Parts for Frigidaire LCE772LL1: 03 - Motor And Blower Parts

Specs: 8 - 18 x 0.500

This wiring clip secures a refrigerator's wire harness to the cabinet or components to prevent chafing and keep wires organized. It helps maintain safe routing and reduces strain on electrical connections. What it does

• Holds wiring harness in place to prevent rubbing against sharp edges or moving parts
• Keeps wires organized to reduce the risk of pinching or accidental disconnection
• Helps prevent intermittent electrical faults caused by loose or strained wiring
• Commonly used near compressor, fan, control box, or rear cabinet areas

• Install by snapping the clip onto the cabinet flange or component and routing the harness through the retainer
• Disconnect power before accessing electrical components or wiring
• Inspect surrounding wiring and insulation; replace any damaged wire or harness tape before reinstalling the clip

Specs: 8 - 18 x 0.500

This wiring clip secures a refrigerator's wire harness to the cabinet or components to prevent chafing and keep wires organized. It helps maintain safe routing and reduces strain on electrical connections. What it does

• Holds wiring harness in place to prevent rubbing against sharp edges or moving parts
• Keeps wires organized to reduce the risk of pinching or accidental disconnection
• Helps prevent intermittent electrical faults caused by loose or strained wiring
• Commonly used near compressor, fan, control box, or rear cabinet areas

• Install by snapping the clip onto the cabinet flange or component and routing the harness through the retainer
• Disconnect power before accessing electrical components or wiring
• Inspect surrounding wiring and insulation; replace any damaged wire or harness tape before reinstalling the clip

The blower housing seal is a perimeter gasket that closes the gap between the blower housing and the adjoining duct or bulkhead. It keeps airflow contained for efficient operation and helps prevent air leaks and debris from escaping.

• Seals the blower housing joint to minimize air leakage
• Helps maintain proper airflow for consistent performance
• Reduces dust/debris escape into the cabinet or surrounding area
• Replaces torn, brittle, flattened, or missing seals that can cause weak air output or rattling

• Disconnect power; turn off gas supply before servicing.
• Access the blower housing; note the original routing/orientation of the seal.
• Remove the old seal and clean mating surfaces of lint and residue.
• Seat the new seal evenly with no gaps or twists; reassemble and verify airflow.

PPH ab st/z/ch `6 - 18x.60

This vane screw secures the internal drum baffle (vane) to the drum, keeping loads turning properly and preventing rattles or snags. Replace a missing or stripped screw to restore a tight, stable baffle during cycles.

• Fastens the drum baffle/lifter (vane) to the rotating drum
• Helps maintain proper tumble and load turnover
• Common symptoms: loose or wobbly baffle, rattling or clunking noises, items catching on a raised baffle edge, or a baffle that detaches
• Visual cues: missing screw or stripped/damaged threads at the baffle mounting holes

• Disconnect power before servicing; shut off gas
• Access the baffle from inside the drum; align holes and start the screw by hand to avoid cross-threading
• Tighten firmly but do not overtighten to prevent stripping the drum or cracking the baffle
• Start all screws before final tightening to seat the baffle evenly

This is a replacement fastening screw used to secure panels, trim or components on compatible appliances. It restores proper fit and helps eliminate loose or rattling parts for a safe, tidy repair. What it does:

• Secures panels, trims or small components in place
• Stops loose parts that can vibrate or rattle during operation
• Replaces missing or stripped screws that prevent components from seating correctly
• Helps maintain alignment of assembled parts to reduce wear or gaps

• Unplug or disconnect power to the appliance before starting any repair
• Use the matching screwdriver or driver bit to avoid cam-out and damage
• Install by hand until threads engage, then tighten snugly—do not overtighten
• If threads are damaged or the screw won't hold, replace with correct OEM part

This temperature control thermostat regulates your appliance's internal temperature by opening and closing the electrical circuit as conditions change, helping it reach and maintain the setting you select for consistent performance. What it does:

• Senses temperature and opens/closes contacts to control the system
• Helps maintain the set temperature by cycling the unit on and off
• Can lead to inconsistent temperature or a control knob that has no effect

• 1 temperature control thermostat

• Disconnect power before servicing; use proper PPE around sharp sheet metal
• Photograph wiring and transfer conductors one at a time to the new control
• Route it exactly as original and avoid kinks or sharp bends
• Set the control to mid-range after installation and allow the unit to stabilize before fine-tuning

A small metal mounting screw used to secure appliance panels and internal components. Simple replacement that restores proper fit and reduces rattling or loose parts when the original fastener is missing or damaged. What it does

• Secures panels, brackets, or trim pieces to the appliance chassis
• Holds internal components in place to maintain alignment and function
• Helps prevent vibration noise and movement from loose parts
• Suitable where the OEM listed screw size and thread match the original

• Disconnect power and water before servicing
• Use the correct screwdriver or driver bit to avoid stripping the head
• Start threads by hand to prevent cross-threading; tighten until snug—do not overtighten
• Keep any removed screws organized to ensure correct reassembly

This vane screw secures the internal drum baffle (vane) to the drum, keeping loads turning properly and preventing rattles or snags. Replace a missing or stripped screw to restore a tight, stable baffle during cycles.

