Parts for Kitchenaid KODE507EBL04: Oven Parts

This tube-vent is the replacement exhaust tube that channels hot, moist air from the dryer to the external vent, helping the dryer remove moisture efficiently and operate safely. What it does:

• Routes dryer exhaust from the drum area to the vent outlet for proper airflow
• Prevents exhaust air leakage that can reduce drying performance
• Helps avoid lint buildup in the cabinet area when intact
• Commonly replaced when cracked, crushed, or collapsed and causing poor drying or unusual odors

• One tube-vent

• Disconnect power (and gas, if applicable) before starting any repair
• Inspect and clear the external vent path; secure tube with appropriate clamps or fasteners
• Do not kink, stretch, or sharply bend the tube — ensure a smooth airflow path
• If you detect heavy lint buildup or damage to ducts, clean or replace the entire venting run and follow local building codes

The Door Hinge Receiver is an OEM part for Whirlpool ranges. It receives and pivotally mounts the range door hinges, facilitating smooth opening and closing of the door.

Causes of a bad range door hinge receiver include normal wear and tear over time, repeated opening and closing stress, and damage or warping from excessive heat exposure.

Symptoms of a bad door hinge receiver include:

• Cracks or wear on mounting surfaces that could compromise safety
• A loose, wobbly or misaligned range door that does not seal properly
• The door being difficult to open and close smoothly
• Potential for the door to fall off if mounting surfaces fail

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.


This spacer provides a small, rigid gap between appliance components to maintain proper alignment and prevent contact. It restores correct spacing so panels, doors, or assemblies fit and move as intended. What it does:

• Maintains proper clearance between parts to prevent rubbing, binding, or wear
• Helps align panels, trim, or assemblies for smooth operation
• Supports fasteners or clips to ensure a secure fit
• Can reduce vibration-related noise when spacing is correct

• One spacer

• Disconnect power or gas before servicing the appliance
• Inspect mounting area and fasteners; replace any worn clips or screws as needed
• Install in the original orientation; do not force into place or over-tighten fasteners

This door latch keeps the door securely closed and engages the door switch/interlock so the appliance operates as designed. Replacing a worn or broken latch helps resolve door-related errors and restores reliable, safe operation.

• Secures the door against the strike for proper closure and alignment
• Actuates the door switch/interlock so controls recognize a closed door
• Helps prevent operation when the door is open or not fully latched
• Common symptoms: door won't latch or stay closed; unit won't start or shows a "door/open-close" message; broken or loose latch hook

• Disconnect power before servicing; use proper PPE and beware of sharp edges
• Access the latch through the door panel/trim as applicable; use non-marring tools to avoid damage
• Transfer any reusable clips/springs from the old latch to the new part
• After installation, verify smooth door closure and that the control detects the door as closed

This oven light assembly replaces a damaged or missing interior light lens and housing to restore oven-cavity illumination for safer cooking and easier food monitoring. It fits into the oven ceiling and protects the bulb from heat and spills. What it does:

• Replaces the oven's interior light lens and housing so the light can safely illuminate the cavity
• Protects the bulb from grease, spills, and direct heat
• Helps resolve symptoms like no interior light, cracked or missing lens, and a rattling or loose lens/housing
• Restores proper light alignment and coverage for better visibility when checking food

• Disconnect power to the appliance before starting any work
• Allow the oven to cool completely; the lens and surrounding parts can get very hot
• Handle glass components carefully to avoid breakage; wear gloves and eye protection

Adjustable leveling foot that stabilizes and levels your appliance on uneven floors to stop rocking and improve overall stability. Simple replacement for a worn or damaged foot to restore a solid, level setup. What it does:

• Threads into the appliance base to support weight and set the appliance height
• Lets you level the appliance to stop rocking or tilting on uneven floors
• Helps reduce vibration and shifting during operation
• Common symptom fix: appliance wobbles, is unlevel, or rocks when pushed

• Disconnect power and pull appliance away from the wall before working underneath
• Support the appliance so it cannot tip; adjust the foot by turning until the unit is level
• Recheck level front-to-back and side-to-side; tighten any retaining hardware if present
• If rusted or stuck, use penetrating lubricant and proper tools; avoid forcing parts in a way that could damage the cabinet

This factory fastener secures components inside your appliance, keeping panels, brackets, and assemblies properly attached. Replacing a worn, stripped, or missing screw restores a tight fit and helps prevent vibration, rattling, and misalignment.

