The Lawn Mower Spindle Assembly is an OEM part for MTD lawn mowers Located in the mower's lower deck, the spindle assembly connects the blade to the drive belt. This enables the mower to cut grass effectively. This assembly is comprised of an adapter and a spindle. It gets activated as a pulley spins the drive belt. While designed to withstand minor impacts, larger or harder objects may cause damage. Damage can lead to blade misalignment or detachment.
You should replace the spindle assembly if it becomes damaged due to impacts with rocks, roots, or other hard objects, or if it wears out over time from regular use. A faulty spindle assembly can lead to uneven cuts, excessive vibration, and potential damage to other mower components.
Symptoms of a bad spindle assembly include:
This OEM part is compatible with various brands under MTD, including Cub Cadet, Troy-Bilt, Yard Machines, Bolens, and some Craftsman models.
Usually ships within 4 - 14 days
The Hex Head Self-Tapping Screw is an OEM part for MTD outdoor power equipment. This screw is designed to securely fasten components of your equipment, providing reliable and durable connections. The thread size is 5/16 inches for major diameter, with 18 threads. The screw is 3/4 inches long and has a hexagonal or six-sided head.
Over time, the Hex Head Self-Tapping Screw can become damaged due to corrosion, stripping of the threads, or wear from frequent tightening and loosening. This can compromise the integrity of the connections and potentially lead to equipment malfunction.
Symptoms of a bad Hex Head Self-Tapping Screw include:
This OEM replacement part is designed for use with various models of MTD outdoor power equipment.
This hex screw is an authentic OEM replacement part sourced directly from the manufacturer. It is used in many different applications in lawn and garden equipment and can be used on many different machines. If the hex screw is missing or loose due to deterioration, a new hex screw should be installed. Hex head screws are removed and replaced using a hex wrench. Screws are used to secure one part of a machine to another part. This hex head screw is not self-tapping, it is designed for pre-drilled holes. Most applications will require a washer and bolt to secure the screw, but there are applications where the screw is inserted into parts that do not have an opening on the other side and so the screw does not need to bolt. Wear gloves when working with screws and outdoor equipment. This hex head screw is made of hardened metal and is sold as an individual unit. This hex head screw can be used on many different model machines manufactured by MTD, Ryobi, Murray, YardMan, Bolens, Cub Cadet, and Husky.
There are multiple uses for the 5/16-18 Hex Screw. It is often used with small gasoline-powered yard equipment such as lawn and garden machines. While hex screws such as these may be used in edgers and snowblowers, the most frequent use this screw is in yard tractors. This variety of screw is commonly used in attaching the various appendages of gas-powered equipment to a central operating platform. In particular, these hex screws are used to secure the engine block of power tools to the frame or housing of the equipment. Once in place, these fasteners have an almost unbreakable strength to them. This is so much so the case that often, in order to detach the engine manifold and repair the inner workings of an engine, the bolts must be chiseled or cut loose. In such cases, it is necessary for the bolts to be replaced during reassembly. Manufacturers insist that genuine OEM replacement parts be used in the rebuilding process. These replacement parts were manufactured to the same exacting specifications used to make the original screws. These OEM screws are compatible with equipment made and sold by Yard-Man, Cub Cadet, Troy-Bilt, Husky, MTD, Bolens, and Yard Machines.
A hex screw fastens and holds two components together. It has a hexagonal head and features threading starting underneath the shoulder down to the tip. Its all-metal construction offers rigidity and longer lifespan. It is also threaded, so you can conveniently loosen or tighten in position. It measures 1/4-20 x 0.5 inch and comes in brass or gold color. Take note that this replacement hex screw may beused in different locations of a machine. Double check the device’s model number for compatibility. To install this hex screw, you will need a hex wrench or a hex socket. This hex screw is a replacement made by MTD. This screw/bolt may be used on lawn mowers, snowblowers, tillers, string trimmers, leaf blowers, edgers, chainsaws, pole pruners, log splitters, or wood chippers made by Craftsman, Toro, Cub Cadet, Ryobi, Troy-Bilt, Husky, Murray, Yard Machines, MTD, Huskee, Montgomery Wards, Bolens, Yard-Man, Turf King, or MasterCut. This OEM hex screw is sold individually.
