Whirlpool WP3398190 Timer (3-Cycle) OEM Part

Manufacturer's Part Number: WP3398190
Genuine Whirlpool part
Appliance Compatibility Tool
$176.52
IN STOCK - SHIPS TODAY
Compare At:
$208.29
You Save:
$31.77

Secure and trusted checkout with

IN STOCK Less than 100 left
Ships Today Guaranteed

Order now and we'll ship it out Today

Over 94% of our orders are delivered in 2 days or less

Call us 1-877-477-7278
Need Help? Chat with a Pro

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WP3398190 replaces AP6008362, 3398190, 2030, 3391658, 3398190R, PS11741497.

Description

This mechanical timer controls and advances each stage of a 3-cycle program. Replacing a worn timer restores proper sequencing so the appliance progresses through cycles automatically without stopping, skipping steps, or running indefinitely.
  • Controls the sequence and duration of each cycle
  • Routes power to components (motor, pump, heater) at the correct times
  • Advances the dial through each stage automatically
  • Symptoms may include cycles not advancing, stopping mid-cycle, running too long, or needing manual knob advancement
What's included: 1 mechanical timer assembly Install notes:
  • Disconnect electrical power before servicing
  • Access the timer from the control console; note orientation and mounting
  • Photograph/label wires and transfer terminal-for-terminal to the new timer
  • Secure the timer, reinstall the console, and run a test cycle to confirm proper advancing
