This is a genuine replacement flat idler pulley used in snowblowers. The idler pulley applies tension to the belt, allowing the belt to turn. If the pulley is causing loud noises or is seizing up, which can cause the belt to break, a replacement may be necessary. A broken belt will cause a snowblower to be unusable.The process for replacing this part will vary depending on the model of the snowblower, so consult the equipment's manual and diagrams for specific instructions. For all replacements, a wrench and/or a socket set of the correct size depending on the machine is needed. Dependent upon the repair needed, bearings and bushings may also need replacement, they are not included and must be bought separately. This is a genuine MTD replacement part. This replacement flat idler pulley is compatible with Craftsman, Cub Cadet, Ryobi, Troy-Bilt, Yard Machines, MTD, Huskee, Montgomery Wards, Bolens, and Yard-Man brands.
Usually ships within 4 - 14 days
This replacement part is an idler arm assembly. It is a genuine replacement part made by MTD. Idler arm assemblies are meant to help the user steer and maneuver the appliance so that they can move in the desired direction. A new idler arm assembly might be needed if the current one is damaged or missing. These parts can become stripped over time and might need to be replaced. If the user is unable to steer the machine or appliance properly, the idler arm assembly might need to be replaced. Be sure to refer to the appropriate user manual for more information on how to replace this part. This part is a genuine OEM replacement part to ensure long-lasting use and proper fit. This idler arm assembly is sold individually and is sourced directly from the manufacturer.
This replacement part is a screw, and it is intended for use in different types of lawn equipment. This is a genuine replacement part made by MTD. This specific screw is typically found in snowblowers and is responsible for keeping different parts in place and secure. A new screw might be needed if any current ones are missing or damaged. After years of normal wear and tear screws can become stripped overtime and might need replacing. To replace this part the user should only need a common household screwdriver and possibly pliers if the screws have become wedged in an area. Overall this should be a fairly simple repair depending on the amount of new screws needed.This is a genuine OEM replacement part sourced directly from the manufacturer and is sold individually. Be sure the correct amount of screws are purchased as many machines require more than one to operate successfully.
This genuine OEM replacement part is an extension spring for a Craftsman snowblower idler pulley assembly. The idler pulley attaches to a part of the snowblower's housing and is helps to transfer energy throughout the belt drive. This extension spring helps to redistribute some of the back-and-forth motion created in the pulley as the snowblower runs. This keeps the assembly from shifting out of place and potentially slipping. This extension spring is attached at two points and, if pulled in both directions too far, can eventually lose some of its tension. When this happens, the idler assembly can begin to shake and even slip out of place. Replacing the extension spring is an easy job that will only require a socket wrench to remove the idler pulley. A pair of pliers may help to remove the spring from its clips. This part is only compatible with Craftsman snowblowers and is sourced from its original manufacturer. It ships individually and any additional parts needed will have to be purchased separately.
This carriage bolt is a fastener with a flat tip and a round head with threading along the shank. Also known as coach bolts and plow bolts, the item can be used with many types of lawn and garden equipment. This is a 5/16 carriage bolt that resists turning after the bolt has been tightened. Wear and tear or impact can cause damage to a carriage bolt and lead to the need to replace them.Removing a carriage bolt requires twisting the nut loose from the end of the bolt and then hitting the nut with a hammer. This will begin to move the shoulder out of the lawn equipment. Continue the process until the bolt is loose enough to remove. Installing a new carriage bolt simply requires sliding the bolt into the hole, adding the nut, and tightening things up.This carriage bolt is designed for use with Craftsman, MasterCut, Toro, Yard-Man, Cub Cadet, Montgomery Wards, Ryobi, Huskee, Troy-Bilt, MTD, and Yard Machines lawn and garden equipment. It can be used with lawnmowers, chainsaws, snowblowers, edgers, and tillers. This is a genuine OEM product sourced directly from the manufacturer as an individual component.
This part is a replacement auger shaft bearing housing. This is a genuine OEM part made by MTD and has been sourced directly from the manufacturer. This part can be used to replace a defective or broken auger shaft bearing housing in a variety of snow blower models. The auger shaft bearing housing is intended to cover and protect the equipment's hex bearing, which is located at the end of the auger shaft. This part will require replacement if corroded, dented, or damaged to the point of ineffectiveness. When working on or near an engine, it's important to ensure that the equipment is powered off and completely cool before beginning any repairs. For more accurate information on how and where to place this auger shaft bearing housing, the appropriate owner's manual and equipment diagrams should be referred to. As an authentic replacement part, this auger shaft bearing housing is suitable for use on snow blowers that have been manufactured by MTD, Craftsman, Troy-Bilt, and other brands. Please note that this is a genuine part made of high-quality, durable metal and is sold individually.
