Parts for Magic Chef RB18FA-3AL / 7B20B: 02 - Ice Maker Parts

Size: 8 x 1/2 ab.

This part has been discontinued by the manufacturer and is no longer available.

Ice maker water line: 1/4x 8ft.

Compression nut for 5/16" plastic water line.

Size: 1/4 inch. Nut for plastic water line.

This small retaining clip secures components in place inside the appliance, helping prevent movement, vibration, and premature wear. Replace a bent, fatigued, or missing clip to restore a solid, factory-tight hold.

• Holds panels, brackets, or tubing securely in their mounts
• Helps maintain alignment to reduce rattles, rubbing, or intermittent issues
• Common signs of failure: missing clip, loose fit, buzzing/vibration, parts that won't stay seated
• Restores proper retention after service, transport, or vibration-related fatigue

• Disconnect power and shut off gas/water before servicing
• Note the original clip's orientation; remove with needle-nose pliers
• Seat the new clip fully—do not over-bend; spring tension provides the hold
• Test operation before reassembly

Ice maker water line: 1/4x 8ft.

Color: Stainless steel

The Ice Dispenser Yoke is an OEM replacement part for Whirlpool refrigerators. It houses the ice dispensing mechanism and guides ice from the ice bucket into the chute upon user activation.

Causes of a bad ice dispenser yoke include worn gears or parts that lead to failure of the dispensing mechanism. Broken pieces or cracks in the yoke itself can also prevent proper ice delivery.

Symptoms of a bad ice dispenser yoke include:

• Ice jams or fails to dispense from the refrigerator door
• Chunky or uneven pieces of ice dispensed
• Grinding or sticking sounds coming from the ice dispensing area
• Dispenser mechanism not activating or operating as intended

This OEM Whirlpool part keeps operations efficient without spills or frustration. It's also compatible with models by Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, and Roper refrigerators.

Size: 8-32 x 1/4 inch.

This auger motor and yoke assembly powers the auger that moves ice from the freezer bin through the dispenser, restoring reliable ice delivery when the auger no longer turns or dispenses ice properly. What it does:

• Drives and supports the auger shaft that pushes ice to the dispenser chute
• Replaces a failed or noisy auger motor to restore normal ice dispensing
• Helps when the auger does not rotate, ice won't dispense, or the motor is unusually loud
• Interfaces with the dispenser gearbox/yoke to keep the auger aligned and turning

• One auger motor and yoke assembly

• Disconnect power to the refrigerator before beginning any work
• Remove the ice bin and any obstructing panels to access the auger assembly
• Handle parts and panels carefully—sharp edges may be present

This replacement ice tray holds and releases frozen cubes for a refrigerator icemaker, restoring normal ice production and cube release. Durable molded plastic fits the icemaker assembly and resupplies the ice bin with uniformly sized cubes. What it does

• Holds water while it freezes to form individual ice cubes.
• Releases formed cubes to the ice bin when the icemaker cycles, restoring proper dispensing.
• Commonly used when trays are cracked, warped, or no longer shedding cubes.
• Helps resolve symptoms like leaking inside the freezer, misshapen cubes, or reduced ice output.

• One replacement ice tray.

• Turn off power to the refrigerator or unplug before service to avoid injury.
• Remove ice bin and any retaining clips or fasteners to access the tray; handle gently to avoid damage.
• Inspect surrounding icemaker components for wear; replace additional damaged parts as needed.

By Maytag. Engineered to replace the timer controlled 12 and 24 cube style flex tray ice makers used by Admiral, Maytag, Magic Chef, Crosley and some Montgomery Ward refrigerators before 1990. Includes ducts, fill tube and related hardware. Replacement only, not for brand new installations.

This part has been discontinued by the manufacturer and is no longer available.

This part has been discontinued by the manufacturer and is no longer available.

The Screw is an OEM part for Whirlpool microwaves. It is responsible for securing various parts of the microwave together. This screw ensures a tight and secure fit for parts and helps maintain the structural integrity of the microwave, preventing any loose or rattling parts.

A bad microwave screw can occur due to wear and tear, accidental damage, or misplacement during maintenance or repairs. If you notice symptoms such as loose or wobbly components, difficulty in opening or closing the microwave door, or abnormal noises while the microwave is in use, it may be time to replace this part.

Symptoms of a bad microwave screw include:

• Loose or wobbly components
• Difficulty in opening or closing the microwave door
• Abnormal noises during operation

Restore your Whirlpool microwave by replacing the faulty or missing microwave screw with this genuine OEM part.

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.


The Screw is an OEM part for Whirlpool microwaves. It is responsible for securing various parts of the microwave together. This screw ensures a tight and secure fit for parts and helps maintain the structural integrity of the microwave, preventing any loose or rattling parts.

A bad microwave screw can occur due to wear and tear, accidental damage, or misplacement during maintenance or repairs. If you notice symptoms such as loose or wobbly components, difficulty in opening or closing the microwave door, or abnormal noises while the microwave is in use, it may be time to replace this part.

Symptoms of a bad microwave screw include:

• Loose or wobbly components
• Difficulty in opening or closing the microwave door
• Abnormal noises during operation

Restore your Whirlpool microwave by replacing the faulty or missing microwave screw with this genuine OEM part.

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.


This part has been discontinued by the manufacturer and is no longer available.

This part has been discontinued by the manufacturer and is no longer available.

The Light Bulb is an OEM part for Whirlpool refrigerators. This part illuminates the water and ice dispenser area, providing visibility and ease of use, especially in low light conditions.

Over time, the light bulb can fail due to normal wear and tear, electrical surges, or damage from vibrations and impacts.

Symptoms of a bad light bulb include:

• The dispenser area not lighting up when activated
• Flickering or dim lighting
• The bulb failing to turn on consistently

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

This replacement screw fastens trim, panels and small components to restore secure attachment and reduce rattling or movement. Use when a screw is missing, stripped, or damaged to keep parts aligned and operating quietly. What it does:

• Secures panels, brackets and trim to appliance assemblies
• Prevents vibration, rattling and misalignment caused by missing or damaged fasteners
• Replaces lost or stripped screws that can allow gaps or loose parts
• Helps maintain safe, stable operation by keeping components properly fastened

• Disconnect power (and water if applicable) before accessing interior panels
• Use the proper screwdriver or driver bit to avoid stripping the head
• Align parts before tightening and tighten until snug—do not overtighten
• Replace only with the correct OEM part to ensure proper fit and function

Size: 1/4" to 1/4" John Guess coupler. Compression fitting is also acceptable.

Size: 1/4 inch. Nut for plastic water line.