• Fastens parts to frames, panels, or brackets as specified in your model's parts diagram
• Helps maintain alignment and reduce vibration/rattling during operation
• Replace when the original screw is missing, corroded, stripped, or no longer holds
• Direct OEM hardware for the designated locations on applicable models

• Disconnect power; shut off gas/water if applicable. Allow hot surfaces to cool.
• Use the correct driver size; start threads by hand to avoid cross-threading.
• Tighten until snug—do not overtighten, especially into plastic or thin sheet metal.
• If a mating clip, insert, or nut is damaged, replace that hardware per your model diagram.

Restore a tight, heat-resistant seal around your oven opening with this oven door gasket. It helps keep heat inside the cavity, stabilize temperature, and improve baking performance by sealing the gap between the door and oven frame.

• Forms the primary seal between the oven door and cavity to retain heat
• Reduces heat loss and temperature swings for more consistent cooking
• Helps prevent hot air and moisture from leaking around the door
• Common signs it's worn: visible tears or fraying, flattened spots, heat felt escaping, longer preheat or cook times

• Disconnect power and allow the oven to cool completely before servicing
• Remove the old gasket from the retainer channel or clips; clean the groove
• Press the new gasket evenly into place without stretching; ensure corners are fully seated
• Close the door and check for uniform contact around the perimeter; adjust as needed

This sensor monitors moisture inside the microwave cavity during Sensor Cook/Reheat cycles so the control can automatically set time and power. Replace it if sensor-based functions stop working or the unit shows a sensor error during cooking.

• Detects steam/humidity during sensor cycles to help the control adjust cook time and power
• Helps improve cooking results on Sensor Cook/Reheat programs
• Common failure signs: sensor-cook options won't start or end early, or the display shows a sensor error
• Intermittent or inconsistent results on sensor-only programs can also indicate a failing sensor

• Disconnect power before service. Microwaves can retain dangerous high voltage even when unplugged—use extreme caution
• Access is typically behind the control panel or top grille; note wire routing and connector orientation before removal
• Handle the sensor by its body/connector—avoid touching the sensing element
• After installation, run a sensor-cook cycle to confirm proper operation

A 6-32 machine screw used to secure panels, brackets, and components in many Whirlpool appliances. Replaces worn or missing fasteners to restore proper fit and stop loose parts from rattling or shifting. What it does:

• Secures panels, trim, brackets, and small assemblies
• Helps stop vibration and rattling caused by loose fasteners
• Restores proper alignment for parts held by a 6-32 thread
• Prevents further wear from movement or improper fit

• Disconnect power to the appliance before beginning any repair
• Use the correct driver for the screw head to avoid stripping
• Thread gently and avoid overtightening to prevent damage to threads or components
• Keep removed fasteners organized to ensure correct reassembly

The High Limit Thermostat is an OEM replacement part for Whirlpool ovens. It acts as a safety mechanism that monitors the oven's temperature to prevent overheating. When the oven exceeds a specific temperature, the high-limit thermostat interrupts the electrical flow to the heating element, ensuring the appliance remains within safe operating conditions.

Causes of a bad High Limit Thermostat can include a malfunction due to electrical issues or component failure. It may become unresponsive over time, failing to cut off the power to the heating element when the oven overheats.