This replacement part is a washer. This is a genuine replacement part made by MTD. Washers are small but important to many different types of machinery and appliances. These parts work with screws and nuts to hold certain parts together and secure during use. A new washer might be needed if the current one is no longer up to working standard. It is common for washers to become damaged or stripped over time due to normal wear and tear. If this is the case they should be replaced. Replacing a washer should be simple and only require common household tools. It is recommended that the engine be shut down before attempting to repair or replace any part within an appliance. This is a genuine OEM replacement part which ensures proper fit. This part is sold individually and is sourced directly from the manufacturer.
This self-tapping screw is used to attach various parts to the engine housing of medium sized gasoline powered engines, in particular yard tools such as tillers, snow blowers, yard tractors, riding mowers, power vacuums, shredders, and chippers. It is used in over 150 different gasoline powered engines. Screws such as these are used particularly when a device is going to receive a great amount of vibration and stress while the engine is running and rotating tools are engaged. Such devices sustain a great deal of wear over time and the parts subject to replacement will eventually fail and need to be replaced. In such cases, it is wisest to replace the attaching hardware such as housing screws as well, because it is a self-tapping screw. Screws of this type are designed to forge a tight bond between the metal pieces they are securing together, but once loosened, they should ideally be replaced with new hardware. Make sure when replacing these screws to use genuine OEM parts like these screws. These replacement parts are manufactured to be identical to the original pieces. This hex screw is compatible with the following brands: MasterCut, Yard-Man, Yard Machine, Montgomery Wards, MTC, Murray, Bolens, Craftsman, Turf King, Troy Bilt, Cub Cadet, Huskee, Toro, and Ryobi.
The replacement screw seen here is made from high-quality, durable metal. It is an identical replacement for a faulty screw in many types of lawn and garden equipment. The screw features a hex-bolt shaped head and is used for various applications in the machines. Owners will want to refer to diagrams of their model to ensure the correct application for the screw. A screw may need to be replaced for any number of different reasons. In some cases, the screw could become lost when making other repairs to the machine. It could also become bent or the threads could be damaged. Corrosion is also a possibility over time. Replacing the screw is typically considered a fast and easy repair. The screw is a genuine OEM replacement part that is sold individually. The screw can be used for many models of snowblower, lawnmower, chainsaw, tiller, string trimmer, log splitter, edger, and wood chipper. Compatible brands include Craftsman, Cub Cadet, Troy-Bilt, Murray, Yard Machines, MTD, Huskee, Montgomery Wards, Bolens, Yard-Man, and MasterCut.
This carriage bolt is a genuine MTD part, sold individually. This carriage bolt can be used as a replacement part in a variety of small engine outdoor appliances including lawn mowers, snowblowers, and chainsaws. The purpose of the carriage bolt for one of these outdoor appliances is to work in conjunction with a nut as a fastening component to affix metal to metal or metal to wood so that the parts remain attached to one another while the appliance is in operation.The carriage bolt in an outdoor appliance is a small component that can be easily lost or misplaced or can be damaged through general wear and tear over long-term use or as the result of an accidental collision with a hard object. If the carriage bolt is lost, misplaced, or sufficiently damaged as to not maintain the stable attachment of two or more components, the carriage bolt should be replaced by this genuine OEM replacement part.This OEM part is a genuine replacement that is sold individually and sourced directly from the manufacturer. This carriage bolt is compatible with the following outdoor appliance brands: MTD, Craftsman, Cub Cadet, Troy-Bilt, Yard Machines, Huskee, Yard Man, and MasterCut.
A flange nut's unique wide flange design distributes the nut's pressure over the part it is securing. In return, it creates an even fastening surface, which reduces part damage and nut loosening. This one-piece all-metal fastener has a lock nut version that features a protruding circular flange. This drastically increases bearing surface, compatibility either for irregular or oversized holes, and surface tension reduction. Flange lock nuts are the preferred type of fastener for many lawnmower models because it can provide better fastening than regular screws, which are known to loosen under extreme vibration. However, it’s important to know that flange lock nuts are susceptible to wear and tear due to constant vibration exposure. It is essential to replace the broken flange lock nut immediately to prevent serious damage to the lawnmower. The MTD 712-04063 Flange Lock Nut OEM replacement can be used with Craftsman, White Outdoor, Yard Machines, MTD, or Columbia lawnmowers. It is a genuine or OEM MTD replacement part that measures 5/16-18. It is threaded and requires the use of a wrench. This replacement flange lock nut is sold individually. An MTD bolt carriage may also be needed and is sold separately.
