Robert F Heath , TX April 10, 2020 Had to press water pad really hard to get water to dispense Super easy fix, remove two screws behind drop tray, unplug the wiring harness to dispenser, unplug and remove old pad, then snap new one into place. Reconnect harness. Took less than 5 minutes, works like new. Read More... 7 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Screwdrivers
Gregory L Chandler , IN March 18, 2016 Our refrigerator was automatically discharging water out without pressing a cup against the "water" pad The replacement pad was easy to install (<1 min.) and no more automatic discharge of water. Read More... 4 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Screwdrivers
Thomas W North Potomac , MD September 11, 2017 Appliance: KitchenAid Refrigerator KSCS25FVBT01 Ice dispenser inoperative and ice door stayed open Replaced ice dispenser pad and ice motor using a customers report on the website. Replacing the pad was easy just remove the drip tray and the two screws behind it then lift off the panel. I unplugged if so I could move it to a work area. Removed the old pad by breaking the retaining tabs and snapped in the new one and reconnect the wiring. The ice motor replacement was more difficult but the excellent report on the site helped a lot. Read More... 3 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Nut Drivers, Screwdrivers
Rachel J Chapel Hill , NC January 03, 2020 Had to push really hard on the ice and water pads to make them work I replaced the pads on my Kitchenaid side-by-side. I was able to order ones that looked exactly like the old ones. It was even easier than what I had seen in a YouTube video. Read More... 3 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Screwdrivers
Karen K South Pasadena , CA September 16, 2020 Appliance: Model KSCS25FMVSS02 Water and ice dispenser pads extremely difficult to push. Removed water drip tray to unscrew dispenser housing with Phillips screwdriver. Disconnected housing from refrigerator by unplugging the one wire connection and unplugged the ice and water dispenser pads. Replaced pads with new ones and plugged connections back in. Replaced housing. Works better than it did when we bought the refrigerator! Read More... 2 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Screwdrivers