Symptoms of a bad High Limit Thermostat include:

• The oven not heating up adequately or overheating
• Inconsistent oven temperatures leading to undercooked or overcooked food
• The thermostat being unresponsive or failing to regulate the oven’s temperature

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This bottom oven vent assembly replaces the lower oven vent that covers and directs airflow under the oven cavity, helping keep debris out of the lower compartment and maintaining proper ventilation for safe operation. What it does:

• Directs exhaust and airflow from the oven's lower front area to maintain ventilation.
• Protects the lower cavity from spills, crumbs and debris that can collect beneath the oven.
• Restores a secure, sealed fit where vents are cracked, warped, loose, or missing.
• Reduces drafts, odors or visible smoke coming from under the oven when the original vent is damaged.

• Disconnect power to the appliance before servicing to reduce shock and burn risk.
• Access is typically behind the lower access/grill panel; basic hand tools are usually required.
• Inspect mounting clips or screws when removing the old vent and reuse or replace as needed.

This chassis bottom duct is the lower access cover that protects internal components and channels airflow under the appliance cabinet. It helps keep wiring and parts shielded while allowing proper ventilation. What it does:

• Covers and protects the appliance chassis bottom area from dust, debris and accidental contact
• Directs airflow under the cabinet to support cooling/ventilation paths
• Prevents loose items from entering the chassis and interfering with components
• Can be replaced when cracked, warped, missing, or causing gaps that expose internals

• Intended for use as a direct-replacement exterior cover; verify fit before installation
• Power off and unplug the appliance before removing or installing the duct
• Remove any obstructing panels or fasteners to access the mounting points; retain hardware if reusing
• If damage extends to adjacent components, inspect internal wiring and mounts for service

This bottom vent trim is the lower kick-panel trim piece that restores the cabinet opening under the appliance for a finished look and proper floor-level airflow management. It replaces damaged, bent or missing lower trim to improve appearance and fit. What it does

• Covers the appliance bottom opening and guides air flow beneath the unit.
• Replaces cracked, dented or warped trim that causes gaps or uneven fit.
• Helps prevent large debris from entering the lower cavity and keeps a finished front appearance.
• Fits where the original lower kick-panel trim has been removed or damaged.

• One bottom vent trim piece.

• Disconnect power to the appliance before starting any repair.
• Typically mounts with existing clips or screws; common hand tools may be required.
• Handle edges carefully; trim pieces can have sharp edges.

The Foot Level is an OEM part for Whirlpool wall ovens. It sits at the base of the oven and incorporates adjustable feet, rollers, or glides. The foot level allows for precision leveling and balancing of the oven once installed.

Symptoms of a bad or damaged foot level include:

• The oven rocking or wobbling noticeably during use
• Excessive stress on the oven door or improper door alignment
• Screeching or scraping noises coming from the foot-level area
• Visible damage, bending, or instability of the feet, rollers, or glides
• Inability to properly level or balance the oven for optimal performance

This genuine replacement foot level from Whirlpool restores stability and efficiency. It is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, and select Kenmore wall ovens to ensure they sit firmly and operate smoothly.

The Foot Level is an OEM part for Whirlpool wall ovens. It sits at the base of the oven and incorporates adjustable feet, rollers, or glides. The foot level allows for precision leveling and balancing of the oven once installed.

Symptoms of a bad or damaged foot level include:

• The oven rocking or wobbling noticeably during use
• Excessive stress on the oven door or improper door alignment
• Screeching or scraping noises coming from the foot-level area
• Visible damage, bending, or instability of the feet, rollers, or glides
• Inability to properly level or balance the oven for optimal performance

This genuine replacement foot level from Whirlpool restores stability and efficiency. It is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, and select Kenmore wall ovens to ensure they sit firmly and operate smoothly.