• Fastens the drum baffle/lifter (vane) to the rotating drum
• Helps maintain proper tumble and load turnover
• Common symptoms: loose or wobbly baffle, rattling or clunking noises, items catching on a raised baffle edge, or a baffle that detaches
• Visual cues: missing screw or stripped/damaged threads at the baffle mounting holes

• Disconnect power before servicing; shut off gas
• Access the baffle from inside the drum; align holes and start the screw by hand to avoid cross-threading
• Tighten firmly but do not overtighten to prevent stripping the drum or cracking the baffle
• Start all screws before final tightening to seat the baffle evenly

This factory 8-18 screw secures appliance panels, brackets, and components. Replace missing or stripped hardware to restore a tight, rattle-free assembly and dependable operation.

• Fastens components to frames, brackets, and covers
• Replaces missing, damaged, or rusted screws
• Helps reduce looseness, vibration, and rattling noises
• Restores proper alignment of panels and assemblies

• Disconnect power before servicing; shut off gas/water if applicable
• Start the screw by hand to avoid cross-threading; use the proper driver
• Tighten snugly—do not overtighten to prevent stripping metal or plastic

Keep your dryer tumbling smoothly by restoring proper belt tension. This idler spring attaches to the idler arm and maintains tension on the drive belt so the drum turns reliably without slipping or squealing. What it does:

• Applies constant tension to the idler pulley to keep the drive belt tight around the drum and motor
• Helps resolve a drum that won't turn or tumbles intermittently
• Addresses belt issues such as slipping off, appearing loose, or premature breakage from low tension
• Can reduce squealing/chirping from the idler area caused by belt slip

• 1 idler spring

• Disconnect power; for gas dryers, also shut off the gas supply
• Access the idler assembly by removing the front or lower access panel per your model
• Relieve belt tension, unhook the old spring from the idler arm/frame, and install the new spring in the same orientation and holes
• Rotate the drum by hand to check smooth operation before reassembly

This factory 8-18 screw secures appliance panels, brackets, and components. Replace missing or stripped hardware to restore a tight, rattle-free assembly and dependable operation.

• Fastens components to frames, brackets, and covers
• Replaces missing, damaged, or rusted screws
• Helps reduce looseness, vibration, and rattling noises
• Restores proper alignment of panels and assemblies

• Disconnect power before servicing; shut off gas/water if applicable
• Start the screw by hand to avoid cross-threading; use the proper driver
• Tighten snugly—do not overtighten to prevent stripping metal or plastic

This block is a small mounting spacer used to secure and align components inside the appliance, helping maintain proper fit and operation. It replaces worn or broken mounting blocks to restore stable support and alignment. What it does:

• Provides a stable mounting surface or spacer between cabinet components
• Holds panels or assemblies in correct position to prevent rubbing or misalignment
• Helps reduce vibration or shifting of the connected parts during operation
• Commonly replaced when cracked, broken, or missing

• One mounting block

• High-level replacement; may require removing panels or trim to access mounting location
• Use appropriate hand tools and keep fasteners organized for reassembly
• Disconnect power before servicing any electrical components

Hex washer head ,10-32 x 0.375. Ground

This vane screw secures the internal drum baffle (vane) to the drum, keeping loads turning properly and preventing rattles or snags. Replace a missing or stripped screw to restore a tight, stable baffle during cycles.

• Fastens the drum baffle/lifter (vane) to the rotating drum
• Helps maintain proper tumble and load turnover
• Common symptoms: loose or wobbly baffle, rattling or clunking noises, items catching on a raised baffle edge, or a baffle that detaches
• Visual cues: missing screw or stripped/damaged threads at the baffle mounting holes

• Disconnect power before servicing; shut off gas
• Access the baffle from inside the drum; align holes and start the screw by hand to avoid cross-threading
• Tighten firmly but do not overtighten to prevent stripping the drum or cracking the baffle
• Start all screws before final tightening to seat the baffle evenly

This factory 8-18 screw secures appliance panels, brackets, and components. Replace missing or stripped hardware to restore a tight, rattle-free assembly and dependable operation.

