Parts for Speed Queen ATEE9ASP176TW01: Front Bulkhead / Air Duct / Felt Seal / Cylinder Parts

This front bulkhead assembly replaces the washer's front tub support and splash barrier, restoring proper drum alignment and helping prevent leaks. Built as a service-pack replacement to fit factory mounting points and finishes. What it does:

• Supports and aligns the washer drum and outer tub for smooth spinning
• Forms a splash barrier to help keep water inside the tub and away from controls
• Provides the factory mounting surface for door seal, bearing, and related components
• Helps reduce vibration caused by misaligned or damaged bulkheads

• Disconnect power and water supply before starting any repairs
• Drain the washer and remove the front panel or cabinet to access the bulkhead
• Keep track of gaskets, seals, and fasteners; replace any worn seals to prevent leaks

This moisture sensor base positions and secures the washer's moisture sensing contacts so the control can detect fabric dampness and finish cycles correctly. Restores reliable wetness detection when the original base is damaged or worn. What it does:

• Holds the moisture-sensing probes/contacts in the correct location for accurate wetness readings.
• Passes moisture detection signals to the control so automatic cycles advance and end properly.
• Helps address symptoms like inconsistent dryness, cycles that stop too soon or run too long, or error codes related to moisture sensing.
• Use when the mounting base is cracked, corroded, or connector fit is loose.

• Disconnect power to the appliance before starting any repair to avoid shock or injury.
• Access typically requires removing the washer cabinet or access panels; keep fasteners and connectors organized.
• Handle sensor contacts carefully to avoid bending or contaminating the probe surfaces; ensure connectors are fully seated.

This replacement moisture sensor bar mounts inside the drum and helps the dryer detect when laundry is dry. A worn or damaged bar can cause sensor-dry cycles to end too soon or run too long.

• Senses moisture on fabrics and signals the control to advance or extend auto-dry cycles
• Helps stop the cycle when clothes reach the selected dryness level
• Symptoms can include auto-dry cycles ending early, extended run times, or inconsistent dryness
• Build-up on the bars can also affect sensing performance

• Disconnect power before servicing; shut off gas supply for gas dryers
• Access the sensor at the front bulkhead/lint housing; move wire leads to the new bar and secure with existing hardware
• Clean any residue from both sensor bars to improve accuracy
• Reassemble and test with a small damp load on a sensor cycle

A clear silicone adhesive/sealant used to bond and seal appliance trim and components, helping restore watertight and stable assemblies. Supplies a durable, flexible hold for small repairs where factory adhesive is specified. What it does:

• Bonds trim, panels, and small plastic or metal parts to prevent movement and leaks
• Seals gaps to reduce water intrusion around housings and door areas
• Provides a flexible, durable hold that resists vibration and temperature changes
• Useful for reattaching trim, tabs, and molded parts when original adhesive has failed

• One (1) clear 3 oz tube of DOW 737 adhesive

• Use in a well-ventilated area; wear gloves and eye protection to avoid skin/eye contact
• Surface must be clean, dry, and free of oils or old adhesive for best adhesion
• Apply as a thin, even bead; allow recommended cure time before reassembling or using appliance
• Follow any OEM repair instructions and local disposal guidance for adhesive containers

This rubber rear drum seal fits the dryer drum opening and helps keep the drum centered while reducing air leaks and preventing lint and fabric from getting between the drum and bulkhead for quieter, more efficient drying. What it does:

• Seals the gap between the dryer drum and bulkhead to maintain proper airflow.
• Cushions the drum edge to prevent metal-on-metal contact and reduce noise.
• Worn or torn seals can cause rubbing, squeaking, banging, excess vibration, or longer dry times.
• Visible gaps, shredded rubber, or lint buildup at the drum edge are common signs the seal needs replacement.

• Disconnect electrical power (and shut off gas supply for gas dryers) before starting any repair.
• Replacement commonly requires partial or full drum removal; inspect the drum and bulkhead for additional wear while accessible.
• Wear gloves and eye protection; watch for sharp edges and pinch points during reassembly.

This seal kit restores a proper water-tight barrier in the washer's drive area to prevent leaks and protect bearings and motor components on 1992-and-newer units.