This is a flanged lock nut. It’s designed to apply tension, typically on a joint that needs to have a certain amount of flex. As such, it’s mostly used on snowblower chutes and lawnmower handles. They can remain in place, but with a forgiving connection that can take a beating. The nut size is 3/8, with a thread size of 16. A lock nut will generally last for many years. However, the silicone ring inside will wear down if it’s frequently tightened and loosened. It needs to be replaced when it will no longer reliably remain in place. Generally, this begins as a symptom of slight slippage and worsens as time goes on. Thankfully, whether it’s being used on a snowblower or a lawnmower, this nut is generally straightforward to access. Simply unscrew the old nut, then screw the new nut on until it’s nice and tight. Our flanged lock nuts are genuine OEM MTD nuts, and they are sold individually.
The nut-hex flange 5/8-18 features a hex nut with a wide flanged portion at one end. This flange will act as an integrated washer that does not spin. Since the flange acts as a washer, it ensures that the nut can fasten to the material's surface evenly. If any of these nuts are removed from a machine to do other work, it is recommended to replace them with a new nut-hex flange. Check the nuts that are currently on the machine at least once a year. Make sure they are properly tightened and that they are in good condition. Replace them as needed. This OEM part will work for many types of equipment, including lawnmowers, edgers, snowblowers, and lawn tractors. The part will work with many brands, including Ryobi, Poulan, Bolens, Yard-Man, MTD, Yard Machines, and Troy-Bilt.
This part is a replacement nut. This is a genuine OEM part made by MTD and has been sourced directly from the manufacturer. It is intended to replace a defective or lost nut in outdoor power equipment.Nuts help to secure different equipment components together properly. They will need to be replaced if corroded, stripped, lost, or unable to properly fasten together parts. Wear work gloves to protect the hands and check that equipment is powered off and cooled down before starting the repair process. For more accurate information on how and where to use this nut, the appropriate owner's manual and equipment diagrams should be referred to. This nut is a genuine OEM part made of durable metal and is sold individually. It is suitable for use with outdoor power equipment that have been manufactured by MTD, Craftsman, Troy-Bilt, and other brands.
A cotter pin is a small but necessary part found in many pieces of outdoor lawn & garden equipment and machinery. It is a type of split pin, which is a metal fastener featuring two tines that are bent during installation to fasten metal together. It designed for use especially with lawn tractors and is compatible with products by the following brands: MTD, Craftsman, Cub Cadet, Yard Machines, MasterCut, Bolens, Yard-Man, and Troy-Bilt.The low cost, availability, and extreme versatility of these cotter pins mean that they are used in countless machines nearly everywhere. Since this is a standard piece of hardware used frequently with lawn and garden equipment, it is important that the user refers to the appropriate diagrams of his or her unit to ensure the part is installed correctly.This cotter pin is a genuine OEM part sourced directly from the manufacturer, and it is sold individually. The manufacturer of this particular cotter pin is MTD.
This chute bracket is an authentic OEM replacement part sourced directly from the manufacturer for use on lawn mowers and lawn tractors to hold the discharge chute in place on the machine. The discharge chute directs the grass trimmings and debris out from under the lawnmower so that there is no buildup underneath the machine. If the bracket holding the discharge chute becomes loose, it may fall off during use, and the chute would then fall off the machine. Over time, the mower's vibrations may cause the screws holding the bracket to loosen and then come out, causing the bracket to fall off. If the bracket is missing, it should be replaced to ensure the discharge chute stays attached.Routine inspection of screws and nuts on the mower can prevent the bracket from falling off the machine. When replacing the bracket, make sure to keep the screws used to attach it to the lawnmower and reuse them to install the one. Make sure the screws are secure but not overtightened.This chute bracket is a metal part that is individually sold. It does not include fastening hardware. This bracket is designed for use on lawn mowers and lawn tractors manufactured by Troy-Bilt, Yard Machines, Yard Man, and MTD.
