Parts for Maytag SDG5401AWW: 02 - Control Panel Parts

This is a genuine replacement mounting screw used to secure appliance components and panels. It restores proper fit and prevents movement that can cause noise or misalignment. What it does:

• Fastens panels, brackets, and small components in place
• Helps stop rattling or vibration caused by loose hardware
• Restores secure attachment after stripped or missing fasteners
• Matches OEM thread and head style for correct fit

• Use the correct driver to avoid stripping the head
• Tighten until snug; do not overtighten to prevent damage
• Disconnect power to the appliance before accessing internal components
• Replace matching screws in the area for consistent fit

Color: White. Measures about 3 inches in diameter.

The Timer Knob Insert is an OEM replacement part for Whirlpool dryers. This is a cap located on the timer knob on the control panel. Color: White. This is the timer knob cap only. For the complete assembly, you must also order the knob and skirt.

Causes of timer knob Insert failure can include cracked plastic from years of repeated turning motions. Wear on components also occurs due to extensive lifetime usage cycles.

Symptoms of a faulty timer knob insert include:

• Knob becomes loose, detached or inoperable for timings scrolling
• Cracks appear exposing internal timer parts

This is a genuine Whirlpool OEM replacement this part is also compatible with Maytag, Jenn-Air and some Kenmore models.

This selector knob attaches to the control shaft so you can choose cycles and options on your appliance. Replace a cracked or stripped knob to restore smooth, accurate settings without forcing or damaging the control stem.

• Attaches to the control shaft to operate the cycle/timer or option switch
• Common symptoms: knob is cracked, stripped, loose, spins freely, falls off, or is missing
• Restores positive, accurate control feel when selecting settings

• Disconnect power before servicing
• Pull the old knob straight off the shaft; avoid prying against the control panel
• Align the keyed/flat side and press the new knob on until fully seated
• If your original knob used a spring clip or insert, transfer it to the new knob before installation

Screw: 8-16 x 3/8 inch.

This timer regulates the length and progression of the drying cycle. When it fails, the dryer may not start, advance through the cycle, or shut off as expected. Replacing the timer restores reliable cycle control and end-of-cycle shutoff.

• Advances the selected cycle by opening and closing internal contacts as the dial turns
• Routes power to key circuits (motor and heat) at the proper time during the cycle
• Common symptoms include: cycle won't advance or end, dryer runs too long/short, won't start, or dial doesn't move
• Helps ensure consistent, predictable drying performance and automatic shutoff

• Disconnect power before servicing; for gas dryers, also shut off the gas supply
• Access the control console, remove the knob and mounting screws to release the timer
• Transfer wires from the old timer to the new one one-at-a-time, matching terminal positions
• Secure the timer, reinstall the knob and console, and run a test cycle to ensure proper advance and shutoff

Screw: 8-16 x 3/8 inch.

Color: White.

The Whirlpool screw is an OEM replacement part responsible for securing various components or parts on different types of Whirlpool appliances. The screw is designed to provide a secure and reliable fastening connection, ensuring that different parts of the appliance stay in place. It is commonly used in different locations within the appliance, such as the cabinet, panels, or other structural elements.

This part fixes the following symptoms:

• Loose or wobbly components within the appliance
• Panels or parts that are not securely attached
• Rattling or unusual noises due to loose parts
• Damaged or missing screw

The Whirlpool screw can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.
