Frigidaire 137523400 Door Switch/Lock Kit OEM Part

Our Frigidaire front loading washing machine was purchased about 17 years ago. Subsequently, the door switch/lock set was redesigned requiring installing an upgrade kit 137523400 (AP5630665) involving removing the front lower panel and loosening the rear panel to provide needed access to install an adapter wiring harness. Installation of the upgraded harness to the switch assembly is color to color through the front lower panel. Watch the installation video for replacing the lock assembly and it will make your job far more simple. Remove all the perimeter screws from the back of the machine (this is not mentioned in the included instructions) and shift the back out enough to be able to complete the connection of the upgraded harness. Going in through the back of the machine is not mentioned in the included instructions. Then reassemble per the included instructions and you should be back up and running. The job is not difficult, just a bit time consuming. It worked out GREAT and surely it is FAR cheaper than buying a new front loading washing machine!

Tried getting the replacement latch, an inexpensive part, but the part was no longer available because the entire door lock and switch were modified for the purposes of replacement parts. So I ended up having to buy not only the latch but the door lock, switch, and new wire harness kit. $$$. The replacement parts were easy - no instructions necessary, but the new wire harness definitely required instruction to know how to hook up the wires. Fortunately the instructions that came with the kit provided sufficient detail to do the re-wiring. I had to do a lot of studying of the words they used to describe how things are connected, and there was a little bit of vagueness about one connection, but once I fully understood what the instructions were saying, everything went together right and it all worked when I turned it on. So everything worked out OK.

I looked at the schematic and flow chart which came with this six year old Kenmore front loading washing machine. It showed that if the light was on there should be current to the switch. Therefore it appeared to be a failure of the lock. I confirmed this assessment with a question to a technician at JustAnswer.com and the technician confirmed my diagnosis. He emailed a link to Appliance Parts Pros to my door lock kit and I made the purchase. I didn't use the entire kit, just the switch and it fixed the problem. My only problem using Appliance Parts Pros was that the shipment took a week to arrive. Applicance Parts Pros did apologize and credited me for the shipping charges.

Went on google and u-tube. Read about problem and saw video. I have an older Frigidaire front load Washer and old door latch was discontinued. But ApplianceParts Pro had a undated kit. ordered it followed instructions and now we have clean clothes. Took a week to get parts.
