Dean T Tigard , OR December 11, 2014 Appliance: Whirlpool Washer WFW94HEXW2 Whirlpool wfw94hexw2 was giving error code f06 e01 (and e02 at times) The washer would try to start. The door would lock, but then would get stuck in the phase of start-up where the drum needs to roll around (I assume so it knows what's in there). It would sit and think about it for a couple minutes and then give the error codes. I shut it off (sometimes had to unplug it and plug it back in), and it would take about 10 minutes for the door to unlock. After reading about fixes, I decided to dive in and try it (the washer is only 3 years old and I'm pretty mechanical). Took off the top and back, unplugged and plugged in all wires from the CCU and MCU and still nothing. So I decided to replace the MCU first. I ordered it and it Thursday late afternoon and it was here on Monday (great service APP). Easy install (3 wire connectors), plugged it back in, hit the power and start buttons and it works like new. Read More... 210 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Nut Drivers
Christine B Woodinville , WA June 24, 2017 Appliance: Maytag Washer MHW7000AG2 Error codes f06 and e02 Replaced the motor control unit. Original unit had burn marks on the board Like others on here, had the error codes flash on the display, the door was locked, and machine ceased to function. Tried resetting by unplugging, but same errors eould come up. Door eventually unlocked to get my clothes out. Researched online and found this website. Decided to follow the directions on taking the part out to see if that was truly my problem and sure enough there were scorch marks on the motor board. Thought it was worth a shot to replace and see if it would work after replacing. The return policy made it a no brainer. Nothing to lose! So glad it's fixed! Video made it easy. Hard part was moving the heavy appliance, but my son helped me with that. Part arrived quickly so wasn't out of a washer for long. Read More... 59 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers, Socket Set
Samuel T Cordova , TN November 21, 2014 Appliance: Maytag Washer MHW6000AW0 Maytag front load washer error f06 e01 Replaced Motor Control Board. Note that you may return this part for a core refund of 60 dollars. Read More... 52 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Nut Drivers, Pliers
G B Islamorada , FL March 21, 2016 Appliance: Whirlpool Washer WFW95HEXW0 Whirlpool duet washer f06 e01 and f06 e02 Machine stopped three of four cycles after replacing the bellows for a leak. Thought I may have pulled some wires from the user interface to the control unit loose. Checked that - no problems. Figured it was the Control Unit - so I ordered one from Appliance Parts Pros. The old one was a bit tricky to remove, and I finally took off the bracket behind the user interface panel to push it aft to free it. Wasn't the problem so I returned the new CCU to Appliance Parts Pros and ordered the Motor Control Board. Thanks for allowing the return, Appliance Parts Pros. Installed the new Motor Control Board and machine started right up. Fix took 15 minutes, troubleshooting a month. Read More... 15 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 2+ hours Tools: Nut Drivers, Screwdrivers
David N Rockford , MI May 02, 2015 Appliance: Maytag Washer MHW6000XW2 F1e2 error code After pulling the lid off my Maytag Maxima washer and getting the technician manual that was attached to the inside of the lid, I traced the code to the motor control unit. After searching for it using the model number on the plate on the front of my washer, I found the part on the website, bought it for $280 and got it a few days later. I needed to pull the back cover off (it's near the floor in the back), replace 3 connectors, and slide the new one into place. I had repair places refuse to even come look at it because "they don't touch front load washers" so I thought it would be incredibly hard to fix. Instead it was incredibly easy. The videos and information on this website gave me the confidence that I could handle this repair. Thanks Appliance Parts Pros! Read More... 13 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Nut Drivers, Pliers