A carriage bolt is a type of fastener. It features a smooth rounded head and a square domed top. It has threading, which leads to up to the square shoulder. The purpose of its square is to prevent the bolt from spinning. Once the carriage bolt is inserted through the hole, using a nut and washer can provide additional security. Carriage bolts can corrode and loosen over time. Since it doesn't have a slotted head, a socket wrench is needed when replacing. This bolt carriage replacement is compatible with wood chippers, tillers, string trimmers, lawnmowers, and edgers. It is a genuine MTD product that measures 5/16x.075. It has a smooth rounded head and square shoulder underneath it. This carriage bolt is sold individually.
A flange nut's unique wide flange design distributes the nut's pressure over the part it is securing. In return, it creates an even fastening surface, which reduces part damage and nut loosening. This one-piece all-metal fastener has a lock nut version that features a protruding circular flange. This drastically increases bearing surface, compatibility either for irregular or oversized holes, and surface tension reduction. Flange lock nuts are the preferred type of fastener for many lawnmower models because it can provide better fastening than regular screws, which are known to loosen under extreme vibration. However, it’s important to know that flange lock nuts are susceptible to wear and tear due to constant vibration exposure. It is essential to replace the broken flange lock nut immediately to prevent serious damage to the lawnmower. The MTD 712-04063 Flange Lock Nut OEM replacement can be used with Craftsman, White Outdoor, Yard Machines, MTD, or Columbia lawnmowers. It is a genuine or OEM MTD replacement part that measures 5/16-18. It is threaded and requires the use of a wrench. This replacement flange lock nut is sold individually. An MTD bolt carriage may also be needed and is sold separately.
This is a self-tapping screw that can be used on a wide variety of lawn and garden equipment in many applications. A self-tapping screw is used to secure metal, wood, plastic, and brick together. When using a self-tapping screw, there's no need to drill a pilot hole since the screw makes its own hole. The only exception is with metal, which will still need a drilled hole before installation. There are many situations when a screw may need to be replaced. Some screws are damaged or broken, while others can become loose and no longer hold materials together. Screw heads can become stripped, which will also mean they need to be replaced. A visual inspection can often give an indication of whether you should replace a self-tapping screw. This is a genuine OEM hex head screw that can be used on various lawn and garden equipment, including wood chippers, lawn mowers, snowblowers, log splitters, tillers, edgers, and leaf blowers. It's compatible with products by MasterCut, Craftsman, Turf King, Cub Cadet, Yard-Man, Ryobi, Bolens, Troy-Bilt, Montgomery Wards, Murray, Huskee, Yard Machines, MTD, and more. This screw is sold individually.
This is a seven-inch cable tie that is used with different types of lawn and garden equipment. It is most commonly used to secure the cable onto the handle of the lawnmower or tiller so it is secure. The cable tie is made of durable plastic but can be damaged or break. When this happens, the tie will need to be replaced to ensure the cable stays on the handle.If the cable tie needs to be replaced, no tools are needed. In the situation where other parts need to be replaced at the same time, a basic set of tools and a pair of work gloves may be required. Turn off the yard equipment and place it on a stable surface before replacing the broken cable tie. The old tie can be removed so the new one can be installed before further use.This cable tie is an authentic OEM replacement part that is directly sourced from the manufacturer. This product is sold individually. The component is designed to be compatible with lawnmowers, lawn tractors, tillers, and snowblowers manufactured by MTD, Troy-Bilt, Yard-Man, and Yard Machines.
This is a flanged lock nut. It’s designed to apply tension, typically on a joint that needs to have a certain amount of flex. As such, it’s mostly used on snowblower chutes and lawnmower handles. They can remain in place, but with a forgiving connection that can take a beating. The nut size is 3/8, with a thread size of 16. A lock nut will generally last for many years. However, the silicone ring inside will wear down if it’s frequently tightened and loosened. It needs to be replaced when it will no longer reliably remain in place. Generally, this begins as a symptom of slight slippage and worsens as time goes on. Thankfully, whether it’s being used on a snowblower or a lawnmower, this nut is generally straightforward to access. Simply unscrew the old nut, then screw the new nut on until it’s nice and tight. Our flanged lock nuts are genuine OEM MTD nuts, and they are sold individually.
