Parts for Ge GSCS3PGXGFSS: 06 - Ice Maker & Dispenser Parts

Replace a cracked or jammed ice bin with this bucket and auger assembly. It stores the ice and uses the auger to move it toward the dispenser chute, restoring smooth, reliable through-the-door ice dispensing.

• Holds harvested ice in the freezer compartment
• Auger engages the drive to move ice toward the dispenser chute
• Helps restore consistent ice delivery through the door
• Typical symptoms: no ice dispensing, weak or intermittent dispense, cracked/broken bucket, grinding or clicking during dispense

• Unplug the refrigerator before servicing
• Empty the old bin and pull the assembly straight out
• Align the rear auger coupling with the drive and seat the assembly fully
• Briefly test the dispenser to confirm proper auger engagement

This helix lock plate secures the ice bucket auger (helix) in the dispenser assembly so ice can move reliably to the chute. Replacing a worn plate restores positive drive and helps reduce jams, slippage, and grinding noises. What it does:

• Locks the helix to the drive so the auger rotates under motor power
• Maintains alignment of the auger/helix stack inside the ice bucket
• Helps prevent slippage that causes weak or no ice dispensing
• Can help address symptoms like no ice dispensing, auger not turning, or loud clicking/grinding from the bucket

• 1 helix lock plate

• Unplug the refrigerator and remove the ice bucket before servicing
• Note the order and orientation of blades, spacers, and hardware during disassembly
• Transfer/install the plate in the same orientation; tighten fasteners snug, not overtight
• Crusher blades and edges are sharp—wear cut-resistant gloves

This is the rear motor cover used in select GE refrigerators. It shields the motor area at the back of the compartment, helping direct airflow and protect the fan/motor assembly for reliable cooling performance.

• Protects the motor/fan area from debris and damage
• Helps channel air correctly through the compartment
• Cracks, broken tabs, or missing cover can lead to noise, poor airflow, frost, or temperature swings
• Restores proper fit and finish inside the compartment

• Unplug the refrigerator before servicing
• Remove shelves/bins obstructing access; retain screws/clips
• Carefully release locking tabs and transfer any reusable hardware
• Ensure the cover seats fully and resecure all fasteners before powering on

This ice dispenser auger drive mounts on the dispenser motor shaft and engages the ice bucket auger. Replacing a worn or stripped drive restores the connection so your refrigerator can move ice smoothly to the chute.

• Couples the dispenser motor to the ice-bin auger to rotate and move ice toward the chute
• On models with crushers, also drives the crushing mechanism
• Worn or rounded splines can cause little or no ice dispensing even though the motor runs
• May produce clicking/grinding noises from the door during dispense
• Visible cracking or play at the coupling indicates replacement is needed

• Unplug the refrigerator and shut off water before servicing
• Remove the ice bin to access the dispenser motor shaft in the freezer door
• Note the orientation; remove the old drive and seat the new drive fully on the shaft, transferring any original hardware if present
• Reinstall the ice bin, restore power, and test ice dispense

This screw fastens appliance panels, brackets, and trim so parts stay secure and aligned. Replace a missing, stripped, or rusty screw to stop rattles and restore a tight, factory fit.

• Secures covers, brackets, and trim to the appliance cabinet or liner
• Replaces missing, stripped, or corroded hardware
• Helps reduce vibration noise and loose or misaligned parts
• Maintains proper fit of guards, kickplates, or internal panels

• Disconnect power; turn off water supply if working near water lines
• Match to the original fastener to size and thread
• Start threads by hand to avoid cross-threading; tighten snugly, not excessively
• If threading into plastic, avoid overtightening to prevent damage
