Parts for Ge MSK27DHSMAD: 05 - Section5 Parts

This clamp secures small hoses or tubing and nearby wiring inside the appliance to keep lines held in place and reduce rubbing, leaks, or vibration noise. It's a direct-fit replacement designed to restore proper hose routing and stability. What it does:

• Holds water, drain or vent tubing securely to prevent sagging and rubbing that can cause leaks or wear
• Keeps hoses and wires aligned to reduce vibration and rattling during operation
• Helps maintain proper connections at fittings so seals stay seated and drip risk is minimized
• Simple mechanical clip action — no special tools or adhesives required

• Disconnect power and shut off the water supply before starting any repair
• Remove the old clamp and install this clamp in the same orientation; tubing sits fully in the fitting
• Use standard pliers (or the OEM-recommended tool) to compress/seat the clamp; avoid twisting or pinching the tubing
• Inspect surrounding tubing and fittings for wear; replace damaged hoses or seals if found

The Ice Maker Fill Tube Grommet is an OEM part for GE refrigerators. This grommet creates a seal between the ice maker fill tube and the refrigerator, preventing leaks and ensuring that water is properly directed into the ice maker during the filling process.

Causes of a bad grommet can include regular wear and tear, damage from exposure to freezing and thawing cycles, or degradation from exposure to water and moisture.

Symptoms of a bad ice maker fill tube grommet include:

• Water leaks around the ice maker fill tube area
• Ice maker not producing ice properly
• Visible cracks or deformation in the grommet
• Water pooling inside or around the refrigerator

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This part has been discontinued and is no longer available.

Left side.

This replacement part is a snack pan slide rail, and it is intended for use in different types of appliances. This is a genuine replacement part made by General Electric. This part is able to hold up other trays and racks in the refrigerator and freezer so that extra shelf space can be utilized. These slide rails can also hold up trays that can support heavy bottles and drinks. A new snack pan slide rail might be needed if the current ones have become stripped and are unable to latch onto the shelving to support it. It is common that these parts can become brittle over time as exposure to low temperature wears down the plastic. Be sure the shelving of the appliance is clear before attempting to replace the slide rail. This is an OEM part sourced directly from the manufacturer. It is sold individually. This replacement part is compatible with different types of appliances made by General Electric.

The Drawer Slide Assembly is an OEM part for GE refrigerators. It provides the mechanism that allows refrigerator drawers to slide in and out smoothly. This assembly includes the tracks and glides that support the drawer, ensuring it moves effortlessly while staying securely in place.

Causes of a bad drawer slide assembly can include wear and tear from frequent use, accumulation of dirt and debris in the tracks, or physical damage from overloading or mishandling the drawer.

Symptoms of a bad drawer slide assembly include:

• Difficulty opening or closing the drawer
• The drawer not staying in place
• Unusual noises when moving the drawer
• The drawer feeling loose or wobbly

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

With a length of 16 1/4 inches, it is structured to support the crisper drawer. This facilitates its smooth and effortless sliding in and out. For matching left-hand side order WR72X207.

The Drawer Slide Assembly is an OEM part for GE refrigerators. It allows for smooth and easy movement of the refrigerator drawers, ensuring convenient access to stored food items. It provides the necessary support and stability to hold the weight of the contents within the drawers. The slide measures approximately 16 1/4 inches long.

A bad Drawer Slide Assembly can occur due to wear and tear over time, excessive load strain, or damage caused by accidental mishandling. If the slide assembly becomes worn, bent, or broken, it can lead to issues such as difficulty in opening or closing the refrigerator drawers, as well as potential damage to the drawers or their contents.

Symptoms of a bad Drawer Slide Assembly include:

• Sticky or stiff movement of the refrigerator drawers.
• Drawer not fully extending or retracting.
• Excessive wobbling or sagging when the drawer is pulled out.
• Visible damage or wear on the slide assembly.

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

For matching right hand side order WR72X206.

The Crisper Drawer Slide is an OEM replacement part for GE refrigerators. It facilitates the smooth movement of the crisper drawer, ensuring easy access to fruits, vegetables, and other stored items. This is the right-hand side refrigerator crisper drawer slide. Approx. 14 7/8 inches long.

Symptoms of a bad Crisper Drawer Slide include:

• The crisper drawer sticking or jamming, making it difficult to open or close
• Visible wear or damage to the slide, affecting its smooth operation
• The drawer not aligning properly, leading to an insecure fit
• The inability to fully extend or retract the crisper drawer

Causes for a malfunctioning Crisper Drawer Slide can include wear and tear from regular use, the accumulation of debris obstructing the slide's path, or damage incurred from overloading the drawer.

