Parts for Maytag DE16CA: 03 - Cabinet Removed Parts

The Lower Dishwasher Rack Assembly is an OEM part for Whirlpool dishwashers. This part holds and organizes dishes, pots, and pans in the lower section of the dishwasher, ensuring they are properly positioned for effective cleaning.

Causes of a bad lower rack can include wear and tear from regular use, exposure to harsh detergents or high temperatures, and physical damage from heavy or improperly loaded items.

Symptoms of a bad lower dishwasher rack assembly include:

• Rust or corrosion on the rack
• Broken or missing tines
• Difficulty sliding the rack in and out
• Poor arrangement of dishes, leading to ineffective cleaning

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

This terminal insulator assembly isolates and supports an electrical connection where it passes through the appliance chassis. Replacing a cracked or heat-damaged insulator helps prevent shorts and restores a safe, reliable connection.

• Electrically insulates a live terminal from the metal cabinet or oven wall
• Provides a secure pass-through/mounting point for the element/wire connection
• Helps prevent arcing, shorting, and localized heat damage at the connection
• Typical symptoms: visible cracks or burn marks on the insulator, tripped breaker, intermittent or no heat due to a compromised connection

• Disconnect power at the breaker or unplug the appliance before servicing
• Access the terminal area; label or photograph wiring to ensure correct reassembly
• Transfer wires one at a time; reuse existing hardware if serviceable and tighten connections securely
• Inspect nearby wire ends/connectors and replace any that are heat-damaged or brittle

Leg, adjustable (w/nut)

The Cycling Thermostat is an OEM part for Whirlpool dryers. It regulates and monitors the temperature inside the dryer during the drying cycle. It ensures that the dryer doesn't overheat and prevents potential damage to clothes or the dryer itself.

Causes of a faulty cycling thermostat can include wear and tear over time, electrical issues, or sensor malfunction.

Symptoms of a bad cycling thermostat may include:

• Clothes taking longer than usual to dry
• Inconsistent drying results
• Overheating or burning smell
• The dryer not heating at all

This OEM Whirlpool part can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

This part has been discontinued by the manufacturer and is no longer available.

This replacement screw fastens appliance panels, brackets, and components. Use it to replace missing, stripped, or rusted hardware to restore a secure fit and help reduce vibration or rattling during operation.

• Secures panels, brackets, and internal components to the cabinet or frame
• Helps prevent vibration, rattling, and misalignment from loose hardware
• Replaces a missing, rusted, or stripped original screw
• Matches the original fastener style for proper fit in specified locations

• Disconnect power; shut off gas and water supplies before servicing
• Use the correct screwdriver or nut driver and match length/thread to the original
• Start threads by hand to avoid cross-threading; do not overtighten, especially into plastic or thin metal

A replacement mounting screw used to secure appliance panels and components. This genuine-style fastener restores proper fit and prevents loose or rattling parts for many Whirlpool appliances. What it does:

• Fastens panels, trim, brackets, or components to the appliance frame
• Restores secure attachment when original screw is missing, stripped, or damaged
• Helps eliminate rattling, vibration noise, and loose-fitting parts
• Matches OEM fit and function when the correct part number is used

• Disconnect power (and water, if applicable) before servicing the appliance.
• Use the correct screwdriver or driver bit to avoid stripping the head; do not overtighten.
• Replace only with the exact part number to ensure correct fit; keep removed hardware organized for reassembly.

This is a replacement machine screw sized 8-18 x 3/8 that secures panels and components on compatible appliances. It restores proper fastening where a worn, stripped, or missing screw causes loose parts or rattling. What it does

• Fastens control panels, trim pieces, or brackets to the appliance chassis
• Replaces stripped, corroded, or missing screws that cause loose panels or vibrating noise
• Provides correct thread engagement for a secure hold in tapped holes
• Small hardware solution often used during door, console, or interior repairs

• One 8-18 x 3/8 machine screw (quantity: 1)

• Use the correct screw size and thread; do not force a different-size fastener into tapped holes
• Hand-start the screw to avoid cross-threading, then tighten with the appropriate screwdriver
• Disconnect power before accessing internal components or panels on electrical appliances
• If metal threads are damaged, repair with a helicoil or replace the damaged component rather than over-torquing

This hex-head sheet metal screw secures appliance panels, brackets, and trim for a tight, rattle-free fit. Replace missing or stripped fasteners to keep covers and components firmly in place and restore proper alignment.

