This part is discontinued by the manufacturer and is no longer available for purchase.
This screw is used to secure the handle end cap to the center of the door. The screw size measures 8-18 x 1/2 inches.
Seals the light lens to the oven cavity, blocking heat, steam, and grease from the bulb housing. Replace if cracked, brittle, or missing. Confirm fit.
10-24 x 1/2 inch mounting screw for securing appliance panels, handles, brackets, and internal components. Replace lost, stripped, or damaged screws.
Hinge pin that connects the door hinge to your range cabinet. Replace if worn, bent, or missing to restore smooth door movement and proper alignment.
This retaining ring secures a component in its groove on a shaft or housing, keeping parts aligned and in place during operation. Replace a bent, stretched, or missing ring to restore a tight hold and reduce movement or noise.
Anchor spring for oven doors. Maintains tension on door hinges to keep the door stable and balanced. Replace if spring is broken, fatigued, or missing.
Replacement oven door spring that provides tension for smooth opening and closing. Install when original spring is broken, worn, or missing for safe use.
Size: 8 x 3/8 inch.
The smoke eliminator vent tube directs cooking vapors and smoke away from the oven cavity to the exhaust system. Replace when experiencing excessive smoke buildup or poor ventilation during cooking.
Light socket assembly houses your oven bulb and provides electrical connections to illuminate the interior. Replace when bulb won't stay secure or light fails.
Original Whirlpool light bulb, 40 watt.
Symptoms of needing to replace the light bulb include:
Causes of a faulty light bulb can include normal burnout over time, electrical issues, or physical damage due to impact or vibrations.
This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Kenmore, Frigidaire, GE, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore appliances.
Appliance won't start or trips breaker? This ground screw secures the grounding conductor to the chassis for safe electrical connection. Simple fix.
Specs: 6 x 3/8B
Light switch for door.
Fix burners that won't spark or click constantly. This spark module generates high-voltage pulses to ignite surface burners. DIY-friendly, 15-minute repair.
Size: 6 inches long. Includes ceramic wire connectors.
Replacement hex nut for dryer terminal blocks and electrical connections. Secures terminal components. Needed when original is stripped, missing, or damaged.
If your range has a strong burning smell or won't power on, the terminal block may be heat-damaged. This insulated connector restores safe power flow.
This part has been discontinued by the manufacturer and is no longer available.