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models. For matching left-hand side order WR72X209.

The left Drawer Rail Slide is an OEM part for GE refrigerators. It provides smooth sliding action for refrigerator drawers, ensuring easy access and optimal storage management. This component guides the drawer in and out, preventing misalignment and supporting the weight of the drawer and its contents.  It measures approximately 14 7/8 inches long.

Over time, the drawer rail slide can become worn or damaged, leading to issues with drawer movement. Common causes of a bad drawer rail slide include normal wear and tear from frequent use, damage from overloading the drawer, or physical impacts that cause misalignment or breakage.

Symptoms of a bad drawer rail slide include:

• Difficulty opening or closing the drawer
• Drawer not aligning properly
• Excessive noise when operating the drawer
• Drawer falling off the rails

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

Note: For matching right-hand side order WR72X208.

Package of 12

This cable clamp secures refrigerator wiring to the cabinet, keeping harnesses organized and protected. Replacing a missing or damaged clamp helps prevent chafing and vibration noise while maintaining proper clearance from fans and other moving components.

• Anchors wire harnesses in their designed routing
• Helps prevent insulation wear from rubbing or vibration
• Keeps wires clear of sharp edges and moving parts
• Common signs it's needed: missing/broken clamp, loose or dangling wires, or new rattling/buzzing noises

• Disconnect power before servicing
• Access the clamp location and note original wire routing
• Position the clamp and secure with the existing fastener; do not overtighten
• Ensure wires aren't pinched and have clearance from the fan/compressor before restoring power

The R134 Drier is an OEM part for GE refrigerators. This component plays a critical role in the refrigeration system by removing moisture and contaminants from the refrigerant, ensuring efficient cooling and preventing damage to other parts of the system. It helps maintain the purity and effectiveness of the refrigerant as it cycles through the system.

You should replace the R134 drier if it becomes clogged or damaged. Common causes of a bad drier include wear and tear over time, exposure to moisture, or contamination from other failing components in the refrigeration system.

Symptoms of a bad R134 drier include:

• Reduced cooling efficiency
• Frost buildup on the evaporator coils
• Unusual noises from the refrigeration system
• Increased energy consumption
• Refrigerator not maintaining the set temperature

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

Nut for 1/4 inch tubing.

This cable clamp secures refrigerator wiring to the cabinet, keeping harnesses organized and protected. Replacing a missing or damaged clamp helps prevent chafing and vibration noise while maintaining proper clearance from fans and other moving components.

• Anchors wire harnesses in their designed routing
• Helps prevent insulation wear from rubbing or vibration
• Keeps wires clear of sharp edges and moving parts
• Common signs it's needed: missing/broken clamp, loose or dangling wires, or new rattling/buzzing noises

• Disconnect power before servicing
• Access the clamp location and note original wire routing
• Position the clamp and secure with the existing fastener; do not overtighten
• Ensure wires aren't pinched and have clearance from the fan/compressor before restoring power

The Ice Maker Water Line is an OEM replacement part for GE refrigerators. It is an important supply line that delivers water from the main water source to the icemaker component. The water line allows water to flow smoothly, facilitating the icemaking process.

Causes of a bad water line can include cracks or punctures from impact or bending, mineral deposits and corrosion building up inside the line restricting flow, or improper connection fittings causing leakage.

Symptoms of a bad ice maker water line include:

• Irregular or insufficient ice production
• No water delivery to the icemaker despite activation
• Noticeable leaks or drips near the water line attachment points
• Strange knocking or hammering sounds are heard when the icemaker is running

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Refrigerator Union Connector is an OEM replacement part for GE refrigerators. It is responsible for connecting the water supply lines from the kitchen plumbing to the refrigerator, allowing water to flow to the ice maker and water dispenser. The plastic connector assists your water dispenser by joining two 5/16 inch x 5/16 inch plastic water lines. Over time, Union Connectors can crack or break under pressure.

Causes of a bad Union Connector include wear and tear from repeated use, exposure to extreme fluctuations or surges in water pressure, or damage from accidental mishandling.

Symptoms of a bad Refrigerator Union Connector include:

• Water leaks at or near the connector area
• Inconsistent or no water flow to the ice maker/dispenser
• Fluctuations in water pressure to the fridge
• Water damage to surrounding kitchen areas from leaks

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.
