Parts for Speed Queen ATEE9ASP176TW01: Motor / Belt Parts

This flow output control assembly routes 120 VAC power to the washer's flow/valve circuits so the machine can control water flow during cycles. It replaces a failed output module to restore proper electrical control of water-related functions. What it does

• Switches 120 VAC power to water flow/valve circuits under controller command
• Helps restore normal water fill and drain sequencing when the output is faulty
• Common symptom: washer fails to energize valves or show flow-related errors
• Works as the electrical output stage tied to the machine's flow control system

• One flow output control assembly (120 VAC)

• Disconnect power before servicing to avoid shock or damage
• Handle the assembly carefully; avoid bending pins or stressing connectors
• Confirm connector orientation and secure mounting before reapplying power

This 1 HP SVI control assembly is the drive/control module that manages motor speed and wash/dry cycles for compatible commercial washers. It replaces a worn or failed control to restore proper motor and drive operation. What it does

• Controls motor power delivery and speed for the washer's SVI drive system
• Coordinates drive commands with cycles so the machine advances through wash and spin stages
• Works as the electronic interface between user inputs/controls and the motor drive

• One 1 HP SVI control assembly (single module as shown)

• Disconnect power before servicing and verify machine is fully de-energized
• Handle the module by the edges and avoid static discharge; use ESD protection when available
• Installation requires access to the service panel and secure electrical/mounting connections; refer to the machine service manual

This poly-V belt kit replaces a worn or broken drive belt to restore power transfer from the motor to the washer/dryer drive system, helping the appliance resume normal spin and agitation. What it does

• Replaces the poly-V (serpentine-style) drive belt that routes over motor and idler pulleys.
• Restores proper drum or agitator rotation when belt wear, glazing, or breakage prevents spinning.
• Reduces slipping and squealing caused by a stretched or glazed belt.
• Works with the machine's pulley system to deliver smooth, reliable power transfer.

• Disconnect power (and water if applicable) before starting any service.
• Remove the access panel or cabinet to access the belt and pulleys.
• Inspect motor, idler, and drum pulleys for wear or damage and replace if needed before installing the new belt.
• Route the belt following the OEM belt routing diagram and verify proper tension before reassembly.

This Micro-V (multi-rib) drive belt transfers motor power to the machine's drive system so the tub/drum turns smoothly. Replacing a worn or broken belt restores consistent tumble/spin and reduces slippage, squealing, and burning-rubber odors.

• Transfers motor rotation to the drive pulley to turn the tub/drum
• Maintains traction across ribbed pulleys to minimize slipping under load
• Common failure symptoms: no tumble/spin, intermittent movement, squealing/chirping, or rubber smell
• Visual clues of wear: cracking, glazing, frayed ribs, or excessive stretch

• Disconnect power; shut off water and gas before servicing
• Note belt routing before removal; route over motor, idler/tensioner, and drive pulley
• Inspect idler, tensioner, and pulleys for wear or rough bearings and replace as needed
• After installation, hand-rotate to check tracking and alignment; run a short test cycle to verify operation

This motor and rod assembly replaces the drive motor and attached rod for compatible Speed Queen commercial washers, restoring agitation and spin force for normal wash cycles. It's a direct-fit motor kit designed for machines that use the Mamba 1/4 R configuration. What it does

• Replaces a worn or failed drive motor to restore agitation and spinning functions.
• Stops or reduces symptoms like no-agitate, no-spin, weak or intermittent agitation, or a humming motor with no drum movement.
• Eliminates excessive drive noise or vibration caused by a failing motor/rod assembly.
• Restores normal belt/drive engagement where applicable (helps re-establish proper mechanical linkage).

• One motor and rod assembly.

• Always disconnect power before beginning service to avoid electrical shock or injury.
• Basic hand tools required; installation may require lifting the cabinet or drum depending on model.
• Follow the machine's service manual for alignment, torque, and electrical connections.

This motor and rod assembly kit restores the drive components that power the washer's agitator or drum, helping return normal wash and spin motion for reliable cleaning performance. What it does:

• Replaces worn or failed motor and rod components that transfer power to the agitator/drum
• Restores agitation and spin functions when the washer won't agitate or spin properly
• Helps eliminate drivetrain noises caused by worn rod or motor coupling
• Works as the direct-drive linkage between the motor and wash basket for consistent cycles

• One motor and rod assembly kit

• Disconnect power before starting and follow the washer manufacturer's service instructions
• Basic mechanical skills and common tools are typically required; some models may require lifting the cabinet or removing the basket
• Inspect related components (mounts, fasteners, electrical connections) during replacement and tighten or replace as needed