• Fastens sheet-metal parts, brackets, and trim using a hex drive
• Replaces worn, rusted, missing, or stripped screws
• Helps reduce vibration and rattling from loose panels
• Common signs you need this fastener: head or threads stripped, screw won't tighten, panel or handle coming loose

• Unplug the appliance before service; turn off water supply if working near water lines
• Use the correct nut driver or socket to avoid rounding the head
• Replace one fastener at a time to maintain alignment; do not overtighten
• Match screw type/length to the original location as specified by the manufacturer

A replacement nut-lock used to secure fasteners and keep panels or components from backing off due to vibration. Simple, durable hardware that restores a secure connection and reduces rattling or loose parts. What it does:

• Secures a mating bolt or stud to prevent loosening from vibration or movement
• Restores a solid attachment for panels, brackets, or assemblies that may come loose
• Helps eliminate symptoms such as rattling, vibrating, or intermittent panel movement
• Suitable where a locking fastener is required to maintain a reliable connection

• Disconnect power and follow appliance safety procedures before starting work
• Locate the matching stud or bolt and remove the old fastener if present
• Use the correct-size wrench or socket and tighten until the nut-lock seats; avoid over-tightening
• Inspect threads and mating hardware for damage; replace damaged components

The Leveling Leg Pad is an OEM replacement part for Whirlpool washing machines. This small but essential component fits beneath the leveling legs, providing stability and preventing the appliance from moving or vibrating excessively during operation. It also protects flooring surfaces from potential scratches or damage.

Symptoms of a bad Leveling Leg Pad include:

• Increased vibration or noise during the wash or spin cycle
• The washing machine wobbling or becoming unsteady
• Visible wear, cracks, or damage to the pad

Causes of a failing Leveling Leg Pad can include wear and tear from prolonged use, exposure to moisture, or excessive weight causing deformation. Replacing worn pads helps maintain the appliance's balance and efficiency.

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

For the leveling leg order 22003428.

The Whirlpool screw is an OEM replacement part responsible for securing various components or parts on different types of Whirlpool appliances. The screw is designed to provide a secure and reliable fastening connection, ensuring that different parts of the appliance stay in place. It is commonly used in different locations within the appliance, such as the cabinet, panels, or other structural elements.

This part fixes the following symptoms:

• Loose or wobbly components within the appliance
• Panels or parts that are not securely attached
• Rattling or unusual noises due to loose parts
• Damaged or missing screw

The Whirlpool screw can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

This motor clip secures a motor to its mounting bracket or housing, keeping it aligned and stable during operation. Replacing a bent, broken, or missing clip helps stop rattling and prevents the motor from shifting. What it does:

• Retains the motor on its mounting bracket or frame
• Helps maintain alignment to reduce vibration and noise
• Prevents movement that can cause rubbing or wire strain
• Direct replacement when the original clip is damaged or missing

• One motor clip

• Disconnect power before servicing; allow all moving parts to stop
• Access the motor area, note the clip's orientation, and remove the damaged clip
• Seat the motor fully, then install the new clip to secure it to the bracket
• Inspect related mounts/grommets and wiring for wear; verify clearances before restoring power

This elbow redirects a fluid or air line inside the appliance to allow routing around components and tight spaces. It restores proper flow path and helps stop leaks or blockages when the original elbow is cracked or worn. What it does:

• Provides a sealed change of direction for a water, drain, or vent line inside the appliance
• Replaces a cracked or broken elbow that can cause leaks, water pooling, or reduced flow
• Re-establishes the correct routing to prevent kinks and stress on connected hoses or tubing
• Helps eliminate intermittent draining or venting issues caused by a damaged fitting

• Disconnect power and shut off water supply before accessing the part
• Verify orientation and routing before removing the old elbow to ensure correct reinstallation
• Inspect and replace any worn clamps, gaskets, or hoses when installing the new elbow
• Tighten fittings to secure but avoid over-tightening which can crack plastic components

This factory fastener secures appliance components such as panels, brackets, and trim. Replacing a missing or stripped screw restores a tight fit, reduces rattling, and helps keep assemblies aligned for reliable performance.

• Fastens appliance parts to maintain structural integrity and alignment
• Helps address symptoms like loose or vibrating panels, gaps, or hardware that won't stay tight
• Replaces lost, damaged, or corroded fasteners during repairs or reassembly
• OEM-matched thread and fit for the specified location

• Disconnect power; shut off gas or water supplies before servicing
• Replace one screw at a time to preserve alignment of parts
• Start threads by hand to avoid cross-threading; tighten snugly without over-torquing
• Use the correct driver size/type specified for your model
