Samsung DA61-05435A Refrigerator Ice Maker Shut Off Arm OEM Part

I heard a cracking sound so I opened the freezer again and found that it was s piece of plastic -- a small bar -- that had broken off of something. I went online, first to identify the broken part. It was the ice guide. I had to do a bit more research to find out what the ice guide does, as well as the part number. I found it easily on appliancepartspros.com. (I think I purchased a new heating element for my electric oven from you and was able to fix it VERY easily. I was hoping this new repair would be as simple.) I had to move the fridge a bit to get to the power cord to pull it out. My 90 pound frame was no match for the fridge but I somehow got it moved enough for my arm to get between the fridge and wall. The bigger hassle for me was to get into the freezer enough to access the screw that holds the ice guide in place. That was the part still attached to the ice maker. I waited until my husband was out of town because I can't stand having someone breathing down my neck while I am trying to fix something. I couldn't just pull the door out, like a drawer. I strained my back trying to get the different sections out -- many are just snap-locked in place instead of with screws so it takes a bit of force. I wondered if I needed to abandon the repair until someone with more muscle was around. But I persevered and finally got the small basket on the door removed. Then struggled with the ice drawer. I couldn’t take out the main containers or remove the door, so, now scrunched down on the floor, I got to the ice maker and was able to pull the cover off (also locked in place with plastic bits and needed a bit of force, a scary thing when you are dealing with PLASTIC.) I tried to pull the whole ice maker out — that would have made replacing the ice guide EASY! — but I couldn’t, so I had to work with the ice maker still inside the freezer. There is only a small distance between the screw I needed to remove and the freezer wall. Make sure you have a VERY short screwdriver. I couldn’t even see if it was a + or - screw and had to take a picture! Once I had the short screwdriver (+) the rest was cake. Took out the old plastic bit, put in the new ice guide and voila! The whole thing also gave me a chance to sort through the contents of the freezer and clean it too. Putting the containers back in was much easier than taking them out. Everything is back to working order. Hurray! Got it fixed without a call to a “professional." (My vodka is no longer in the ice catcher, now that I have more space in the main sections.) Taking stuff out of the freezer and removing all the part necessary took time but once you can access the ice maker, you can fix this in a minute or two.

The "tray full" cut off arm broke on the ice maker in the bottom of our Samsung french door refrigerator, causing the ice to overflow the tray and fall into the area behind the freezer drawer. This caused the drawer to fail to fully close, I ordered two of the "tray full" cut off arms and replaced the broken one. This was accomplished by sliding out the freezer drawer and removing the trays from inside the drawer. The freezer drawer can be easily removed by pressing the small plastic lock-in tabs (one on each sliding arm of the freezer drawer). The broken cut off arm is located on the left side of the ice maker, which I accessed by laying in front of the refrigerator and, using a short no. 2 Phillips screwdriver, removed the one screw holding the arm in place, and replaced the broken arm with the new arm. Worked like a champ! The most difficult thing about he whole process was finding the correct part number (its on the arm, but some web sites say that the part number listed is not correct for my refrigerator.I took a chance and ordered anyway - cost is negligible). The longest part of the process was emptying the freezer drawer and then replacing all the frozen items into the drawer after the repair.

Replaced the arm. Lifted out the tray/top drawer, removed the broken arm by removing one #1 Phillips screw, installed new arm, reinstalled Phillips screw, reinstalled ice drawer.

I ordered a new one from APP and used a screwdriver to replace it, that simple.

I watched the tutorial and it looked easy so I tried it myself.. I ordered the Ice tray first, and then the sensor cover, and shut-off lever. I couldn't believe how inexpensive they were and I was shocked at how quickly they arrived. Putting it together was easier than it looked and my family really thought... I will definitely recommend you to my friends and family.
