Samsung Dryer Fuse Or Sensor

• Takes too long to dry
• Doesn't shut off

You can do this! Although an Art Director by trade, I like working with my hands. I’m adept at working with tools and following instructions. In today’s disposable society, I prefer fixing things. That said, this has to be the easiest repair I’ve ever attempted with the largest cost-savings versus hiring a professional. My brand new dryer had been in use fewer than six months (average 6 loads per week) when suddenly the dryer would not heat. The drum would spin, there were no error codes, and... Read more

• Won't start

You can do this! Although an Art Director by trade, I like working with my hands. I’m adept at working with tools and following instructions. In today’s disposable society, I prefer fixing things. That said, this has to be the easiest repair I’ve ever attempted with the largest cost-savings versus hiring a professional. My brand new dryer had been in use fewer than six months (average 6 loads per week) when suddenly the dryer would not heat. The drum would spin, there were no error codes, and... Read more

• Shuts off too soon
• No heat or not enough heat
• Takes too long to dry

I used Fixya as an initial source describing my problem. I got two responses which were very helpful. One that the "coils" were probably the problem. Two, that the problem could be the thermostat or a thermistor in the dryer. I verified that AC was coming from the timing control, that both the two terminal and three terminal coils,the igniter and shut off thermostat all had continuity. I then applied AC directly to the coils: the two terminal coil ""clanked" and I interpreted that as the coil... Read more

You can do this! Although an Art Director by trade, I like working with my hands. I’m adept at working with tools and following instructions. In today’s disposable society, I prefer fixing things. That said, this has to be the easiest repair I’ve ever attempted with the largest cost-savings versus hiring a professional. My brand new dryer had been in use fewer than six months (average 6 loads per week) when suddenly the dryer would not heat. The drum would spin, there were no error codes, and... Read more

Replaced heating element and thermostat, took me about 2 hours but that's because i had to vacuum out the dryer inside and I also checked the fan before I closed the dryer back up. I have a Samsung DV448AAEP. Works great and saved my family money! Read more

• Takes too long to dry
• Doesn't shut off

I researched the issue on You tube and found out it could be either the "belt broke switch" or the Moisture sensor. A friend who was an appliance mechanic advised "since you have to take it all apart anyways, its best to replace the belt, spring, and Idler wheel" I bought the 5 item for $52. I watched the video on the AppliancePartsPros for changing out the belt and I replace all items on the list. Took 1 1/2 hrs and was fixed on restart!! * Wear gloves, the sheet metal is very sharp edges!* Read more

When starting my dryer the motor would power up and rotoe the drum and blower. Afetr about 20-30 seconds the igniter would come on then the gas valve would open and I would get heat for about 6 or 7 seconds then it would shut off. I know the burner is suppoed to cycle on and off but once the burner shut off it would not come bqack on unless I shut the dryer off and then back on. I checked for continuity on the thermistor, the thermal fuse and the high temp sensor. All three of them appeared to... Read more

Removed the heater of course and installed the part. Very easy to do no need to remove the drum, just top cover, control panel, and front door assembly. Remove the one screw holding heater, remove blue wire, turn heater CCW to the 8 o'clock poisiton. Install in the reverse order. This is the secound one in a month if it fails again i'll just bypass it and install a 25 AMP fuse. Read more

• Shuts off too soon

Replaced heating element about three months ago. Had to order thermistor because of error code "ts" on display and dryer would not run. Removed the two screws on the back that holds the top in place. After removing the top, remove the screws that hold the control panel on front. Make sure not to break the tabs that help hold it in place You do not have to unplug any connectors for the control panel. Lay control panel across top of dryer carefully so that it will be out of the way. Next... Read more

• Takes too long to dry
• Doesn't shut off

Changed Thermistor, Thermostats and the Thermal Fuse Assembly. I did not remove drum, so squeezing my hands in-between drum and vent hose pipe to remove screws was a tight fit, but doable. Read more

• Takes too long to dry
• Doesn't shut off

Replaced blown thermal fuse and while I had the dryer opened, I also replaced the thermistor & thermostat. I ordered the parts from appliancepartspro.com that were shipped within 24 hours. Dryer is now working again. Read more

Changed Thermistor, Thermostats and the Thermal Fuse Assembly. I did not remove drum, so squeezing my hands in-between drum and vent hose pipe to remove screws was a tight fit, but doable. Read more