This genuine OEM replacement auger bearing flange fits a wide range of snowblowers. The auger is the part of a snowblower that scoops up and moves it away from the area being cleared. It is held in place by a bearing, and this flange connects to the bearing to reduce friction and motion. This flange helps prevent grinding, which would degrade the bearing and cause the auger to stop working effectively. Bearings and flanges receive a lot of wear and tear because they are built to absorb friction. Over the natural course of an appliance's life, bearings and flanges will normally wear down and need replacing. If a bearing flange snaps, the auger will no longer turn, and the snowblower will not move snow. To replace a bearing flange, use a socket wrench to gain access to the belt cover and then detach the auger housing. Remove the pulley and thread, then take the auger out of its housing. Pull out the old auger bearing flange and install the new part. This part is compatible with Yard Man, Troy-Bilt, Craftsman, Bolens, MTD, Huskee, and Yard Machines snow blowers. It comes sourced from the original manufacturer and ships individually.
This is a replacement skid shoe for Craftsman snowblowers. Ideally, when one shoe becomes so worn that it needs to be replaced, the other shoe should be replaced as well. Replacement is not difficult and should only require about half an hour. First, take out the key and disconnect the plug wire to prevent the machine from starting during repair. Remove the carriage bolts, nuts, and washers that hold the skid shoes in place. Replace the skid shoes. Ensure that the adjustable skids shoes are elevated enough that the snow blades will not collide with the ground during use. This will prolong the life of the shave plate. This OEM part fits a variety of different snowblowers made by Craftsman, Cub Cadet, Ryobi, Troy-Bilt, Yard Machines, MTD, Huskee, Montgomery Wards, Bolens, Yard-Man. Sold individually. The carriage bolts that hold the shoe in place may also need to be replaced and are sold separately.
This genuine MTD shave plate is located at the base of a snowblower augur. The purpose of a shave plate for a snowblower is to scrape away at packed or otherwise hard to clear snow and collect it into the augur, where it is then tossed out.The shave plate might have to be replaced within the standard lifespan of a snowblower. Signs of damage to a shave plate can include remaining packed snow on the ground that is not swept away by the snowblower or the inability of the augur to collect snow effectively. A in the form of dents, nicks, erosion, or punctures that can affect its efficacy. If the shave plate suffers from damage, it should be replaced with this genuine OEM replacement part. Remember to wear gloves when handling, repairing, and operating outdoor equipment. This is an OEM part sourced directly from the manufacturer. It is sold individually. This shave plate is compatible with the following brands: MTD, Craftsman, Cub Cadet, Yard Machines, and Yard Man.
The roll pin, also called a shear pin, is a slender metal piece that fastens the driveshaft to the auger of a snowblower. This pin actually does double duty as a safety device. When moving through the snow-covered ground where objects cannot be seen, sometimes the snow-moving auger will come into contact with something other than snow. Since the driveshaft of the blower will continue to turn regardless of the mobility of the auger, the auger would be destroyed or significantly damaged upon encountering such an object. The roll pin is designed to shear off when the auger suddenly stops so the working parts of the blower are not damaged. Most blowers are designed so that the pins are easily accessible. By rolling the blower so the belly plate is up, it is easy to remove the belly plate and see where the shear pin goes through the driveshaft and connects with the auger. The broken piece of the old pin can be forced through by the new pin by gently tapping it with a hammer. This OEM genuine replacement part is compatible with a number of snowblowers, including Craftsman, Troy-Bilt, MTD, Yard Machines, and Yard-Man.
This part is a replacement gearbox assembly. This is a genuine OEM part made by MTD and has been sourced directly from the manufacturer. If the current gearbox assembly is defective or broken, this part can be used as a replacement. It is intended for use with a variety of snow blower models.This gearbox assembly is what rotates the snowblower's blades inside the auger housing, making it an essential component. It will need to be replaced if jammed or faulty in any way. When working on or near an engine, always ensure that the equipment is powered off and completely cooled down before attempting to undergo any repairs. For more accurate information on how and where to install this gearbox assembly, the appropriate owner's manual and equipment diagrams should be referred to. This gearbox assembly is suitable for use on a variety of snow blower models manufactured by MTD, Craftsman, Troy-Bilt, and other brands. It is a genuine OEM part and thus is made of high-quality, durable metal. Part sold individually.
This replacement part is a spiral assembly. It is a genuine replacement part made by MTD. This spiral assembly is typically found in snow blowers and is responsible for the spinning or turning mechanisms inside the machine that allows the fan to run and blow out air. A new spiral assembly might be needed if the current one is damaged or broken in any way. If the blower is not working up to standard, it is also possible that the spiral assembly needs to be replaced. Be sure to reference the specific user manual for more details on how to install this new part. Working gloves are also recommended. This part is a genuine OEM replacement part. This assembly is sold individually and is sourced directly from the manufacturer to ensure a proper fit and long-lasting use.