This extension spring attaches to the axle support bracket and the drive belt idler pulley on many types of lawn and garden equipment. It creates additional tension to the drive belt idler pulley. Sometimes the extension spring can be stretched out or may break, often caused through excess use. If this is the case, the spring will need to be replaced.If the spring is broken or no longer creates the appropriate amount of tension, replacement is required. It is an easy process that only requires a set of pliers. The pliers can be used to take the old spring off of the yard equipment before attaching the new extension spring. Make sure the equipment is on a stable surface and powered off when working with it. Remove the spark plug wire to prevent accidents.This extension spring is an authentic OEM replacement part sourced directly from the manufacturer. It is sold as an individual component. The spring is made to be used with lawnmowers, lawn tractors, and tillers created by MasterCut, Yard-Man, Bolens, Huskee, MTD, Yard Machines, Murray, Troy-Bilt, Cub Cadet, and Craftsman.
This cap pulley is a genuine MTD part that is manufactured for compatibility with lawn tractors. On a lawn tractor, the cap pulley, or pulley cap, along with the idler arm and idler arm spring, create tension on the deck drive belt which allows it to operate.It is normal for this cap to become worn over time. It is a relatively easy repair, but the deck of the mower must be removed. One of the biggest signs of a problem with the pulley is a squealing sound, although there may be no signs that it is wearing out until it breaks completely.This cap pulley is a genuine OEM part sourced directly from the manufacturer. It is sold individually. It is manufactured for compatibility with lawn tractors made by Bolens, Craftsman, Columbia, Huskee, Husky, Mastercut, MTD Gold, Murray, Yard Machines, and Yard-Man.
This replacement part is a torsion spring intended for use in lawn mowers. This is a genuine replacement part made by MTD. Torsion springs are used in many machines and are responsible for exerting a force that helps power the machine. The ends of any torsion springs are attached to other components and when these components move, the spring begins to replace them back to their normal position.A new torsion spring might be needed if the user notices that appliance is no longer working properly or will not start. The torsion spring might also be the issue if there are unfamiliar sounds coming from the inside of the machine. Be sure the appliance is completely powered down and cooled off before attempting to replace this part.This is an OEM part sourced directly from the manufacturer. It is sold individually. This replacement part is compatible with lawn mowers made by MTD.
This lock washer is used frequently for a number of applications on power yard equipment. The size, 5/16, is the default for many small engine housing and manifold applications. Lock washers are used with machined bolts to fasten engine blocks to the housing of the equipment being used. The compressed washer is able to handle the constant vibration of the small gasoline engine without losing the seal between the screw or bolt and the housing. Typically these lock washers only need to be replaced when they are misplaced during repairs or when the screws that attach them have to be chiseled or cut away, meaning the washers are destroyed as well. These OEM certified replacement washers have been manufactured to the same specifications as the originals they are replacing. In addition to lawn mowers, lock washers of this type and size are frequently used on blowers, lawn tractors, cultivators, snowblowers, and trimmers. Brands compatible with this type of washer are Murray, Husky, Poulan, Bolens, Yard-Man, Cub Cadet, Troy-Bilt, Yard Machines, MTD, and Ryobi.
This flat washer is used to attach the idler pulley in a number of small and medium sized gasoline powered engines. These engines include snow blowers, log splitters, riding mowers, lawn tractors, and chippers. Because the idler pulley is subject to a great deal of resistance when the pulley is engaged, eventually the pulley will wear out. Should there be a squealing sound when engaging the drive, the problem is likely the idler pulley. In these cases, the pulley must be replaced. It is a good idea to replace the surrounding hardware when replacing the idler pulley; tNhis includes the flat washer, which is subject to corrosion during heavy use. To replace the idler pulley, first detach the spark plug cap. If on a mower or tractor, drop the mower deck. Remove the original pulley and install in order: replacement pulley, hex bolt, flat washer, flange nut. Apart from dropping the mower deck, the only tools required to complete this installation may be a 9/16 ratchet and combination wrench. This washer is a genuine OEM replacement part, designed to perfectly replicate the original piece. This washer is compatible with Troy-Bilt, Yard Man, Yard Machines, MTD, and Craftsman devices.
