Parts for Kitchenaid KFED500EBS05: Upper Door Parts

This inner door panel replaces a damaged or cracked refrigerator door liner to restore interior protection and shelf mounting support. It keeps insulation covered and helps maintain a clean, stable interior surface for door bins and hardware. What it does:

• Covers the door cavity and protects internal insulation and wiring
• Provides mounting surfaces and anchors for door bins, shelves, and hardware
• Prevents drafts and helps maintain interior temperature by sealing around fitted components
• Common signs it's needed: visible cracks, broken mounting bosses, loose or misaligned door bins, or interior moisture buildup

• One replacement door liner

• Disconnect power or unplug the refrigerator before starting any work
• Typical installation requires removing the door inner assembly and unfastening retaining screws/clips
• Handle carefully to avoid damaging mounting bosses or trim; alignment is important for bin fitment
• If hardware is worn or damaged, inspect and replace separately as needed

This replacement door glass restores a clear viewing window and the structural integrity of your appliance door if the original glass is cracked, shattered, or damaged. It helps keep operation safe while returning the door to a like-new appearance. What it does:

• Forms the transparent viewing window in the appliance door
• Helps maintain proper door integrity and safe operation
• Restores visibility into the cavity during use
• Replaces cracked, chipped, loose, or shattered glass

• 1 door glass panel

• Disconnect power and allow the appliance to cool completely before servicing
• Wear cut-resistant gloves and eye protection when handling glass
• Support the door; some models require removing the door to access the glass
• Transfer any brackets/trim from the old glass and avoid overtightening fasteners

This is the upper door frame glass for the appliance door window. It restores a clear, secure viewing window in the upper section of the door so you can monitor cooking without opening the door. What it does:

• Replaces damaged, cracked, or fogged upper door window glass
• Restores a secure seal and clear visibility through the door window
• Helps prevent heat loss from the oven cavity when the door is intact
• Matches OEM form for proper fit and alignment

• Disconnect power to the appliance before beginning any repair.
• Handle glass with care and wear cut-resistant gloves and eye protection.
• You may need to remove the oven door and inner door panel to access and replace the glass; follow the manufacturer's door-disassembly instructions.
• If fasteners or retainers are corroded or damaged, replace them with OEM parts for safe reassembly.

This 8-32 x 3/8 screw secures panels, brackets, and internal components in your appliance so everything stays aligned and tight. Replace worn or missing hardware to restore a solid, rattle-free fit and safe operation.

• Fastens components to frames, brackets, or panels
• Helps reduce vibration, rattling, and misalignment
• Replaces missing, stripped, or corroded screws
• Correct 8-32 machine thread for tapped holes in compatible assemblies

• Disconnect power before servicing; shut off gas or water if applicable
• Start threads by hand to avoid cross-threading
• Tighten snugly without overtightening to prevent stripping

This retainer is a small mounting clip that secures internal components in your appliance, helping keep parts aligned and preventing rattles or movement. It restores proper fit and reduces noise from loose components. What it does:

• Secures panels, assemblies or hardware to prevent shifting during operation
• Keeps components aligned to reduce rattling or intermittent contact
• Helps maintain reliable operation when a worn or broken clip causes loose parts
• Common symptom: loose trim, rattling, or misaligned internal parts

• One retainer/mounting clip as shown

• Disconnect power (and water if applicable) before attempting service
• Inspect the mounting area and replace only the broken or missing clips
• Typical installation requires basic hand tools; handle plastic clips carefully to avoid breakage

This hinge receiver mounts to the appliance frame and accepts the door hinge arm/pin. It keeps the door aligned and secure so it opens and closes smoothly. Replacing a worn or cracked receiver restores proper door action.

• Anchors the hinge arm/pin at the cabinet/frame for smooth door movement
• Maintains door alignment and consistent closing action
• Wear or damage can cause a loose or sagging door, misalignment, or binding
• Common signs include clicking/grinding noises and visible cracks or deformation

• Disconnect power; allow the appliance to cool and shut off gas/water if applicable
• Support or remove the door to access the receiver
• Remove mounting fasteners, swap in the new receiver, and align per service instructions
• Reinstall the door and verify smooth movement and full closure

This factory fastener secures appliance components so panels, brackets, and handles stay tight and aligned. Replace a missing or stripped screw to stop rattles and keep assemblies firmly in place.

• Fastens appliance parts such as panels, brackets, trim, or hardware
• Replaces a missing, loose, or stripped fastener
• Helps eliminate vibration noise and wobbly components
• Restores proper alignment and secure mounting

• Disconnect power; for water- or gas-connected appliances, shut off supply lines before service
• Match length/thread to the original location; start threads by hand to avoid cross-threading
• Use the correct driver bit to prevent stripping the head
• Tighten snugly; do not overtighten into plastic or thin sheet metal

This oven door hinge restores smooth, controlled movement so the door opens easily and closes fully for a reliable seal. Replacing a worn hinge helps reduce heat loss and supports consistent cooking performance and safe operation.

