Parts for Jenn-Air JDS9860CDS02: 04 - Manifold Parts

A set of four valve mounting screws used to secure the water/ice valve or valve bracket in place. These OEM-style screws restore proper valve alignment and fasten valve assemblies for reliable operation. What it does:

• Secures the valve or valve bracket to the appliance chassis to prevent movement during operation
• Helps maintain a tight seal at valve mounting points to reduce risk of leaks
• Replaces missing, stripped, or corroded valve mounting fasteners
• Restores stable valve positioning that can prevent rattling or vibration

• Disconnect power and shut off the water supply before beginning any work
• Use the correct screwdriver or bit to avoid stripping the screw heads
• Thread screws in by hand first, then tighten snugly—do not overtighten to avoid damaging the valve or mounting threads
• If existing threads are damaged, inspect the mounting boss and replace as needed

This switch harness assembly connects the control panel switches to the appliance's main wiring, restoring reliable electrical connections for panel buttons and cycle selection. It replaces a damaged or worn harness to help regain consistent control response. What it does:

• Routes power and signals between the control switches and the main control board
• Replaces frayed, broken, or corroded wiring that can cause intermittent or no response from panel buttons
• Helps resolve symptoms like unresponsive controls, intermittent operation, or no-start conditions linked to panel wiring
• Maintains original connector fit and routing for correct switch function

• One switch harness assembly as shown

• Disconnect power (unplug or switch off breaker) before starting any work
• Handle connectors carefully and match connector shapes; do not force or modify terminals
• Verify routing and secure clips to prevent rubbing or pinching against moving parts

5K. Mueller

This mini burner valve controls gas flow to an individual cooktop/range burner, restoring proper ignition and flame control for affected burners. Designed as a direct-replacement service part for compatible gas ranges. What it does:

• Regulates gas flow to a single burner so the burner can light and hold a steady flame
• Commonly replaces valves that leak, stick, or fail to modulate flame size
• Used when a burner won't ignite, has uneven flame, or cannot be adjusted properly
• Works with the cooktop's ignition and safety systems to deliver controlled fuel to the burner

• One burner valve (mini)

• Turn off the gas supply and unplug the appliance before starting any work
• Use appropriate tools and replace any gaskets or fittings as needed; do not overtighten
• If you smell gas, stop work immediately, ventilate the area.

Size: 10-24X5/16-NI

This 4-spark ignition module controls the spark for gas burners so your cooktop or range lights reliably. It replaces a worn or failed module to restore consistent ignition and reduce click/no-spark issues. What it does:

• Sends timed spark to up to four burner electrodes for ignition
• Enables safe ignition sequence when burner control is turned on
• Helps eliminate symptoms like intermittent sparking, no spark, or continuous clicking
• Works with the range/cooktop's control system to coordinate ignition

• One 4-spark ignition module

• Disconnect power and shut off gas before attempting service
• Handle module and wiring harnesses carefully to avoid damage to connectors
• Verify proper electrode gap and burner alignment when reassembling

G4 orifice holder secures the gas orifice to the burner tube, keeping the orifice aligned for reliable ignition and a consistent flame. Replaces a damaged or worn holder to help restore proper burner flame behavior. What it does:

• Holds and positions the gas orifice in the burner tube for correct flame pattern and stability.
• Ensures consistent ignition and steady flame when the burner is operating normally.
• Common symptom indicators: burner won't light reliably, flame is weak or uneven, or burner performance is inconsistent.

• Turn off the appliance power and shut off the gas supply before beginning work.
• Inspect the orifice and burner tube for debris and proper alignment during installation.
• Tighten fasteners snugly but avoid overtightening; ensure the orifice is properly seated and oriented.
• After installation, check for correct ignition and perform a gas-leak check.

This orifice holder secures and positions the gas orifice at the burner, helping restore correct gas flow and consistent flame performance for compatible gas cooktop/range burners. Use it to replace cracked, warped, or missing holders. What it does:

• Holds the burner orifice in the proper position for accurate gas metering
• Helps maintain a steady burner flame and reliable ignition
• Replaces damaged or worn holders that can cause weak or inconsistent flames
• Works with surface burners and orifice assemblies where this holder is specified

• Turn off gas supply and unplug the appliance before servicing.
• Remove burner components and replace the holder with the matching OEM part.
• Inspect the orifice and surrounding tubing for damage; tighten fittings per manufacturer guidance.

The Whirlpool screw is an OEM replacement part responsible for securing various components or parts on different types of Whirlpool appliances. The screw is designed to provide a secure and reliable fastening connection, ensuring that different parts of the appliance stay in place. It is commonly used in different locations within the appliance, such as the cabinet, panels, or other structural elements.

This part fixes the following symptoms:

• Loose or wobbly components within the appliance
• Panels or parts that are not securely attached
• Rattling or unusual noises due to loose parts
• Damaged or missing screw

The Whirlpool screw can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.