• Seals the drive shaft/tub interface to stop water migration
• Helps prevent bearing and motor damage from moisture
• Common leak symptoms: water under the washer, rust streaks at center post, noisy spin from moisture intrusion
• May also address oil/water contamination around the transmission area

• Disconnect power and water; move the washer to a stable, level work area
• Removal of agitator, inner tub, and drive components is typically required
• Inspect shaft and mating surfaces; clean and lightly lubricate as specified by service literature
• Use proper drivers/press tools; do not hammer seals into place

This white baffle cylinder is the replaceable tub/agitator baffle that helps move and separate laundry during the wash cycle for proper cleaning action. It restores agitation and water flow when the original baffle is worn or damaged. What it does:

• Channels water and works with the agitator/tub to help move clothes for improved washing action
• Helps reduce tangling and keeps items circulating through the wash zone
• Replaces cracked, broken, or excessively worn baffles that cause poor agitation or noisy operation
• Matches the original white finish for a factory appearance

• Disconnect power and water supply before beginning any repair
• Basic tools typically required; may need to remove agitator or access cap—refer to your model's service manual
• Inspect mating surfaces and fasteners; replace any worn hardware and ensure proper seating to avoid agitation issues

This is the rotating dryer cylinder assembly. Replacing a dented, rusted, or out-of-round cylinder restores smooth tumbling and helps prevent snags, noise, and uneven drying performance.

• Holds and tumbles laundry while working with the belt/drive system
• Internal white baffles lift and separate clothes for better airflow
• Smooth interior helps protect fabrics from catching or tearing
• Typical signs it's needed: loose or broken baffles, interior rust, dents, scraping/thumping once per revolution, or recurring fabric snags

• Disconnect power; for gas dryers, also shut off the gas supply
• Wear cut-resistant gloves—metal edges can be sharp
• Access typically requires removing the top/front panels and releasing belt tension; note belt routing
• Set drum, route belt correctly, spin by hand to confirm clearance, then reassemble and test

The Drying Rack is an OEM part for Speed Queen dryers. This part provides a flat, stationary surface within the dryer drum for drying items that should not be tumbled, such as shoes, hats, or delicate garments.

Common causes of a bad drying rack include physical damage from overloading, warping from exposure to high heat, or cracks and breaks from regular use over time.

Symptoms of a bad drying rack include:

• Items not staying in place during the drying cycle
• Visible cracks, bends, or breaks in the rack
• Difficulty fitting the rack securely in the dryer drum
• Unusual noises during the drying process due to a loose or unstable rack

This OEM Speed Queen part is also compatible with some Alliance Laundry Systems models.

This appliance screw replaces a missing or damaged fastener to secure panels and brackets. With a 10B-16 thread and 0.34-inch length, it restores a tight fit to help reduce vibration, rattles, and loosening.

• Fastens sheet-metal parts, brackets, and covers in the appliance cabinet
• Helps maintain alignment and support of components subject to vibration
• Direct replacement for stripped, rusted, or missing hardware
• Can help resolve symptoms like loose panels, rattling noises, or gaps

• Disconnect power; shut off gas/water as applicable before servicing
• Start threads by hand in the original hole or clip to avoid cross-threading
• Tighten snugly without overtightening to prevent stripping
• If the receiving clip/nut is damaged, repair or replace it for a secure hold

A replacement self-tapping screw used to secure plastic trim and sheet-metal panels on laundry equipment. Durable washer-head design helps distribute load and resist pull-through in plastic mounting points. What it does

• Fastens panels, trim pieces, and components where a short sheet-metal screw is required
• Self-tapping tip forms threads in plastic or thin metal for a secure hold
• Washer-style head spreads clamping force to reduce damage to plastic parts
• Common repair for missing, stripped, or broken mounting screws that cause loose panels or rattling

• One self-tapping screw (12-16 x 0.562 in) with hex washer head

• Use the correct screwdriver or low-torque driver to avoid over-tightening into plastic
• Start by hand-threading, then finish with short, controlled driver pulls
• Disconnect power and follow all safety guidance for the appliance before servicing
• Replace any damaged mating threads or inserts to ensure a secure repair

This air duct assembly routes airflow inside the washer cabinet to support proper ventilation and cooling of internal components. It replaces damaged or cracked ducts to restore directed airflow and reduce overheating risk. What it does:

• Channels air from the blower/fan to internal areas to help dissipate heat and control moisture.
• Prevents airflow leaks that can cause poor ventilation, unusual heat buildup, or increased drying times.
• Restores proper airflow paths that may stop intermittent fan noise caused by loose or broken ducting.
• Keeps dust and lint contained within the duct path to reduce buildup on sensitive components.

