or accidental breakage during maintenance or operation.

Symptoms of a bad timer knob clip include:

• The timer knob spinning freely without engaging
• Difficulty in setting or adjusting the timer
• The timer knob falling off or feeling loose
• The washing machine not starting or stopping cycles correctly

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This pressure switch senses the washer's tub water level and signals the control to stop filling and advance the cycle. Replacing a faulty switch restores proper fill levels and helps resolve overfilling, no-fill, and cycle-advance issues.

• Monitors water level via air pressure through the tub's pressure hose
• Signals the control to shut the inlet valves and begin wash/agitate or spin
• Helps advance the cycle once the target water level is reached
• Common failure symptoms include continuous filling/overfill, no fill or low fill, won't agitate/spin, or stopping mid-cycle with water-level errors

• Unplug the washer before servicing; turn off water supply
• Access the switch in the control console/top panel; move wire connectors to the new switch one at a time
• Inspect the pressure hose for kinks, cracks, or water in the line and seat it firmly on the new switch
• Run a test fill to ensure the water shuts off at the selected level

The Control Knob is an OEM part for GE washing machines, crafted to seamlessly integrate with your appliance. This knob allows users to select and adjust various settings, ensuring precise control over the washing machine's operations.

Signs that you might need to replace the Control Knob include it becoming loose, unresponsive, or breaking off, which can occur with age or from accidental damage.

Symptoms of a bad Control Knob include:

• The knob not engaging with the machine's settings, leading to difficulty in selecting wash cycles.
• A loose or wobbly knob that does not securely fit onto the washing machine.
• Visible cracks or damage that prevent the knob from functioning correctly.

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Knob Clip is an OEM part for GE washing machines and dryers. This small but crucial component is designed to secure the control knob to the appliance's control panel.

Over time, knob clips can wear out or break due to frequent use or accidental damage. When this happens, the control knob may become loose, fall off easily, or fail to engage the control panel properly, making it difficult to set the appliance to the desired cycle or function.

Symptoms of a bad Knob Clip include:

• The control knob is loose or falls off the panel easily.
• Difficulty in adjusting settings due to a loose knob.
• The knob does not stay in place or slips when turned.

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

Size: 8-18 b.

The Rotary Temperature Switch is an OEM replacement part for GE washers. This switch controls the temperature setting during wash cycles, accommodating various fabric types.

Causes of a bad rotary temperature switch can include wear and tear from frequent use, electrical failures, or damage due to moisture exposure. Over time, the internal components of the switch may degrade, leading to incorrect temperature settings or unresponsive controls.

Symptoms of a bad temperature switch include:

• Inability to select temperature settings
• Wash cycles running at an unexpected temperature
• Fluctuations in water temperature during the wash
• Constantly running hot or cold water into the tub

This OEM GE replacement part is compatible with Hotpoint, RCA, and some Kenmore branded washers as well.

The Washer Timer is an OEM part for GE washing machines. This part manages the sequence of operations during the wash cycle, including filling, agitating, rinsing, and spinning.

Causes of a bad washer timer can include electrical issues such as short circuits or power surges, wear and tear of internal mechanical components, and moisture infiltration leading to corrosion.

Symptoms of a bad washer timer include:

• The washing machine not advancing through cycles
• Cycles taking longer than usual or not completing
• The machine stopping mid-cycle or not starting
• Inconsistent or erratic cycle times

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This is a 8-18 x 1/2 inch hex washer head screw used to secure appliance panels and components. It provides a reliable, corrosion-resistant fastener for repair or reassembly tasks. What it does:

• Fastens panels, brackets or trim where an 8-18 x 1/2" screw is specified
• Hex washer head offers wider bearing surface to prevent pull-through
• Stainless finish resists rust and corrosion in humid appliance environments
• Restores proper fit and function when original screw is missing or damaged

• One 8-18 x 1/2 in. hex washer head stainless screw

• Use the correct driver/socket to avoid stripping the head
• Tighten securely but avoid over-torquing to prevent damage to plastic or thin metal parts
• Disconnect power and follow appliance safety precautions before working inside the unit
• Replace only with the same size and head style for proper fit

Harness to corset & shifter

This 10-18 Hi/Lo hex-washer screw is a direct-use replacement fastener for appliance panels, brackets and components. It restores secure mounting and helps stop loose trim, rattling or parts that shift during use. What it does:

• Secures panels, trim pieces, mounting brackets and similar components that use a 10-18 thread with a hex-washer head
• Restores proper fit where screws are missing, stripped, or corroded
• Helps eliminate rattling, vibration noise, and misaligned parts caused by loose fasteners
• Matches OEM head and thread style for a correct mechanical fit in specified locations

• Turn power or gas to the appliance off before working on electrical or gas-equipped units; unplug when applicable
• Use the correct sized hex driver or socket to avoid rounding the head
• Tighten until snug—do not overtighten to avoid stripping threads or damaging thin sheet metal
• If replacing multiple fasteners in a load-bearing area, replace all to ensure even fit and alignment

This hose clamp kit secures the washer's hoses at the pump, tub, or valve connections, helping stop leaks and hose blow-offs. Replace worn or missing clamps to restore a tight, reliable seal during fill, wash, and drain.

• Secures drain, pump, and fill hoses to fittings to maintain a watertight seal
• Helps prevent drips, leaks, and hoses slipping off during vibration
• Replaces clamps that are rusted, stripped, deformed, or missing
• Common symptoms: water leaking at hose joints, loose hose connections, clamp won't tighten
• Useful when installing a new hose, pump, or valve

• Unplug the washer and turn off water supplies; have towels or a pan ready for residual water
• Release and remove old clamps; seat the hose fully over the fitting before installing new clamps
• Tighten evenly and do not overtighten to avoid hose or fitting damage
• Restore power and water, then run a short cycle to check for leaks at each connection

The Water Inlet Fill Spout is an OEM replacement part for GE washing machines. It guides water from the inlet valve to the wash tub for a controlled flow. The fill spout is designed to reduce splashing and ensure that water is evenly distributed within the washing machine.

A bad Water Inlet Fill Spout can be due to cracks or damage from material wear, blockages caused by debris or mineral buildup, or issues with its connection to the inlet valve.

Symptoms of a malfunctioning Water Inlet Fill Spout include:

• Water splashing or leaking during the fill cycle
• Inefficient filling of the washing machine
• Visible damage or cracks in the spout
• Restricted water flow into the wash tub

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Triple Water Valve is an OEM part for GE washing machines. This part controls the flow of water into the washer, allowing for the precise mixing of hot, cold, and warm water necessary for different wash cycles.

Causes of a bad triple water valve can include mineral buildup or blockages from debris, electrical issues such as faulty solenoids, and wear and tear from frequent use.

Symptoms of a bad triple water valve include:

• The washer not filling with water or filling very slowly
• Incorrect water temperature during wash cycles
• Leaks from the valve area
• The washer not advancing through cycles properly

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Pressure Switch Hose is an OEM part for GE washing machines. It connects the pressure switch to the tub, allowing the switch to monitor the water level within the washing machine. This ensures the proper amount of water is used during each cycle for efficient washing and rinsing.

You should replace this pressure switch hose if it becomes cracked, clogged, or otherwise damaged. Common causes of a bad hose include wear and tear from repeated use, buildup of detergent or debris, and damage from improper handling or installation.

Symptoms of a bad pressure switch hose include:

• Washing machine not filling with water
• Overfilling or underfilling of the tub
• Inaccurate water level detection
• Error codes related to water level issues

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.
