Parts for Kitchenaid KCMC155JBL0: 02 - Oven Interior Parts

This baseless light bulb restores the washer drum light so you can clearly see inside during loading and unloading. Replace a failed lamp to regain visibility and help prevent small items from being missed. What it does:

• Illuminates the washer drum when the light feature is activated
• Replaces a burned-out or damaged baseless lamp in the drum light assembly
• Common symptoms: light won't turn on, flickers intermittently, or the bulb appears darkened/broken
• Helps you check for remaining items after a cycle

• Includes 1 baseless light bulb

• Disconnect power to the appliance before servicing
• Allow the old bulb to cool completely before handling
• Access the drum light housing; pull the old bulb's leads straight out and insert the new bulb's leads fully into the socket
• Avoid touching the glass; handle the new bulb with clean gloves or tissue, then restore power and test

15 Amp, 125/250 Volt. Package of 2. Switches have 3/16 inch terminals.

Size: 4 x 8mm.

Fastener screw

This is a Whirlpool microwave magnetron. The microwave magnetron is one of the main components that control the heating function in the appliance. If a microwave has suddenly stopped heating but is still turning on normally, the problem could be the magnetron. Use a voltage tester to confirm whether this part is causing the problem. This component is made for installation in a microwave and oven combo where the microwave doubles as a vent hood. To replace this part, begin by unplugging the appliance and removing it from above the oven. Two people will be needed for this repair. This part requires exposure to highly sensitive electrical parts that could cause severe injury.This is a genuine OEM replacement part sourced directly from the manufacturer. This part is compatible with Whirlpool, Magic Chef, Amana, and Maytag appliances.

This electrical safety fuse opens the circuit when a short or overcurrent occurs. Replacing a blown fuse can help restore power after the root cause is corrected, protecting controls and wiring from further damage.

• Protects the appliance by interrupting power during overcurrent or short-circuit events
• When open/blown, the appliance may be completely unresponsive
• Helps prevent damage to control boards and wiring during faults
• Often fails after a component shorts or a power surge occurs

• Disconnect power to the appliance before servicing
• Use a multimeter to test the fuse for continuity; replace only if open
• Install a fuse with the exact same rating and form factor as the original
• If the new fuse blows again, stop and diagnose the underlying fault; consider service for high-voltage systems

This fuse block is the appliance electrical terminal used to secure and connect a fuse or wire harness, restoring a safe electrical path for heating and motor circuits. It helps maintain reliable power transfer inside the appliance. What it does:

• Provides a secure mounting point and electrical connection for a fuse or inline connection
• Enables proper power flow between the control and high-voltage components
• Can cause loss of power, intermittent operation, or heating issues when damaged or corroded
• Replaces a worn, cracked, or melted terminal block to restore safe connections

• Disconnect power to the appliance before starting any work
• Handle wiring carefully; secure all splices and fasteners to manufacturer torque recommendations

The Screw is an OEM part for Whirlpool microwaves. It is responsible for securing various parts of the microwave together. This screw ensures a tight and secure fit for parts and helps maintain the structural integrity of the microwave, preventing any loose or rattling parts.

A bad microwave screw can occur due to wear and tear, accidental damage, or misplacement during maintenance or repairs. If you notice symptoms such as loose or wobbly components, difficulty in opening or closing the microwave door, or abnormal noises while the microwave is in use, it may be time to replace this part.

Symptoms of a bad microwave screw include:

• Loose or wobbly components
• Difficulty in opening or closing the microwave door
• Abnormal noises during operation

Restore your Whirlpool microwave by replacing the faulty or missing microwave screw with this genuine OEM part.

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.


This is a genuine replacement screw used to fasten appliance panels, trim, and components. It restores secure attachment and helps eliminate rattles or loose parts for safe, reliable operation. What it does:

• Secures panels, brackets, trim pieces, or internal components
• Stops vibration-related noise caused by loose or missing fasteners
• Restores proper alignment and fit of assembled parts
• Provides the correct thread and length for the intended factory location

• One screw

• Use the correct screwdriver or bit to avoid stripping the head
• Hand-start the screw to ensure correct thread engagement before final tightening
• Tighten until snug; avoid over-tightening which can strip threads or crack plastic
• Disconnect power to the appliance before working in areas near electrical components
