Parts for Dacor ER36GSCHNG: Manifold Parts

This single aluminum service valve is a sealed-system access valve used on compatible refrigeration systems to allow safe service, pressure checks and refrigerant charging. It provides a reliable access point without replacing major components. What it does

• Provides a sealed access point for refrigerant charging, pressure testing and diagnostic service
• Helps isolate the refrigerant line during repairs or evacuation
• Reduces the need to disturb larger sealed-system components when performing service
• Commonly used when addressing pressure/charge-related symptoms or performing routine diagnostics

• One single aluminum service valve

• Follow all refrigerant-handling regulations and use proper recovery equipment
• Depressurize the system and verify zero pressure before removing or installing the valve
• Inspect fittings and gaskets for damage and replace as needed to ensure a proper seal

This retaining ring secures the LED assembly in place, keeping indicator lights and display components stable for reliable operation. It's a small but important part that helps prevent loose or misaligned LED modules. What it does:

• Holds the LED assembly securely to the control/display area
• Prevents movement or rattling of indicator lights during operation
• Helps maintain proper alignment so LEDs remain visible and functional
• Can address symptoms like loose display trim, vibrating noises, or intermittently obscured LEDs

• Disconnect power before starting any repair to avoid shock or damage
• Handle the LED assembly and connectors gently to avoid breaking LEDs or wiring
• Use basic hand tools; avoid forcing the ring—align and snap into place per OEM guidance

This LED socket assembly restores the high-intensity indicator lighting used on select cooktops to show an active cooking zone. Replace a failed module to bring back clear, consistent illumination. What it does:

• Provides bright LED illumination for a cooking zone indicator
• Restores visual feedback that a burner/zone is in use
• Replaces a failed or damaged LED socket/module
• Common symptoms: no light, dim or flickering light, intermittent operation, or physical damage

• One LED socket assembly

• Disconnect power at the breaker before servicing
• Allow the appliance to cool and protect the glass surface while working
• Access the module from beneath the cooktop; match connector orientation and mounting position
• Test illumination before final reassembly