• One light-gray air duct assembly

• Disconnect power to the appliance before attempting any service.
• Remove access panels as needed to reach the duct; handle plastic parts gently to avoid cracking.
• Verify alignment and secure all fasteners; ensure ducts seat properly over blower or vent connections.
• Inspect and replace as needed for best results.

This lint filter captures lint and fibers from the drying airflow to protect the blower and vent path. Replacing a damaged or missing screen helps maintain airflow, reduce lint buildup, and keep drying performance consistent.

• Traps lint and debris as air circulates through the dryer
• Helps maintain proper airflow and drying efficiency
• Replace if mesh is torn, frame is warped/cracked, or the filter won't seat fully
• Common symptoms: longer dry times, lint on clothes or around the door, or a filter that pops out

• Disconnect power; for gas models, also shut off the gas supply
• Remove the old filter from the lint opening and vacuum any lint from the housing
• Insert the new filter fully so it sits flat and seals properly
• Never operate the dryer without the lint filter installed

This light gray lint filter cover shields the dryer's lint screen opening and helps direct airflow for efficient lint capture. Replace a cracked or missing cover to maintain airflow and reduce the chance of fabric snags.

• Covers the lint screen opening and channels air through the filter
• Helps keep the lint screen aligned and properly seated
• Provides a smooth edge at the door opening to protect fabrics
• Typical signs it's failing: cracks, broken tabs, loose lint screen, lint in drum, longer dry times

• Disconnect power before servicing
• Open the door; remove screws or release locking tabs to remove the old cover
• Position the new cover and secure it with existing hardware as applicable
• The lint screen slides in fully and seats flush before use

This felt pad cushions and isolates contact points inside the machine to reduce metal-to-metal contact, noise, and wear. Replace a worn or missing pad to help restore smoother, quieter operation and protect mating surfaces. What it does:

• Provides a soft, low-friction barrier between contacting parts
• Helps prevent squeaking, scraping, or rattling during operation
• Reduces wear at the specified contact point to protect components
• Visible thinning, glazing, or a missing pad can lead to noise and accelerated wear

• 1 felt pad

• Disconnect power (and gas/water, if applicable) before servicing
• Remove the old pad and clean the surface; align the new pad with the original footprint
• If adhesive-backed, apply to a clean, dry surface; reassemble and test for proper operation

This Rulon 488 cylinder glide supports the front edge of the dryer drum at the bulkhead. Replacing a worn glide restores smooth, quiet rotation and helps eliminate scraping or squealing from the front of the drum.

• Provides a durable, low-friction surface between the drum rim and front bulkhead
• Supports the drum to minimize drag and wear for quieter operation
• Worn glide may cause scraping/squealing noises or a dragging drum
• Visible flat spots, grooves, or excessive wear on the glide indicate replacement

• Disconnect power and shut off gas supply before servicing
• Access the front bulkhead and support the drum to relieve load on the glide
• Remove the worn glide and clean the mounting area; install the new glide in the same position/orientation per factory fasteners
• Rotate the drum by hand to inspect felt seals and any additional glides and replace if worn

The Glide Kit is an OEM replacement part for Speed Queen dryers. Designed for models manufactured in 1992 and later, this kit ensures the drum rotates smoothly during operation. It includes glide components that reduce friction between the drum and the dryer frame, allowing efficient and quiet performance.

Symptoms of a bad Glide Kit include:

• Squeaking or grinding noises during dryer operation
• Visible wear or damage to the glides upon inspection
• The drum becoming difficult to turn or feeling misaligned

Causes of a failing Glide Kit can include natural wear and tear over extended use, overloading the dryer, or improper alignment of the drum, which increases stress on the glides.

This OEM Speed Queen part is also compatible with Alliance laundry equipment.