This deck lift pivot cup is an authentic OEM replacement part sourced directly from the manufacturer for use on riding lawnmower decks. This pivot cup separates the hex lock nut and the lift arm so that the arm can move freely while being secured to the deck. If the pivot cup is damaged or broken, the lift arm would not be able to move, and the deck would not be adjustable up and down. Regular maintenance and inspection will reveal problems with parts like the pivot cup, which can then be repaired. If the deck is not moving freely, the pivot cup should be checked and replaced if necessary. Park the mower on a flat surface and take the spark plug out for safety. Remove the deck mower and remove the blades. Locate the lift arm and the hex nut. Remove the hex nut and set it aside. Remove the damaged pivot cup and then insert the new one. Replace the hex nut and tighten it. Reverse the process to reassemble the lawnmower. This deck lift pivot cup is a metal part that is sold as a single unit. It is designed for use on lawn mowers and lawn tractors manufactured by MTD, Murray, and Craftsman.
This is a genuine replacement shoulder screw that is compatible with select models of lawn tractors. The shoulder screw has multiple applications in lawn tractors, where it is typically used as some kind of axle for wheels or other components. Over time, this type of screw can become worn from repetitive motion or the threads can start to strip. If the screw fails or is unable to work effectively, it can affect whatever it is responsible for securing or holding, as well. This could result in the entire machine not working until a replacement is made. This is a genuine manufacturer's replacement manufactured by MTD. It is compatible with their lawn tractors as well as those from Yard Machines, Troy-Bilt, Yard Man, Husky, and Cub Cadet. The screw is made of durable metal and is sold as a single unit. This is considered specialty hardware and is also sometimes referred to as a shoulder bolt.
This is a two in one blade that can be used as a lift blade to bag clippings, as well as a side discharge for clippings. It is time to consider replacing this blade when there are uneven or even missed areas of cutting or bagging when using the mower. It may be that the blade has been dulled by prolonged use or bent or damaged by striking rocks and dense roots. Either way, replacing the blade is a relatively easy repair to make and should be considered a part of routine maintenance. The repair requires the use of the proper tools, including wrenches and sockets. An appropriate flange bolt may need to be purchased as well if the original has been damaged or worn. "This OEM replacement cutting blade works with more than 150 types of tractors and mowers made by Craftsman, Yard Machines, Yard-Man, MTD, and Troy Bilt. This ships singly and is a high-quality blade made of durable materials.
This is a flat washer that can be used with bolts and screws on many kinds of lawn and garden equipment. Before a bolt can be fastened to a surface, a fastener needs to be inserted through the end. A washer can be used with these items to help distribute the load. Washers are also responsible for decreasing heat and friction while a fastener is tightened to a surface. Washers can also be used to offer electrical insulation or operate as spacers.Even though washers are made of durable materials, they can be damaged over time. If the shape of the washer is bent or cut in half, this indicates that it needs to be replaced. A socket wrench or screwdriver can be used to make the replacement. Remove the screw or bolt, remove the fastener, and add the washer to the fastener before it screws back in.This flat washer is a genuine OEM replacement part sourced directly from the manufacturer. It is compatible with lawnmowers, wood chippers, snowblowers, log splitters, tillers, chainsaws, and edgers by Craftsman, MasterCut, Cub Cadet, Turf King, Ryobi, Bolens, Husky, Montgomery Wards, Murray, Huskee, Yard Machines, and MTD. It comes as an individual part.
This replacement part is a torsion spring and is intended for use in different types of lawn equipment. This is a genuine replacement part made by MTD. This spring is found in different types of lawn mowers and is able to assist other parts working together to allow the engine to run properly and smoothly. Though this spring is small it is an important part of many machines.A new torsion spring might be needed if the current one is damaged or missing. Because of the nature of the spring, it is not unusual for it to become stripped or snapped due to normal wear and tear within the machine. Unusual noises may come from inside the machine if the torsion spring is not working properly. This torsion spring is sold individually and is sourced directly from the manufacturer to ensure proper fit. This is a genuine OEM replacement part.
This engagement bracket is a genuine MTD part designed for lawn tractors. On most models, this engagement bracket is installed on the top of the lawn tractor. It usually works with the blade engagement cable.This engagement bracket is a genuine OEM part sourced directly from the manufacturer and is sold individually. Like many metal parts that are exposed to open air and elements, the engagement bracket may become worn over time and need to be replaced. If replacing the blade engagement cable, it is a good idea to also replace the bracket.This engagement bracket is compatible with lawn tractors manufactured by Brute, Craftsman, Columbia, Huskee, Husky, Mastercut, Mtd Gold, Murray, White Outdoor, Yard Machines, and Yard-Man between 2010 and 2014. It may also be compatible with lawn tractors manufactured by Cub Cadet and Troy-Bilt.
