Parts for Maytag JGS9900CDS01: 04 - Manifold Parts

A set of four valve mounting screws used to secure the water/ice valve or valve bracket in place. These OEM-style screws restore proper valve alignment and fasten valve assemblies for reliable operation. What it does:

• Secures the valve or valve bracket to the appliance chassis to prevent movement during operation
• Helps maintain a tight seal at valve mounting points to reduce risk of leaks
• Replaces missing, stripped, or corroded valve mounting fasteners
• Restores stable valve positioning that can prevent rattling or vibration

• Disconnect power and shut off the water supply before beginning any work
• Use the correct screwdriver or bit to avoid stripping the screw heads
• Thread screws in by hand first, then tighten snugly—do not overtighten to avoid damaging the valve or mounting threads
• If existing threads are damaged, inspect the mounting boss and replace as needed

This small holder secures a local assembly inside compatible Whirlpool appliances to keep components aligned and stable during operation. Replacing a damaged holder restores proper fit and reduces noise or loose parts. What it does:

• Clips or seats a nearby component so it stays in the correct position during use
• Prevents rubbing, vibration, or misalignment that can cause noise or premature wear
• A cracked or missing holder can allow parts to shift, rattle, or come loose
• Simple, low-profile part used where a secure fit is required

• One holder ORF retainer

• Turn power off and unplug the appliance before servicing
• Access may require removing panels or trim—keep fasteners organized
• Inspect surrounding clips and mounts; replace any damaged hardware for a secure fit

This orifice holder secures the 5K gas orifice in place on compatible gas burners, keeping the orifice aligned for consistent flame performance and safe operation. It's a small but essential mounting component. What it does:

• Holds the 5K orifice firmly at the burner connection to maintain correct alignment
• Helps ensure consistent gas flow to the burner for steady, even flames
• A damaged or loose holder can cause a weak, uneven, or intermittent flame
• Works with the burner assembly to support reliable ignition and heat output

• One orifice holder (5K) as shown

• Turn off gas supply and power to the appliance before servicing
• Access may require removing the burner cap and grates or front panels
• Handle small components carefully; keep track of fasteners and orientation

This ORF holder is a small retainer that secures an ORF assembly in place, helping maintain proper alignment and reliable operation. Replaces a worn or broken holder to restore secure mounting and reduce rattling. What it does:

• Secures the ORF assembly or related component to prevent movement or misalignment
• Prevents rattling, vibration noise, and intermittent contact caused by a loose or damaged retainer
• Helps maintain proper fit so the related part can operate as designed
• Commonly replaced when the original holder is cracked, broken, or missing

• One ORF holder

• Disconnect power before servicing to avoid shock or injury
• Remove surrounding trim or panels carefully to access the holder without damaging adjacent parts
• Inspect mating surfaces and hardware; replace any damaged clips or screws as needed

This dual orifice holder secures two burner orifices in gas ranges, keeping the burner orifices aligned for proper gas flow and stable flames. It helps restore consistent ignition and even heat across affected burners. What it does:

• Holds and positions two burner orifices in the manifold or burner assembly
• Keeps orifices aligned to ensure proper gas flow to each burner
• Can resolve symptoms like weak, uneven, or inconsistent burner flames and ignition problems
• Works as a replacement for damaged, corroded, or bent orifice mounting hardware

• One dual orifice holder

• Turn off gas supply and electrical power before servicing; follow local codes
• Remove burner caps and access the orifice area per your model's service instructions
• Retain correct orientation when installing; avoid bending or stressing the orifice

The Top Burner Igniter is an OEM part for Whirlpool gas cooktops and ranges. This thin metal coil provides the spark to light the burner flames during startup. It is a spark electrode with a male spade connection.

Causes involve cracking of fragile ceramic insulator casings allowing moisture ingress, compromised electrical connections cutting off sparking ability, or general wear reducing spark output strength.

Symptoms of failure consist of:

• Inability to light one or more front gas burners
• Click sounds but no flame present when turning burner knob
• Safety issues arising from unlit gas accumulating

This is a genuine Whirlpool OEM replacement this part is also compatible with Maytag, Jenn-Air and some Kenmore models.

