Parts for Dacor ER36GSCHNG: Rear Assembly Parts

This broil burner assembly replaces the oven's upper-heat jet broil burner to restore broil function and reliable high-heat performance. Designed to fit specific Samsung gas ranges, it delivers concentrated heat for broiling and browning. What it does:

• Replaces the upper oven broil burner assembly that provides concentrated high heat for broiling
• Restores even browning and searing when the broil element is worn or damaged
• Commonly used when the broil flame is weak, uneven, or the burner will not light
• Works as the service replacement assembly for jet-style broil systems

• Turn off and disconnect power and gas supply before beginning any service
• Handle components carefully and follow the appliance manufacturer's service instructions
• Installation may require basic hand tools and removal of the oven interior or broil shield

This transformer supplies the correct voltage to power the halogen light inside the appliance. It steps down household voltage to safely operate the halogen bulb. Replace this transformer if the halogen light no longer turns on even with a good bulb, or if the light flickers intermittently.

Replace a convection motor if your oven heats unevenly or takes longer to cook. This motor drives the fan that circulates hot air for even baking.