• Provides the pivot and spring-assisted action for opening and closing the oven door
• Helps pull the door closed and hold it at intended stop positions
• Maintains even gasket contact to keep heat inside the cavity
• Common symptoms of a failing hinge: door won't close fully or sit flush, drops or slams open, binds or pops when moving, or shows an uneven gap

• Disconnect power and allow the oven to cool completely before servicing
• Support the door; open to the removal position and release hinge locks, then lift the door off
• Use caution—hinge springs are under tension; wear hand and eye protection
• Install in the same orientation and verify door alignment and smooth operation after reassembly

This oven door hinge restores smooth, controlled door movement and a proper seal. Worn hinges can cause a sagging door, poor closure, or binding—replacing the hinge helps maintain safe operation and consistent cooking performance.

• Supports the oven door with a spring mechanism for controlled opening and closing
• Helps pull the door tight against the gasket for an effective seal when closed
• Works with the opposite hinge to keep the door aligned and stable
• Common symptoms include door not closing fully, sagging or dropping, hard-to-open/close action, or heat escaping around the door

• Disconnect power and allow the oven to cool completely before servicing
• Remove the door following your model's instructions; engage hinge locks or use retaining pins if provided
• Replace the hinge in the same orientation; ensure hinge arms are fully seated in the receivers
• Reinstall the door and verify smooth motion and a complete seal

This upper door insulation restores the door's thermal barrier to help the refrigerator/freezer hold temperature and reduce condensation. It replaces deteriorated or missing insulation to improve cold-air retention and reduce frost build-up. What it does:

• Replaces worn or damaged insulation inside the upper door cavity
• Helps limit heat transfer to maintain interior temperature
• Reduces condensation and frost forming on the door liner
• Can address symptoms like uneven cooling, warm spots near the door, or excessive frost

• Disconnect power to the appliance before starting any service
• Access requires removing the inner door liner or trim—keep screws and clips organized for reassembly
• Position insulation without compressing; use the original retainer clips or adhesive as OEM specified
• Dispose of old insulation per local regulations and check door seal condition after reinstall

This small mounting spacer positions and supports adjacent components to maintain proper alignment and reduce movement. It helps prevent rubbing and wear by keeping parts at the correct distance for smooth operation. What it does:

• Keeps panels, trim, or internal components correctly spaced to prevent contact and wear
• Stabilizes assemblies to reduce vibration and movement
• Helps eliminate rubbing, squeaks, or misalignment-related issues
• Restores proper component clearance after repairs or part replacement

• Disconnect power to the appliance before beginning any repair
• Access may require removing panels, trim, or control assemblies; use basic hand tools
• Position spacer as shown in service literature and secure without over-tightening

The Screw is an OEM part for Whirlpool ranges. This screw is used to secure various components within the range, ensuring that parts such as panels, control boards, or burners are firmly attached and remain stable during operation.

Causes of a bad range screw can include regular wear and tear, over-tightening, or exposure to high heat.

Symptoms of a bad range screw include:

• Loose or unstable components within the range
• Difficulty in securing parts during maintenance or repair
• Visible damage or wear on the screw
• Parts becoming misaligned or rattling during operation

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

This genuine replacement screw restores secure mounting of panels and components on Whirlpool appliances, helping stop loose or rattling parts and maintain proper fit. Small but essential fastener for routine repairs. What it does:

• Secures panels, trim, brackets or small components to appliance frames
• Replaces missing, damaged, or stripped screws that cause loose or misaligned parts
• Helps stop vibration noise and restore proper panel alignment
• Provides the correct thread and length for the original mounting location

• Use the correct screwdriver or bit to avoid stripping the head
• Tighten until snug; do not overtighten to prevent thread or part damage
• Turn off and unplug the appliance before accessing internal components
• Keep removed fasteners organized so you return them to the original locations

This mounting bracket provides a secure anchor point to fasten and support internal components. It restores proper alignment and reduces movement so panels and modules stay firmly in place. What it does:

• Secures internal appliance components to the cabinet or frame
• Helps maintain proper alignment of panels and modules
• Reduces vibration and rattling caused by loose or worn brackets
• Prevents further wear on attached parts by stabilizing them

• One mounting bracket

• Disconnect power (unplug or switch off circuit breaker) before starting repairs
• Use basic hand tools; verify bracket orientation and fastener locations before tightening
• Replace only with exact-fit bracket to ensure proper alignment
• If mounting holes or nearby parts are damaged, inspect and replace any additional worn components

The Screw is an OEM part for Whirlpool microwaves. It is a small yet vital component that joins together other parts of the microwave to create a cohesive machine. The screw is responsible for tightly securing internal components like the magnetron tube, control panel, and outer case during operation.

Symptoms of a bad screw include:

• Loose or detached internal microwave components
• External parts like the door or casing that will not stay aligned or attached
• Overheating or arcing due to poor grounding from loose screws
• Component malfunctions if mounting positions are compromised

Causes of a bad screw can include wear and tear that causes stripping or loosening over time, or damage from handling that results in breaking or bending.

This OEM Whirlpool part is compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore microwave models.

This replacement screw with a 10-16 thread secures panels, brackets, and other components in your appliance. Restoring the correct hardware keeps parts tight and aligned, reducing vibration and preventing loosening over time.

• Secures sheet-metal panels, brackets, and assemblies
• Replaces missing, stripped, or corroded fasteners
• Helps eliminate rattling or vibration from loose hardware
• Maintains proper alignment for reliable performance

• Disconnect power; turn off the water supply before servicing
• Use the correct driver/bit and start threads by hand to avoid cross-threading
• Tighten snugly; do not overtighten into sheet metal or plastic
• Reinstall in the original location and orientation