• Fastens components to frames, brackets, and covers
• Replaces missing, damaged, or rusted screws
• Helps reduce looseness, vibration, and rattling noises
• Restores proper alignment of panels and assemblies

• Disconnect power before servicing; shut off gas/water if applicable
• Start the screw by hand to avoid cross-threading; use the proper driver
• Tighten snugly—do not overtighten to prevent stripping metal or plastic

No.8 pan head `10 - 10b x 0.50 `cr/sq drive

This vane screw secures the internal drum baffle (vane) to the drum, keeping loads turning properly and preventing rattles or snags. Replace a missing or stripped screw to restore a tight, stable baffle during cycles.

• Fastens the drum baffle/lifter (vane) to the rotating drum
• Helps maintain proper tumble and load turnover
• Common symptoms: loose or wobbly baffle, rattling or clunking noises, items catching on a raised baffle edge, or a baffle that detaches
• Visual cues: missing screw or stripped/damaged threads at the baffle mounting holes

• Disconnect power before servicing; shut off gas
• Access the baffle from inside the drum; align holes and start the screw by hand to avoid cross-threading
• Tighten firmly but do not overtighten to prevent stripping the drum or cracking the baffle
• Start all screws before final tightening to seat the baffle evenly

This is a replacement fastening screw used to secure panels, trim or components on compatible appliances. It restores proper fit and helps eliminate loose or rattling parts for a safe, tidy repair. What it does:

• Secures panels, trims or small components in place
• Stops loose parts that can vibrate or rattle during operation
• Replaces missing or stripped screws that prevent components from seating correctly
• Helps maintain alignment of assembled parts to reduce wear or gaps

• Unplug or disconnect power to the appliance before starting any repair
• Use the matching screwdriver or driver bit to avoid cam-out and damage
• Install by hand until threads engage, then tighten snugly—do not overtighten
• If threads are damaged or the screw won't hold, replace with correct OEM part

This vane screw secures the internal drum baffle (vane) to the drum, keeping loads turning properly and preventing rattles or snags. Replace a missing or stripped screw to restore a tight, stable baffle during cycles.

• Fastens the drum baffle/lifter (vane) to the rotating drum
• Helps maintain proper tumble and load turnover
• Common symptoms: loose or wobbly baffle, rattling or clunking noises, items catching on a raised baffle edge, or a baffle that detaches
• Visual cues: missing screw or stripped/damaged threads at the baffle mounting holes

• Disconnect power before servicing; shut off gas
• Access the baffle from inside the drum; align holes and start the screw by hand to avoid cross-threading
• Tighten firmly but do not overtighten to prevent stripping the drum or cracking the baffle
• Start all screws before final tightening to seat the baffle evenly

This vane screw secures the internal drum baffle (vane) to the drum, keeping loads turning properly and preventing rattles or snags. Replace a missing or stripped screw to restore a tight, stable baffle during cycles.

• Fastens the drum baffle/lifter (vane) to the rotating drum
• Helps maintain proper tumble and load turnover
• Common symptoms: loose or wobbly baffle, rattling or clunking noises, items catching on a raised baffle edge, or a baffle that detaches
• Visual cues: missing screw or stripped/damaged threads at the baffle mounting holes

• Disconnect power before servicing; shut off gas
• Access the baffle from inside the drum; align holes and start the screw by hand to avoid cross-threading
• Tighten firmly but do not overtighten to prevent stripping the drum or cracking the baffle
• Start all screws before final tightening to seat the baffle evenly

Blower wheel clamp

Restore visibility inside your appliance. This lamp assembly replaces a damaged or failed interior light so you can clearly see contents when the door opens, helping maintain safe, reliable illumination in the cabinet/drum.

• Provides interior illumination when the door opens or when the control calls for light
• Houses the bulb and makes the electrical connection
• Common symptoms: no interior light, flickering/intermittent light, or heat-damaged/burned socket or housing

• Disconnect power before servicing to avoid electrical shock
• Access the lamp from the interior or service panel per model
• Install a bulb with the correct type and wattage specified for your model
• Test light operation before reassembling panels

This factory 8-18 screw secures appliance panels, brackets, and components. Replace missing or stripped hardware to restore a tight, rattle-free assembly and dependable operation.

• Fastens components to frames, brackets, and covers
• Replaces missing, damaged, or rusted screws
• Helps reduce looseness, vibration, and rattling noises
• Restores proper alignment of panels and assemblies

• Disconnect power before servicing; shut off gas/water if applicable
• Start the screw by hand to avoid cross-threading; use the proper driver
• Tighten snugly—do not overtighten to prevent stripping metal or plastic
