Parts for Lg WM3632HW / ABWEEUS: Section 3 Parts

The Water Inlet Valve Assembly is an OEM replacement part for LG washing machines, designed to control the flow of water into the laundry tub. This part is responsible for opening and closing to allow water into the wash drum at the appropriate times during the wash cycle, providing the correct water level and temperature.

Causes of a bad Water Inlet Valve Assembly can include mineral deposits blocking the valve, electrical failure preventing the valve from opening or closing properly, or physical damage to the valve mechanism itself.

Symptoms of a bad Water Inlet Valve Assembly include:

• Inadequate filling of the washer drum
• Water entering the drum when the washer is off
• Unusual noises during the fill cycle
• Water that is too hot or too cold, indicating a failure in valve operation that controls temperature

This OEM LG part can also be used on Kenmore/Sears appliances.

This inlet hose supplies fresh water from the household line to the dishwasher. Replace a damaged or leaking hose to help restore proper filling and prevent water leaks during operation.

• Channels water from the supply valve to the dishwasher's inlet
• Common failure signs: leaks under or behind the unit, fill errors, slow or no fill
• Helps resolve intermittent water supply issues caused by a kinked or cracked hose

• Unplug power and shut off the water supply before starting
• Place a towel or pan to catch residual water when disconnecting
• Check for leaks after installation and tighten connections as needed

This inlet hose is the internal water line for your dishwasher, routing fresh water from the fill valve into the wash system. Replacing a brittle or leaking hose restores reliable filling and helps protect floors and cabinetry from water damage.

• Channels incoming water from the inlet valve to the tub/sump
• Maintains proper fill level and flow at the start of each cycle
• A cracked, kinked, or loose hose can cause leaks or slow/no fill
• Restores correct water delivery and helps prevent water damage

• Disconnect power and shut off the water supply before servicing
• Pull the dishwasher forward for access; place a towel or pan to catch residual water
• Note the original routing and clamp positions; transfer clamps and avoid kinks
• Restore water, run a quick fill cycle, and check all connections for leaks

The Drain Hose Assembly is an OEM part for LG washing machines. It is a component designed to transport used water from the washer to the drain. This flexible hose assembly ensures that water flows smoothly out of your washing machine after each cycle, preventing leaks and maintaining the efficiency of your appliance.

Causes for replacement can include wear and tear over time, clogs from lint or small items, kinks that restrict water flow, or damage from moving or improper installation.

Symptoms of a bad Drain Hose Assembly include:

• Water leaking from the back or bottom of the washing machine
• Difficulty draining water out of the washer
• Puddles of water forming around the appliance during or after operation

This OEM LG part is also compatible with some Kenmore models.

This spring-style hose clamp secures a washer's rubber hose to its fitting to maintain a tight, leak-resistant seal. Replacing a weakened clamp helps stop drips and keeps the hose firmly in place during operation.

• Provides constant spring tension to hold a rubber hose on its port
• Helps prevent leaks at the connection point
• Resists vibration so the hose doesn't back off the fitting
• Common signs include water at a hose joint, a loose/detached hose, or a rusted/broken clamp

• Disconnect power and turn off water supply before servicing
• Place a towel or pan to catch residual water from hoses
• Use pliers to compress the ears, slide off the old clamp, position the new clamp behind the hose bead, and release evenly
• After reassembly, run a quick test cycle and check for leaks

The Clamp is an OEM part for LG washing machines. It is used to secure the hose connections within the washer, ensuring that water flows correctly without leaks.

Over time, the clamp can become worn or damaged due to repeated exposure to water, vibration, or general wear and tear. If the clamp fails, it can lead to water leaks or hoses becoming detached.

Symptoms of a bad clamp include:

• Water leaking from hose connections
• Hoses coming loose or detaching during operation
• Visible rust or damage on the clamp
• Poor water flow or pressure issues

This OEM LG part is also compatible with Sears/Kenmore models.