This wing nut is a hand-tightening fastener used to secure small appliance components for easy tool-free adjustment or removal. It offers a simple replacement when the original nut is lost, stripped, or broken. What it does:

• Secures panels, brackets, or components that require occasional removal or adjustment
• Allows tool-free tightening and loosening with built-in wings for finger grip
• Restores proper fit where a missing or damaged nut causes rattling, looseness, or instability
• Designed for repeated hand-operation without specialized tools

• Disconnect power to the appliance before performing any work to avoid shock or injury
• Thread by hand until snug; avoid overtightening to prevent stripping threads or cracking surrounding parts
• Inspect mating threads and replace if damaged to ensure secure fastening
• Use appropriate size and thread type—do not force a mismatched nut onto the stud

This pressure regulator controls and stabilizes incoming pressure so the appliance operates reliably and consistently. Replacing a faulty regulator restores proper pressure to the system and helps prevent performance issues. What it does:

• Regulates and holds incoming pressure within the appliance's required range for stable operation
• Ensures consistent flow to internal components that rely on correct pressure
• Can reduce symptoms like erratic or weak operation, inconsistent cycling, or pressure-related performance problems
• Helps prevent downstream component stress from overpressure

• One pressure regulator

• Turn off and disconnect electrical power and shut off the water or gas supply (as applicable) before starting
• Relieve system pressure and verify no flow before removing the old regulator
• Replace with the OEM regulator and tighten fittings to manufacturer torque specs; use thread sealant where specified by the manufacturer
• After installation, restore supply, check all connections for leaks, and test appliance operation.

This hot-surface oven igniter lights the gas burner so your oven reaches temperature reliably. Replacing a failed igniter restores consistent ignition and proper cooking for bake and broil cycles. What it does:

• Heats to a glowing temperature that ignites the oven's gas burner.
• Restores normal heating when a weak or broken igniter prevents the oven from reaching set temperatures.
• Common symptoms a bad igniter can cause: oven won't heat, very long preheat times, or burner fails to light.

• Disconnect electrical power and turn off the gas supply before starting any work.
• Handle the igniter carefully; avoid touching the ceramic/glass surface and support by bracket or wiring.
• Verify the connector and mounting pattern match your appliance before finalizing installation.

The Oven Igniter is an OEM part for Whirlpool ovens. It is responsible for igniting the gas to start the oven heating process. This igniter is crucial for ensuring that the oven reaches and maintains the desired temperature for baking and cooking.

Over time, the igniter can suffer from wear and tear, leading to inefficient ignition or complete failure. Causes of a bad igniter can include repeated heating cycles, electrical issues, or physical damage to the igniter element.

Symptoms of a bad igniter include:

• The oven not heating up or taking too long to preheat
• A noticeable gas smell due to incomplete ignition
•  The igniter glowing without igniting the gas

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This mounting nut secures the gas orifice to the burner valve assembly, keeping the orifice properly positioned for consistent burner operation. Replacing a worn or damaged mounting nut restores secure fit and reliable gas flow. What it does:

• Threads onto the orifice to hold the gas orifice in place on the valve assembly
• Keeps the orifice aligned to help maintain steady burner flame and ignition
• Prevents orifice movement that can cause inconsistent flame height or ignition issues
• Small metal fastener used where the orifice and valve meet on gas ranges and cooktops

• Turn off the appliance and shut off the gas supply before starting work
• Use the correct-size wrench and gentle force to avoid stripping threads
• Inspect mating parts for damage; replace if worn or cross-threaded

The Whirlpool screw is an OEM replacement part responsible for securely fastening various components and parts within Whirlpool appliances. These screws are essential for maintaining the structural integrity and safe operation of the appliance. These screws hold together critical components like panels, brackets, handles, and internal parts.

This part fixes the following symptoms:

• Loose or wobbly handles on refrigerators, ovens, or other appliances
• Vibrations or rattling noises during appliance operation
• Inability to assemble or disassemble parts during appliance repair or maintenance

The Whirlpool screw can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

Size: 10-24X5/16-NI

This burner baffle directs heat and flame away from sensitive components to help maintain even cooking and protect the range's internal parts. It's a direct-replacement trim piece used on compatible gas ranges and cooktops. What it does:

• Shields and redirects burner flame to reduce hot spots and protect nearby components
• Helps maintain more consistent surface temperatures during use
• Prevents flame impingement on adjacent parts that can cause discoloration or premature wear
• Supports proper burner operation by holding components in correct alignment

• One burner baffle

• Disconnect power and shut off the gas supply before starting work; allow all components to cool
• Basic hand tools are typically required; handle the baffle carefully to avoid bending or scratching
• Verify correct fit and orientation from the parts diagram before final reassembly

Size: 10-24X5/16-NI

This spark module controls ignition for four surface burners and provides automatic reignition if a flame goes out. It generates the high-voltage spark and monitors flame for dependable lighting and consistent cooktop performance.

• Generates high-voltage pulses to ignite up to four surface burners
• Senses flame presence and automatically re-sparks if a flame is lost
• Helps stop sparking once flame is detected to reduce clicking
• Symptoms this part is involved with include: no spark on any burner, intermittent or weak spark, or continuous clicking after lighting

• Disconnect power and shut off gas before servicing
• Access is typically under the cooktop or behind a panel; mount the module securely away from heat and moisture
• Transfer wires one at a time to matching terminals; ensure ground/neutral connections are secure for proper flame sensing
• After reassembly, restore power and test each burner for ignition and that clicking stops when flame is present
