Parts for Ge PSA22MIMCFBB: 01 - Door Kit Parts

This in-line water filtration system reduces water contaminants and improves taste of drinking water and ice. Reduces the taste and odor of chlorine through high quality carbon block media without removing minerals beneficial to your health. The filter should be replaced every six months or 300 galleons for best performance. The Quick Connect feature makes filter replacement fast and easy. Flow rate: 0.5 gpm/1.9 lpm. 1/4" quick connect fittings on both ends.

Black

This freezer door stop plate helps position and secure the door by limiting its swing, restoring proper alignment and preventing over-rotation that can cause gaps or rubbing. Simple replacement for worn or damaged stops. What it does:

• Stops the freezer door at the correct open/closed position so the door seals properly
• Prevents the door from swinging too far and rubbing or catching on the cabinet
• Restores consistent door alignment when the original stop is bent, broken, or missing
• Reduces wear on hinge and gasket areas caused by improper door travel

• One freezer door stop plate

• Disconnect power to the appliance before starting any repair to avoid injury
• Remove the freezer door or access panel as needed to reach the stop plate
• Use hand tools to remove/install mounting screws; align the plate before tightening to avoid misalignment
• Do not force parts; if mounting holes are damaged, assess bracket/hinge condition before finalizing repair

Black

Fresh food

Black

10-32 F HXW 3/4 S

Black

This top hinge assembly secures and guides the freezer door, restoring proper alignment and smooth opening/closing for refrigerators. Replace a worn or damaged hinge to stop sagging, rubbing, or uneven door gaps. What it does:

• Supports the freezer door at the cabinet top and keeps the hinge pivot aligned
• Allows the door to swing smoothly without binding or scraping
• Helps maintain an even door seal to improve closing reliability
• Addresses symptoms like door sag, uneven gaps, rubbing, or noisy hinge movement

• Disconnect power and empty or support the door before removing hinge hardware
• Use appropriate tools and have a helper to hold the door during replacement
• Reinstall hardware snugly and check door alignment and seal before restoring service
• If plastic trim or cap is present, handle carefully to avoid breakage

12-24 TT HX .811

12-24 CA HX 7/8 S

Package of 12

This kit is required when replacing the freezer door. For the freezer door order by model number.