This 120V light housing assembly secures and protects the interior light in your machine, restoring dependable illumination inside the cabinet. It positions the bulb and socket correctly so you can clearly see the drum/compartment when the door opens.

• Mounts and insulates the interior light socket within the cabinet
• Positions the bulb for proper interior illumination
• Helps resolve issues from a cracked, heat-damaged, or loose housing
• Typical symptoms: interior light won't turn on, flickers intermittently, or only works when the door is moved
• Designed for 120V systems

• Disconnect power before servicing to avoid electrical shock
• Access the light area per your model's service information; remove panels as needed
• Note wire locations; make secure connections to the new housing
• Restore power and test the interior light before final reassembly

A replacement low-profile Phillips screw used to secure panels and components on compatible laundry equipment. Provides a secure, low-profile fastening where a shorter head is required. What it does:

• Fastens trim, control panels, or small brackets where a low-profile head is needed
• Restores secure attachment when original screws are missing or stripped
• Helps eliminate rattling or loose panels caused by missing hardware
• Matches common #8 AB-18 x 1/2" thread and length for specified OEM fittings

• Use the correct Phillips screwdriver to avoid cam-out and head damage
• Start threading by hand to avoid cross-threading; do not force
• Tighten until snug—do not over-torque to prevent stripping the mating threads
• If threads are damaged, replace with an appropriate fastener or repair the hole before installing

This self-tapping screw secures panels and components on Speed Queen laundry appliances, restoring firm fastening and preventing rattles or gaps. Compact 8-18 x 3/8 size for use where a small, hex-washer-head fastener is required. What it does:

• Cuts its own mating thread in sheet metal or plastic mounting holes for a secure fit
• Holds control panels, trim pieces, and light brackets in place
• Replaces missing or damaged fasteners that cause loose or vibrating panels
• Helps restore proper panel alignment and reduces noise from loose parts

• Disconnect power before servicing the appliance
• Use the matching hex-washer driver or nut driver to seat the screw
• Start straight and apply steady pressure; avoid cross-threading
• Do not overtighten — snug until panels are secure

This genuine bracket secures a component inside your appliance cabinet, keeping it aligned and stable so the machine runs smoothly. Replace a bent, cracked, or stripped bracket to restore proper fit and prevent vibration, rubbing, and rattling.

• Provides a rigid mounting point for the specified assembly in your model
• Maintains correct position and spacing between parts
• Helps prevent vibration, rattling, and rubbing noises
• Replace if bent, cracked, or the mounting holes are stripped
• Common symptoms include loose/misaligned parts, unusual noises, or components not staying secured

• Unplug the appliance; shut off gas or water supply if applicable
• Support the attached component while removing fasteners
• Note orientation (take a photo) and transfer any clips/spacers from the original bracket if present
• Tighten fasteners evenly and verify alignment/clearances before use

This front bulkhead assembly replaces the dryer or washer front panel that supports the drum and front bearings, restoring proper drum alignment and enclosure. It helps reduce vibration, air leaks, and rubbing that can cause noise or wear. What it does:

• Supports the drum and front bearing to keep the drum centered during operation
• Provides the mounting surface for the door and front seal to maintain proper airflow and closure
• Prevents drum-to-frame contact that can cause squeaks, scraping, or excess vibration
• Helps keep lint and moisture contained in the drum area to protect internal components

• Disconnect power (and water, if applicable) before starting any repair
• Remove the dryer/washer door and front cover to access mounting fasteners; keep hardware for reassembly
• Transfer any door latch, seal, or trim pieces to the new bulkhead as needed
• After installation, recheck drum rotation and clearances; run a short test cycle to confirm quiet operation

This front bulkhead assembly replaces the washer's front tub support and splash barrier, restoring proper drum alignment and helping prevent leaks. Built as a service-pack replacement to fit factory mounting points and finishes. What it does:

• Supports and aligns the washer drum and outer tub for smooth spinning
• Forms a splash barrier to help keep water inside the tub and away from controls
• Provides the factory mounting surface for door seal, bearing, and related components
• Helps reduce vibration caused by misaligned or damaged bulkheads

• Disconnect power and water supply before starting any repairs
• Drain the washer and remove the front panel or cabinet to access the bulkhead
• Keep track of gaskets, seals, and fasteners; replace any worn seals to prevent leaks