This wire cover is a protective sleeve that helps route and shield appliance wiring to reduce wear and prevent accidental contact. It restores a neater harness run and helps maintain safe electrical routing inside the appliance. What it does:

• Protects wires from abrasion and chafing against sharp edges or moving parts
• Helps prevent exposed conductors that can cause shorts, arcing, or burning smells
• Keeps wiring bundled and routed to reduce pinching and stress on connectors
• Reduces risk of intermittent electrical issues caused by damaged insulation

• Disconnect power before beginning any service to avoid shock or injury
• Inspect surrounding wiring and connectors for damage; replace any frayed or exposed wires
• Slide cover over the wiring harness or route harness through sleeve as needed; secure with existing clips or approved fasteners

The Whirlpool screw is an OEM replacement part responsible for securing various components or parts on different types of Whirlpool appliances. The screw is designed to provide a secure and reliable fastening connection, ensuring that different parts of the appliance stay in place. It is commonly used in different locations within the appliance, such as the cabinet, panels, or other structural elements.

This part fixes the following symptoms:

• Loose or wobbly components within the appliance
• Panels or parts that are not securely attached
• Rattling or unusual noises due to loose parts
• Damaged or missing screw

The Whirlpool screw can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

Halogen oven light that restores bright interior illumination so you can check food without opening the door. Direct-fit replacement that returns clear, focused lighting to compatible Whirlpool ovens. What it does:

• Replaces a burned-out or dim oven light so the interior is clearly visible
• Stops flickering or intermittent lighting caused by a failed halogen bulb
• Provides concentrated, high-intensity light for better visibility while cooking
• Helps identify when interior glass is cracked or bulb filament is damaged

• Always disconnect power to the appliance at the breaker before servicing the oven
• Allow the old bulb to cool completely; halogen bulbs run hot
• Avoid touching the new halogen bulb glass with bare hands — use gloves or a clean cloth to prevent oil deposits and premature failure

This cover protects and finishes the appliance's control panel area, keeping switches and electronics safe while restoring the original appearance. It provides a clean, secure surface that helps prevent dust and moisture from reaching internal controls. What it does:

• Covers and protects the control console or user interface area from dirt and debris
• Helps prevent accidental contact with buttons, switches, or electronics
• Restores the appliance's finished look after damage or wear
• Reduces light or moisture exposure to internal components when properly installed

• One control panel cover

• Disconnect power (unplug or switch off breaker) before starting any repair
• Remove any retainers or screws holding the console in place; retain hardware if reusing
• Handle carefully to avoid scratching the finish; align tabs and fasteners before securing

This cover protects and finishes the appliance's control panel area, keeping switches and electronics safe while restoring the original appearance. It provides a clean, secure surface that helps prevent dust and moisture from reaching internal controls. What it does:

• Covers and protects the control console or user interface area from dirt and debris
• Helps prevent accidental contact with buttons, switches, or electronics
• Restores the appliance's finished look after damage or wear
• Reduces light or moisture exposure to internal components when properly installed

• One control panel cover

• Disconnect power (unplug or switch off breaker) before starting any repair
• Remove any retainers or screws holding the console in place; retain hardware if reusing
• Handle carefully to avoid scratching the finish; align tabs and fasteners before securing

The Light Bulb is an OEM part for Whirlpool microwaves. It provides illumination inside the microwave, allowing you to monitor the cooking process. This light bulb is designed to fit securely in the designated socket, ensuring consistent and bright lighting.

Causes of a bad light bulb can include burning out due to extended use, damage to the bulb or filament, or issues with the electrical socket. When the bulb fails, it can make it difficult to see inside the microwave while it is in operation.

Symptoms of a bad light bulb include:

• No light inside the microwave when in use
• Flickering or dim light
• Light turning on and off intermittently

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Screw is an OEM part for Whirlpool appliances. This specific screw is used in various locations within Whirlpool appliances, securing components and ensuring the stability and proper alignment of parts. It is designed to fit precisely and maintain a firm hold, contributing to the overall functionality and safety of the appliance.

Over time, screws can become worn or stripped due to regular use, corrosion, or over-tightening.

Causes of a bad screw include wear and tear, exposure to moisture leading to rust, and over-tightening which can strip the threads.

Symptoms of a bad screw include:

• Loose or wobbly components
• Misalignment of parts
• Noise due to vibrating or loose parts
• Difficulty in securing or removing the screw

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.