Washers are used in various locations on many types of lawn and garden equipment and can help to keep a bolt or screw in place. The washer will also help to spread the load from connection, which can help to reduce the risk of damage. One of the most common reasons to replace a washer is if the current washer is lost. If the washer is corroded or if it has been bent or otherwise damaged, it should be replaced, as well. Replacing a washer is generally easy, but this can depend on the location of the washer that needs to be replaced. The authentic OEM replacement flat washer is sold individually. Having several of these available for future needs is a good idea. The washer can be used on snowblowers, lawn mowers, tillers, edgers, log splitters, chainsaws, and wood chippers. Compatible brands include Craftsman, Cub Cadet, Ryobi, Troy-Bilt, Husky, Murray, Yard Machines, MTD, Huskee, Montgomery Wards, Bolens, Yard-Man, Turf King, and MasterCut.
This replacement part is a flange bushing, and it is intended for use in different types of lawn equipment. This is a genuine replacement part made by MTD. This flange bushing is typically found in snow throwers but is compatible with other devices as well. The flange bushings are an important part of many appliances as they help reduce friction inside the machine. A new flange bushing might be needed if the current ones are broken or damaged in any way. It is common that different machinery needs multiple flange bushings. These small but important parts are placed around tubes or poles and are meant to assist during the rotating or sliding mechanisms. Be sure the machine is completely powered off and cooled down as the area with the bushings is often hot from friction. See the owner's manual for more exact instructions before attempting to replace this part. These flange bushings are sold as a set and are OEM replacement parts. These flange bushings are compatible with lawn equipment made by MTD.
This is a 28 inch, left-hand auger spiral assembly, made of metal, that is used in snowblowers. This sleek, helix-shaped auger is the part of the snowblower that draws the snow inside the machine so it can then be propelled elsewhere. As this is a left-hand auger, it rotates differently than a right-hand auger.With normal snowblower use, these parts can become worn or damaged. A common cause of a broken or bent auger is when a snowblower hits a rock or other hard object hidden under the snow. This causes the auger to be incapable of moving the snow into the housing and through the chute. When this happens, the auger must be replaced. To ensure that the snowblower works properly, augers should be inspected regularly and replaced when found bent or broken. Replacing the auger is a process that requires a few steps. Unplug the spark plug to disable the machine, then remove the belt covers, drive pulley, and lastly the auger. This part is sold separately and is a genuine OEM part. It is compatible with over 150+ machines, including select snowblowers made by Ryobi, MTD, and Yard Man.
This is a shear bolt, also known as a shear pin, which is used in many models of snowblowers. The shear bolt connects the auger shaft to the auger on the tool. This connection allows the augers to rotate, collecting snow and sending it to the impeller fan. Most snowblowers have at least one shear pin on each side of the auger gearcase. Large objects that get stuck between the housing and augers can damage the pins, necessitating replacement.If there is damage to the shear bolt or if it has broken, the snowblower may not work as expected. To replace the bolt, the snowblower should be turned off. Wear work gloves and remove the spark plug wire before disassembling the snowblower to reach the shear bolt. It can be removed and replaced with a new part.This is a genuine OEM replacement part that is sourced directly from the manufacturer. It is sold as an individual part. The shear bolt is designed for use with snowblowers created by Yard-Man, Yard Machines, MTD, Montgomery Wards, and Huskee.
This grease fitting attaches to the cast pivot bar on many types of garden and lawn equipment. It is made of durable metal and ensures that internal parts of the equipment are lubricated so they operate at their full potential. Sometimes a grease fitting can become worn damaged and need to be replaced.If a lawn tool no longer seems to be properly lubricated, the grease fitting could be the cause. A pair of pliers will be required to make the replacement. Clean the area near the grease fitting and then use a hex wrench to remove it from the machine. Take the new fitting and place it into the hole and tighten it before applying grease.This is a genuine OEM replacement grease fitting that is sourced directly from the manufacturer. The part is sold individually. The fitting is compatible with chipper shredders, lawn tractors, snowblowers, string trimmers, edgers, chainsaws, and lawnmowers manufactured by Yard-Man, Cub Cadet, Troy-Bilt, Craftsman, Ryobi, Murray, Broan, Yard Machines, Huskee, Montgomery Wards, Bolens, MasterCut, and MTD.
